12 Technical Data

Communication
SMA devices
SunSpec Modbus devices
I/O systems and meters
RS485 devices
Connections
Voltage supply
Network (LAN)
USB
Voltage supply
Voltage supply
Input voltage range
Power consumption
Ambient Conditions in Operation
Ambient and storage temperature
Max. permissible value for relative humidity
(non-condensing)
Maximum operating altitude above mean sea
level (MSL)
Degree of protection
General Data
Dimensions (W x H x D)
Weight
Mounting location
Mounting type
Status display
Operating manual
Max. 50 devices, Speedwire, 100 Mbit/s
Max. 20 devices
Ethernet, 10/100 Mbit/s, Modbus TCP
Modbus RTU (1200 baud, 9600 baud or
19200 baud) / SMA Data1 (1200 baud and
19200 baud)
2-pole connection, MINI COMBICON
2 x RJ45 switched, 10BaseT / 100BaseT
1 x USB 2.0, type A
External power supply unit (available as an
accessory)
10 V DC to 30 V DC
Typically 4 W
-20°C to +60°C (-4°F to +140°F)
5% to 95%
0 m to 3000 m (≥70 kPa)
IP20 (NEMA 1)
161.1 mm x 89.7 mm x 67.2 mm (6.3 in x
3.5 in x 2.7 in)
220 g (0.49 lb)
Indoors
Top-hat rail mounting / wall mounting
LEDs for system and communication status
