SMA Solar Technology AG
System LED
Flashing orange
and green in alter-
nation
Glowing green
Network port LEDs
The colors of the network port LEDs and what each color indicates are not
standardized
The colors used by SMA Solar Technology AG for the Link LED and the Activity LED and what
each color indicates may be different to those used in third-party products.
Figure 3: Network port LEDs
Position Designation
A Link LED
B Activity LED
4.5 Sunny Portal
Sunny Portal is an Internet portal which enables you to monitor systems and to visualize system
data.
The Sunny Portal serves as the user interface for the extended configuration of the product, of
system sections, systems, system groups and the entire system portfolio. The Sunny Portal monitors
and analyzes the system and its components on all levels.
There are two Sunny Portal versions: the classical Sunny Portal (https://www.sunnyportal.com) and
the newly developed Sunny Portal powered by ennexOS (https://ennexOS.sunnyportal.com). Both
systems differ in their supported functions. With an existing user account, you can log into both
portals, the Sunny Design (system planning software from SMA) as well as the app SMA 360°.
4.6

Interfaces and Functions

The product can be equipped or retrofitted with the following interfaces and functions: The
availability of the functions depends on the product version and additional options purchased.
Operating manual
COM LED Explanation
Glowing red Function button has been pressed for between 15 and 20
seconds.
- Function button has been pressed for longer than 20 sec-
onds.
Color
Green
Yellow
Explanation
Shows the network connection status.
Shows network connection activity.
EDMM-10-BE-en-27
4 Product Overview
21
