Icon
4.3

Function Button

Depending on how long it is activated for, the function button performs the following functions:
• 1 to 5 seconds: no effect
• 5 to 10 seconds: restarts the Data Manager
• 10 to 15 seconds: resets password and administrator account of the Data Manager
• 15 to 20 seconds: resets the Data Manager to the default settings
• Longer than 20 seconds: no effect
The length of time the function button has been activated for is indicated via LED signals (see
Section 4.4, page 19).
4.4

LED Signals

System- and COM LED
The LEDs indicate the operating state and communication status of the product. Not relevant
operating states are shown as "-".
System LED
Startup process
Operating manual
Explanation
RCM (Regulatory Compliance Mark)
The product complies with the requirements of the applicable Australian stan-
dards.
This equipment contains specified radio equipment that has been certified to
the Technical Regulation Conformity Certification under the Radio Law.
ICASA
The product complies with the requirements of the South African standards for
telecommunication.
ANATEL
The product complies with the requirements of the Brazilian standards for
telecommunication.
Este equipamento opera em caráter secundário, isto é, não tem direito a pro-
teção contra interferência prejudicial, mesmo de estações do mesmo tipo, e
não pode causar interferência a sistemas operando em caráter primário.
The product complies with the Moroccan safety and EMC requirements for
electronic products.
COM LED Explanation
4 Product Overview
