- Page 1 FA01639-EN LHS A/01 LHS V/01 LHS V/01 PLUS INSTALLATION AND CONFIGURATION MANUAL English...
-
Page 2: General Precautions
• Only use this product for its intended purpose. Any other use is hazardous. • Came S.p.A. is not liable for any damage caused by improper, erroneous or unreasonable use. -
Page 3: Description Of Parts
PRODUCT DATA AND INFORMATION Description LHS A/01 (840AA-0060) Monolith intercom entry panel for X1 system expandable up to 4 calls. LHS V/01 (840AA-0040) Monolith video entry panel for X1 system expandable up to 4 calls. LHS V/01 PLUS (840AA-0050) Monolith video entry panel for X1 system expandable up to 4 calls, with Bluetooth and built-in RFID reader for access control. - Page 4 Call button P1 PROG LED (yellow) Call button P3 Call button P2 Warning LED Call in progress Call button P4 Warning LED Electric lock activation CAME KEY connector and rubber cap RESET button The [RESET] button allows you to restart the device.
- Page 5 Size...
- Page 6 Technical data MODELS LHS V/01 LHS V/01 PLUS LHS A/01 IP protection rating IK protection rating Operating temperature (°C) -25 ÷ +55 -25 ÷ +55 -25 ÷ +55 Storage temperature (°C) * -25 ÷ +70 -25 ÷ +70 -25 ÷ +70...
-
Page 7: Installation
INSTALLATION Preliminary operations Wall-mounted installation Installation with rain cover (optional) - Page 8 Recess installation Button assembly...
-
Page 10: Function Of Terminals
Function of terminals ① ⑤ Local power supply input 16-18 V DC Door release button (NO) ② ⑥ BUS output Programmable I/O (Default NO port contact input) ③ ⑦ Max. 12V - 1A electric lock Max. auxiliary contact 1 A 30 V (Default AUX 2) ④... -
Page 11: Electrical Connections
ELECTRICAL CONNECTIONS AGT V AGT V – – CL RES CL RES VAS/101 − − B OUT − − > CONTROL BOARD > VLS/2... -
Page 12: Example Set-Ups
EXAMPLE SET-UPS Example set-up without VA/01 XDV/304 VAS/101 Cable length Maximum number of internal receivers per cable type Section Cable type VCM/1D La, Lb VCM/1D or UTP CAT5 Master 2x1mm² or 2x2.5mm² Slave Section Max. section length (m) UTP CAT5 La + Lb 100 VCM/1D or 60 UTP/CAT 5 Master... - Page 13 Example set-up with VA/01 XDV/304 VA/01 Cable length Maximum number of internal receivers per cable type Section Cable type VCM/1D La, Lb VCM/1D or UTP CAT5 Master L1, L2, L3 VCM/2D Slave Section Max. section length (m) UTP CAT5 100 VCM/1D or 60 UTP/ Master La + Lb CAT 5...
- Page 14 PROGRAMMING With a CAME KEY device, the CONNECT SetUp app can also be used for programming. PROGRAMMING ENTRY PANELS WITHOUT VA/01 - A/01 Summary table PROG button functions Press for 3 to 6 seconds Enter fi rst programming Program calls in an already programmed system...
- Page 15 Entering programming mode > 3’’ < 6’’ Press the [PROG] button for 3 seconds to enter programming mode. Release the button within 6 seconds. The warning LEDs will fl ash together with the button LEDs. The [PROG] LED will remain on. If the [PROG] LED does not light up, there has been a malfunction.
- Page 16 Associating internal receivers In [Programming calls] lift the internal-receiver handset to be confi gured (if present) and press and hold the buttons together The video and the LED crown on the video camera will activate (video versions only). On the entry panel, press the call button to be associated with the internal receiver. A tone confi...
- Page 17 Enable the function when associating the internal receiver. Press and hold the button. The LED switches on to confi rm the function was activated. Repeat the procedure for each internal receiver on which you wish to activate the function. Re-associating the internal receiver automatically deactivates the OPEN GATE function, which must be reactivated.
- Page 18 Programming proximity cards or tags* *LHS V/01 PLUS model only This function is used to program proximity cards or tags, and assign one or more outputs to each to be controlled. Do this when there are no internal receivers being associated. Each new programmed card/tag overwrites the previous one.
- Page 19 Programming the intercom function Enabling/Disabling the intercom function With VSE/301.01, please see the power supply unit documentation. Leave the function disabled on the entry panel. The feature is disabled by default. + 20’’ Press and hold the [PROG] button for approximately 20 seconds, until the LEDs fl...
- Page 20 On the internal receiver, press the INTERCOM button with which you wish to associate it. Wait for the beep that will confi rm successful programming. Repeat for all the internal receivers you wish to include in the intercommunicating group. Exiting programming mode To exit programming mode, press the [PROG] button.
- Page 21 PROGRAMMING ENTRY PANELS WITH VA/01 AND A/01 Entering programming mode – M1 PROG Press and hold the power supply unit [PROG] button for at least 3 seconds. LEDswill fl ash together with the [P1-P4] button LEDs. The [PROG] LED on the power supply unit and entry panel turn on and stay on. Programming call buttons Press [P1] to confi...
- Page 22 To continue with programming on a second entry panel, press any active call button. The LED will switch off . When reprogramming a system, you start from this step. You do not need to program the call buttons again. To repeat [Programming call buttons] see the paragraph on [Reprogramming a system]. Associating internal receivers In [Programming calls] lift the internal-receiver handset to be confi...
- Page 23 On the entry panel, press the call button to be associated with the internal receiver. A tone confi rms that the setting has been stored. Programming OPEN GATE and GATE STATUS function (latch) Only for internal receivers with OPEN GATE function Use this function to control and display the gate status (open/closed).
- Page 24 Programming the AUTOMATIC DOOR RELEASE function* *For internal receivers with AUTOMATIC DOOR RELEASE function only This function is used to open the entrance automatically when there is a call from the entry panel. No communication is activated and the call ends automatically. Enabling the function allows the user to activate/deactivate it as required.
- Page 25 Programming proximity cards or tags with local control* *LHS V/01 PLUS model only This function is used to program proximity cards/tags, and assign one or more outputs to each to be controlled. Do this when there are no internal receivers being associated. Each new programmed card/tag overwrites the previous one.
- Page 26 Programming proximity cards or tags with access control* *LHS V/01 PLUS model only The internal receivers must be associated before programming. A tag or card saved with local control cannot perform the access control function and vice versa. Inserting cards or tags Press the [PROG] button on the power supply to exit programming mode.
- Page 27 At the end of the saving process, remove the PROG RFID jumper and put it to one side. Deleting tags/cards You can delete all cards or tags for a single group/button. Insert the power supply unit RFID PROG jumper in the “-” position. and the PROG LEDs will fl...
-
Page 28: Restoring Factory Settings
Perform the delete procedure, choosing from one of the following methods: Run the proximity card or tag over the RFID reader. Press the call button assigned to the group you want to LED switches on and you will hear a tone to delete. - Page 29 SETTINGS Audio and electric lock time settings Remove the rubber cap to access the settings. Use a screwdriver and turn the screws clockwise (to increase) or anticlockwise (to decrease). The opening time of the electric lock can be set from 1 to 10 seconds (Default 1 second).
- Page 30 Adjusting video camera LED crown brightness* *video models only In [Programming calls], press the button on any internal receiver connected to the system and activate the video camera. Press any call button to increase or decrease the brightness of the video camera LED crown.
-
Page 31: Final Operations
FINAL OPERATIONS Wall-mounted installation Installation with rain cover (optional) Recess installation... - Page 32 CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso - Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941 info@came.com - www.came.com...
