Summary of Contents for CAME Entrotec Entroview
- Page 1 guide...
- Page 2 entroview user guide Unlock Privacy Adjust Low Med Hi When someone calls Lift the handset to answer an incoming call. The video monitor will display for the length of the call. While on a call To let the caller gain access, press Unlock. Replace the handset to complete the call.
-
Page 3: Wiring Diagram
installation guide wiring diagram ENTROVIEW PLUS PRIVACY DOOR OPEN Suggested Colour Code Suggested Colour Code Cat 5 / Cat 6 6 Pair CW1308 White/Blue DR - White/Blue+Blue/White Blue VT - White/Orange+Orange/White White/Orange 0V - White/Green+White/Brown *Orange BZ - White/Grey White/Green S2 - Green/White Green S1 - Brown/White... -
Page 4: Video Setup
entroview user guide video setup Press the Menu button to turn the screen on. Press Menu to cycle through the on screen display options. ENTROV IEW Press + or – to adjust the selected parameter. Once adjusted the settings will store and the screen will turn off. PR IVAC Y DOOR O PE N Menu... - Page 5 entroview user guide ringtones To adjust the ringtone press and hold Privacy to start the ringer. Press Privacy to select the ringtone options and press Door Open to store.
- Page 6 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
