Chapter 3: BIOS Setup
PCH-IO Configuration
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCH-IO Configuration
► SATA And RST Configuration
► HD Audio Configuration
PCH LAN Controller [Enabled]
Wake on LAN [Enabled]
Restore on AC power loss [Last State]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
PCH LAN Controller
Enables or disables onboard NIC.
Wake on LAN
Enables or disables integrated LAN to wake the system.
Restore on AC Power Loss
Select AC power state when power is re-applied after a power failure.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
SATA And RST Configuration
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Controller(s)
Enables or disables the SATA controller.
SATA Mode Selection
Configures the SATA mode. The options are AHCI and Intel RST Premium.
Port 0 to Port 3
Enables or disables SATA port 0 to port 3.
Hot Plug
Enables or disables hot plugging feature on SATA port 0 to port 3.
34
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced Chipset
SATA Controller(s) [Enabled]
SATA Mode Selection [AHCI]
Serial ATA Port 0 Empty
Software Preserve Unknown
Port 0 [Enabled]
[Disabled]
Hot Plug
Configured as eSATA Hot Plug supported
Spin Up Device [Disabled]
SATA Device Type [Hard Disk Drive]
Topology [ISATA]
SATA Port 0 DevSlp [Disabled]
DIT0 Configuration [Disabled]
DIT0 Value 625
DM Value 15
Serial ATA Port 1 Empty
Software Preserve Unknown
Port 1 [Enabled]
Hot Plug [Disabled]
Configured as eSATA Hot Plug supported
Spin Up Device [Disabled]
SATA Device Type [Hard Disk Drive]
Topology [ISATA]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
▲
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
