6.14 Master and DAC1-4 Volume Control (Address 17h, 18h, 19h, 1Ah, & 1Bh)
7 6
6.14.1 x Volume Control
Sets the level of the x Volume Control. Each volume step equals
4.6.5.1 on page 39
x VOLUME
00000000
00001111
00010000
00010001
00011000
...
11111110
11111111
6.15

Interrupt Control (Address 1Eh)

7 6
INT MODE INT POL [1:0]
6.15.1 INT MODE
Sets the behavior mode of the interrupt registers of the device. In the default configuration, if the interrupt
notification registers are read and any error is found to have occurred since the last clearing of that reg-
ister, the device will automatically set the corresponding mask bit in the appropriate mask register. In the
non-default configuration, the mask bits will not be set automatically.
INT MODE
0
1
6.15.2 Interrupt Pin Polarity
Sets the output mode of the interrupt pin.
INT POL
00
01
10
11
DS900PP2
5 4
x VOLUME[7:0]
for the muting behavior of these volume registers.
x Volume is: [dB]
+6.02
+0.38
0
-0.38
-3.01
...
-89.55 (most total attenuation before mute)
-89.92 (least total attenuation before unmute)
5 4
Reserved
Upon the reading of an error out of the interrupt notification bits, the CS4244 will:
Automatically set the corresponding mask bit.
Not set the corresponding mask bit.
Output mode of the interrupt pin is:
Active High
Active Low
Active Low/Open Drain
Reserved
3 2
6.02
/
16
3 2
Reserved Reserved
CS4244
1 0
dB ~= 0.38 dB. See Section
1 0
Reserved Reserved
56
