COSMO 40 1
Continious measurements can be used. This function is used for minimum/maximum measurements. The
minimum value must be used for measurements at right angles to the target; the maximum distance for
all other measurements. Be sure that the first measurement and distance are measured at right angles. Use
continious measurement function.
Indirect measurement – determing a distance using 2 auxilary measurements
This function is used when height and distance can't be measured directly.
Press button (2) 3 times. The symbol "triangle" is displayed. The distance to be measured is blinking in the
symbol triangle. Press button (1) to take distance measuring (hypothenuse of triangle). The result is displayed
in the second line. This measurement can be taken in the indirect measurement function. Press and hold but-
ton (1) for 2 sec. After second pressure of the button (1) maximum value is fixed.
The second distance to be measured is blinking in the symbol triangle. Press button (1) to take distance
measuring. There is a right angle between laser beam and the length you need to measure. That's why you
should work in continious mode. Press and hold button (1) for 2 sec. After second pressure of the button (1)
