Bio-Logic
Bio-Logic
ULTRAVIOLET WATER PURIFIERS
Models
BIO 1.5
BIO 3.0
Read and Follow All Safety Instructions. Save These Instructions.
SINCE 1963
Manufacturers / Engineers / Sales / Service
Germicidal Ultraviolet - Equipment & Lamps
Extensive Product Information Available at:
ultraviolet.com
Document No. 98-1523D1 • July 2015 • ©2015 Atlantic Ultraviolet Corporation
Ballast
120v 50/60 Hz
230v 50/60Hz
10-0518A
10-0518A
Installation
Installation,
Operation
& Maintenance
®
®
Ballast
10-0514A
10-0514A
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlantic Ultraviolet BIO 1.5
Summary of Contents for Atlantic Ultraviolet BIO 1.5
- Page 1 Read and Follow All Safety Instructions. Save These Instructions. Installation, Installation Operation & Maintenance SINCE 1963 Manufacturers / Engineers / Sales / Service Germicidal Ultraviolet - Equipment & Lamps Extensive Product Information Available at: ultraviolet.com ® Document No. 98-1523D1 • July 2015 • ©2015 Atlantic Ultraviolet Corporation...
-
Page 2: Table Of Contents
® Ultraviolet Water Purifiers, Models BIO 1.5 and BIO 3.0 using ballast no. 10-0518A and 10-0514A. Questions that are not specifically answered by these instructions should be directed to the Factory. Atlantic Ultraviolet Corporation takes all possible precautions when packaging equipment to prevent damage. Carefully inspect and report all damage. -
Page 3: Safety Warnings
SAFETY WARNINGS • All personnel should be alerted to the potential hazards indicated by the product safety labeling on this unit. • The following conventions are used to indicate and classify precautions in this manual and on product safety labeling. Failure to observe precautions could result in injury to people or damage to property. -
Page 4: Product Application
PRODUCT APPLICATION ONSTRUCTION • The water purifier is designed to mount horizontally. • The water purifier’s dual chamber heads are removable and may be rotated independently, which aids in the installation, maintence or the retrofiting of an existing system. • The water purifier’s chamber and chamber head are passivated and electropolished type 316 Stainless Steel. -
Page 5: Installation
INSTALLATION OCATION The water purifier is intended for indoor use only. The water purifier is designed to mount horizontally. The water purifier should be protected from the elements and from temperatures below freezing. The ambient temperature, in the area surrounding the water purifier, should be between 35 F and 100 Electrical power supplied to the water purifier MUST match power requirements listed on the water purifier. -
Page 6: Recommended Installation
ECOMMENDED NSTALLATION Figure 2 - Recommended Installation Note: Drain Pan Recommended. Water BIO-1.5 and BIO-3.0 purifi er should be installed at 120v 50/60Hz using ballast no. 10-0518A has ground wire attached. minimum of 18” above fl oor BIO-1.5 and BIO-3.0 230v 50/60Hz ballast no.10-0514A has ground wire attached. -
Page 7: Installation : Bio
: BIO-1.5 BIO-3.0 .10-0518A 120 50/60H NSTALLATION USING BALLAST NO Z AND .10-0514A 230 50/60H USING BALLAST NO SAFETY EQUIPMENT REQUIRED TO PERFORM TASK Remove water purifier from shipping carton. Inspect water purifier, power cord and plug for damage. Do not operate if there is any damage to the purifier, power cord or plug. -
Page 8: Recommended Options
19. Gloves: Gloves should be worn to offer hand protection from sharp threats like glass, wire, and metal. NOTE: The recommended options above are available from Atlantic Ultraviolet Corporation or a distributor of Atlantic Ultraviolet Corporation’s products. For the other devices that may be required for your application, please contact your... -
Page 9: Maintenance
MAINTENANCE The water purifier is designed to operate with a minimal amount of maintenance, providing the water quality does not exceed maximum concentration levels, see “Water Quality” in the “Product Application” section. Ordinary maintenance consists of; • Lamp replacement is recommended every 10,000 hours of operation, approximately 12 months of continuous service. •... -
Page 10: Lamp Installation Or Replacement : Bio 1.5 And Bio 3.0 120 Ballast No .10-0518A)
BIO-1.5 BIO-3.0 .10-0518A NSTALLATION OR EPLACEMENT USING BALLAST NO 50/60H .10-0514A 230 50/60H Z AND USING BALLAST NO Figure 4 - Lamp Replacement for BIO-1.5 and BIO-3.0 (ballast no 10-0518A or 10-0514A) Step 1 - Disconnect Power to Water Purifier and Remove Ground Connector Step 2 - Remove End-Cap Step 3 - Remove Socket Step 4 - Remove Lamp... -
Page 11: Quartz Sleeve Installation , Cleaning Or Replacement
UARTZ LEEVE NSTALLATION LEANING OR EPLACEMENT Figure 5 - BIO-1.5 & BIO-3.0 120v 50/60Hz (ballast no. 10-0518A) Step 5 - Remove Washer & O-Ring Step 4 - Remove Gland Nut From Each End Step 6 - Remove Quartz Sleeve from each end SAFETY EQUIPMENT REQUIRED TO PERFORM TASK WARNING: Disconnect power to water purifier. -
Page 12: Replacement Of Broken Quartz Sleeve
EPLACEMENT OF ROKEN UARTZ LEEVE Figure 6 - Chamber Head Removal SAFETY EQUIPMENT REQUIRED TO PERFORM TASK CAUTION: Broken Quartz is SHARP. It is recommended that protective goggles and gloves are worn when handling. WARNING: Disconnect power to water purifier. •... -
Page 13: Isposal Of
ISPOSAL OF ERCURY DDED AMPS Germicidal ultraviolet lamps, like standard fluorescent lamps contain small amounts of mercury. Mercury added lamps should not be placed in the trash. Dispose of properly. For further information regarding the disposal and recycling of lamps containing mercury, along with Federal and State requirements visit http://www.lamprecycle.org. ®... -
Page 14: Technical Specifications
TECHNICAL SPECIFICATIONS Table 4 - Technical Specifications Model: BIO 1.5 BIO 3.0 Flow Rate (GPM): Inlet\Outlet Size: 3/8”FNPT 3/8”FNPT Number of Lamps: Lamp Model No.: 05-1366-R 05-1370-R Quartz Sleeve: Length: 14-1/2” 20-1 /8” Width: 3-21/32” 3-21/32” Height: 3-7/8” 3-7/8” Voltage: ... -
Page 15: Replacement Parts
REPLACEMENT PARTS Figure 7 - Exploded View Table 6 - Replacement Parts BIO-1.5 to BIO-3.0 BIO-1.5 BIO-3 Item No. Description Quantity Rubber O-Ring, Static Gland 00-1108B 00-1108B Lamp Socket & Ballast, 120v 50/60Hz 10-0518A 10-0518A Lamp Socket & Ballast, 230v 50/60Hz 10-0514A 10-0514A Lamp Socket &... -
Page 16: User Assistance
® Under no circumstances shall the Atlantic Ultraviolet Corporation be liable for any incidental, consequential or special damages, losses or expenses arising from the contract for this product, or in connection with the use of, or inability to use, our product for any purpose whatsoever.
