PPC2-Cxxx-ADL Series Panel PC
MODEL:
MODEL:
PPC2-Cxxx-ADL Series
Series
Panel PC equips 12th Gen Intel® Core™ i9/i7/i5/i3 or
Pentium® Processor, Dual-Channel DDR4 SO-DIMM, One
M.2 E Key & One M.2 M Key Expansion Slots, SATA 6Gb/s,
IP 65 Compliant Front Panel and RoHS Compliant
Rev. 1.00 – March 28, 2023
e
User Manual
Page i
Advertisement
Table of Contents
Troubleshooting
Related Manuals for IEI Technology PPC2-C ADL Series
Summary of Contents for IEI Technology PPC2-C ADL Series
- Page 1 PPC2-Cxxx-ADL Series Panel PC MODEL: MODEL: PPC2-Cxxx-ADL Series Series Panel PC equips 12th Gen Intel® Core™ i9/i7/i5/i3 or Pentium® Processor, Dual-Channel DDR4 SO-DIMM, One M.2 E Key & One M.2 M Key Expansion Slots, SATA 6Gb/s, IP 65 Compliant Front Panel and RoHS Compliant User Manual Page i Rev.
- Page 2 PPC2-Cxxx-ADL Series Panel PC Revision Date Version Changes March 28, 2023 1.00 Initial release Page ii...
- Page 3 PPC2-Cxxx-ADL Series Panel PC Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
- Page 4 PPC2-Cxxx-ADL Series Panel PC Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. Vorsicht! Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. Attention! La mise au rebut ou le recyclage de ce produit sont généralement soumis aux lois et/ou directives de respect de l'environnement.
- Page 5 PPC2-Cxxx-ADL Series Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 6 PPC2-Cxxx-ADL Series Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
-
Page 7: Table Of Contents
PPC2-Cxxx-ADL Series Panel PC Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................4 RONT ANEL 1.5 R ......................4 ANEL 1.6 B ...................... - Page 8 PPC2-Cxxx-ADL Series Panel PC 3.10 M ..................29 OUNTING THE YSTEM Wall Mounting ....................29 Panel and Rack Installation ................31 Arm Mounting ....................35 Stand Mounting ....................37 3.11 S ................. 38 ERIAL EVICE ONNECTION RS-232 Serial Ports ..................38 RS-232/422/485 Serial Port ................
- Page 9 PPC2-Cxxx-ADL Series Panel PC EC Flash Connector (EC_SPI1) ..............52 I2C Connector (I2C1) ..................53 IDPM Slot (IDPM1) ..................53 ME Flash Connector (FLASH1) ..............54 M.2 M-Key Slot (NGFF1) ................54 M.2 A-Key Slot (NGFF4) ................55 SATA 6Gb/s Connector (S_ATA1) ..............56 SATA Power Connector (SATA_PWR1) ............
- Page 10 PPC2-Cxxx-ADL Series Panel PC List of Figures Figure 1-1: PPC-Cxxx-ADL Panel PC .................... 2 Figure 1-2: Front Panel ........................4 Figure 1-3: Rear View ........................4 Figure 1-4: Bottom Panel ....................... 5 Figure 1-5: PPC2-C15-ADL Dimensions (Unit: mm) ..............9 Figure 1-6: PPC2-CW15-ADL Dimensions (Unit: mm) ..............10 Figure 1-7: PPC2-C17-ADL Dimensions (Unit: mm) ..............11 Figure 1-8: PPC2-C19-ADL Dimensions (Unit: mm) ..............12...
- Page 11 PPC2-Cxxx-ADL Series Panel PC Figure 3-22: Machine mounted to panel ..................34 Figure 3-23: Installation Panel Mount Kit ...................34 Figure 3-24: Tighten the Mounting Screws ................35 Figure 3-25: Install into a Rack ....................35 Figure 3-26: Arm Mounting Retention Screw Holes ..............36 Figure 3-27: Arm Mounting (ARM-11-RS) ...................37 Figure 3-28: Stand Mounting Retention Screw Holes ...............37 Figure 3-29: Stand Mounting .......................38...
- Page 12 PPC2-Cxxx-ADL Series Panel PC List of Tables Table 1-1: Model Variations ......................3 Table 1-2: PPC2-C15/CW15/C17-ADL Specifications ..............6 Table 1-3: PPC2-CW19/C19/CW22-ADL Specifications .............. 8 Table 2-1: Package List ........................17 Table 2-2: Optional Items ......................18 Table 3-1: AT/ATX Mode Selection .....................28 Table 3-2: RS-232 Serial Port Pinouts ..................39 Table 3-3: RS-232/422/485 Serial Port (COM3) Pinouts ............39 Table 5-1: Peripheral Interface Connectors ................50...
-
Page 13: Introduction
PPC2-Cxxx-ADL Series Panel PC Chapter Introduction Page 1... -
Page 14: Overview
PPC2-Cxxx-ADL Series Panel PC 1.1 Overview Figure 1-1: PPC-Cxxx-ADL Panel PC The PPC-Cxxx-ADL panel PC is powered by 12th Gen Intel® Core™ i9/i7/i5/i3 and Pentium® Processor. The PPC-Cxxx-ADL is a heavy industrial panel PC with rugged and trendy design which can be applied in harsh industrial environments and enriches aesthetic experience at the same time. -
Page 15: Model Variations
PPC2-Cxxx-ADL Series Panel PC 1.2 Model Variations The model variations of the PPC2-Cxxx-ADL Series panel PC series are listed below. Size Resolutions Processor Model 15" 1024x768 Intel ® Pentium ® Gold G7400 PPC2-C15-ADL-P/4G-R10 15" 1024x768 Intel ® Core™ i3-12100 PPC2-C15-ADL-i3/4G-R10 ®... -
Page 16: Front Panel
PPC2-Cxxx-ADL Series Panel PC Anti-glare and anti-UV touchscreen ◼ Support gloved and wet hand operation ◼ Supports dual 2.5G Ethernet port ◼ HDMI 2.0 display output ◼ RoHS compliant design ◼ 1.4 Front Panel The front side of the PPC-Cxxx-ADL (Figure 1-2) is a flat panel LCD touchscreen surrounded by an aluminum frame. -
Page 17: Bottom Panel
PPC2-Cxxx-ADL Series Panel PC 1.6 Bottom Panel An overview of the bottom panel is shown in Figure 1-4. Figure 1-4: Bottom Panel 1.7 Technical Specifications PPC2-C15-ADL PPC2-CW15-ADL PPC2-C17-ADL LCD Display 15” (4:3) 15.6” (16:9) 17” (5:4) Max. Resolution 1024 (W) x 768 (H) 1920 (W) x 1080 (H) 1280 (W) x 1024 (H) Brightness... -
Page 18: Table 1-2: Ppc2-C15/Cw15/C17-Adl Specifications
PPC2-Cxxx-ADL Series Panel PC LAN1: Intel® I225 + LAN2: Intel® I225 Ethernet 1 x PCIe Gen4 x16 Slot with x16 Signal Expansion 1 x M.2 E-Key 2230 (PCIe Gen3 x1 + CNVIo + USB 2.0) 1 x M.2 M Key 2242/2280 NVMe (PCIe Gen3 x4) VESA 100mm x 100mm Mounting Panel, Wall, Rack, Stand and Arm... - Page 19 PPC2-Cxxx-ADL Series Panel PC PPC2-CW19-ADL PPC2-C19-ADL PPC2-CW22-ADL LCD Display 18.5” (16:9) 19” (5:4) 21.5” (16:9) Max. Resolution 1920 (W) x 1080 (H) 1280 (W) x 1024 (H) 1920 (W) x 1080 (H) Brightness 400 cd/m² 350 cd/m² 350 cd/m² Contrast Ratio 1000:1 41.66736111 1000:1...
-
Page 20: Table 1-3: Ppc2-Cw19/C19/Cw22-Adl Specifications
PPC2-Cxxx-ADL Series Panel PC Software Programmable Support 1~255 sec. system reset Watchdog Timer Operating Temperature -10ºC ~ 60ºC -10ºC ~ 50ºC (with air flow) Storage Temperature -20ºC ~ 60ºC Humidity 10% ~ 95%@40℃, non-condensing IP Level IP 65 compliant front panel Operating Vibration MIL-STD-810F 514.5C-1 (with SSD) Half-sine wave shock 5G;... -
Page 21: Dimensions
PPC2-Cxxx-ADL Series Panel PC 1.8 Dimensions PPC2-C15-ADL Dimensions Figure 1-5: PPC2-C15-ADL Dimensions (Unit: mm) Page 9... -
Page 22: Ppc2-Cw15-Adl Dimensions
PPC2-Cxxx-ADL Series Panel PC PPC2-CW15-ADL Dimensions Figure 1-6: PPC2-CW15-ADL Dimensions (Unit: mm) Page 10... -
Page 23: Ppc2-C17-Adl Dimensions
PPC2-Cxxx-ADL Series Panel PC PPC2-C17-ADL Dimensions Figure 1-7: PPC2-C17-ADL Dimensions (Unit: mm) Page 11... -
Page 24: Ppc2-C19-Adl Dimensions
PPC2-Cxxx-ADL Series Panel PC PPC2-C19-ADL Dimensions Figure 1-8: PPC2-C19-ADL Dimensions (Unit: mm) Page 12... -
Page 25: Ppc2-Cw19-Adl Dimensions
PPC2-Cxxx-ADL Series Panel PC PPC2-CW19-ADL Dimensions Figure 1-9: PPC2-CW19-ADL Dimensions (Unit: mm) Page 13... -
Page 26: Ppc2-Cw22-Adl Dimensions
PPC2-Cxxx-ADL Series Panel PC PPC2-CW22-ADL Dimensions Figure 1-10: PPC2-CW22-ADL Dimensions (Unit: mm) Page 14... -
Page 27: Unpacking
PPC2-Cxxx-ADL Series Panel PC Chapter Unpacking Page 15... -
Page 28: Unpacking
PPC2-Cxxx-ADL Series Panel PC 2.1 Unpacking To unpack the panel PC, follow the steps below: WARNING! The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the panel PC has been properly installed. This ensures the screen is protected during the installation process. -
Page 29: Packing List
PPC2-Cxxx-ADL Series Panel PC 2.2 Packing List NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the PPC-Cxxx-ADL was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com. -
Page 30: Optional Items
PPC2-Cxxx-ADL Series Panel PC 2.3 Optional Items The following items are optional accessories for the PPC-Cxxx-ADL: PPC2-C15/CW15/C17/C19/CW19/CW22-ADL Item Part No. Description ARM-31-RS VESA 75/100 desk arm Stand STAND-C19-R10 VESA 75/100 easy stand Wall AFLWK-19B Wall mounting kit WIN10-IOTE2019-H-RS Win10 IoT Ent LTSC 2019 MultiLang OEI High End Wi-Fi Kit EMB-WIFI-KIT02I3-R10 2T2R M.2 Wi-Fi module, Wi-Fi 6E &... -
Page 31: Installation
PPC2-Cxxx-ADL Series Panel PC Chapter Installation Page 19... -
Page 32: Anti-Static Precautions
PPC2-Cxxx-ADL Series Panel PC 3.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the maintenance of the PPC-Cxxx- ADL may result in permanent damage to the PPC-Cxxx-ADL and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the power module. -
Page 33: Preinstalled Components
PPC2-Cxxx-ADL Series Panel PC Air Circulation: Make sure there is sufficient air circulation when installing ◼ the PPC-Cxxx-ADL. The PPC-Cxxx-ADL cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the PPC-Cxxx-ADL. Leave at least 5 cm of clearance around the PPC-Cxxx- ADL to prevent overheating. -
Page 34: Removing The Rear Cover
PPC2-Cxxx-ADL Series Panel PC Step 5: Connect the peripheral devices Step 6: Power the system up 3.5 Removing the Rear Cover WARNING: Before any internal installation procedures are carried out on the system, make sure the system is turned off and cooled down for 5 minutes. -
Page 35: Solid-State Drive Installation
PPC2-Cxxx-ADL Series Panel PC 3.6 Solid-State Drive Installation One 2.5” SATA HDD drive can be installed in the PPC-Cxxx-ADL. To install the HDD into the system, please follow the steps below. Step 1: Remove the back cover see Figure 3-1. Step 2: Remove the three screws securing the hard drive bracket to remove the hard drive bracket. -
Page 36: Figure 3-3: Hdd Retention Screws
PPC2-Cxxx-ADL Series Panel PC Figure 3-3: HDD Retention Screws Step 4: Install the HDD and bracket back into the system. See Figure 3-4. Figure 3-4: Install the HDD and Bracket Step 5: Connect the SATA cable. See Figure 3-5. Figure 3-5: SATA Cable Step 6: Re-install the rear cover and secure it with screws. -
Page 37: Dimm Installation (Optional)
PPC2-Cxxx-ADL Series Panel PC 3.7 DIMM Installation (Optional) To install a DIMM, please follow the steps below and refer to Figure 3-7. Step 1: Remove the rear cover. See Section 3.5 above. Step 2: Locate the DIMM slots as shown in Figure 3-6. Figure 3-6: DIMM Slot Locations Step 3: Open the two handles outwards as far as they can. -
Page 38: Installation (Optional)
PPC2-Cxxx-ADL Series Panel PC Step 5: Once aligned, press down until the DIMM is properly seated. Clip the two handles into place. See Figure 3-7. Step 6: To remove a DIMM, push both handles outward. The memory module is ejected by a mechanism in the socket. -
Page 39: Figure 3-9: Press The End Of The M.2 Retaining Clip
PPC2-Cxxx-ADL Series Panel PC Figure 3-9: Press the End of The M.2 Retaining Clip Step 4: Insert M.2 card. The notch at the end of the M.2 card needs to be aligned with the notch of the fixed buckle (Figure 3-10). Figure 3-10: Insert M.2 Card Step 5: Secure the M.2 card. -
Page 40: At/Atx Mode Selection
PPC2-Cxxx-ADL Series Panel PC Figure 3-11: Securing the M.2 Card Step 6: Re-install the rear cover. 3.9 AT/ATX Mode Selection AT and ATX power modes can both be used on the PPC-Cxxx-ADL panel PC. The selection is made through an AT/ATX switch on the I/O interface panel. The system is set to ATX mode by default. -
Page 41: Mounting The System
PPC2-Cxxx-ADL Series Panel PC 3.10 Mounting the System The following sections describe the mounting methods supported by the PPC-Cxxx-ADL. WARNING! When mounting the PPC-Cxxx-ADL panel PC, it is advisable to have more than one person help with the installation to prevent accidental damage to the panel and avoid personal injury. -
Page 42: Figure 3-13: Wall-Mounting Bracket
PPC2-Cxxx-ADL Series Panel PC Figure 3-13: Wall-mounting Bracket Step 6: Insert the four monitor mounting screws provided in the wall mounting kit into the four screw holes on the real panel of the monitor and tighten until the screw shank is secured against the rear panel. Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on the bracket. -
Page 43: Panel And Rack Installation
PPC2-Cxxx-ADL Series Panel PC Figure 3-14: Mount the Chassis Step 9: Secure the panel PC with the wall-mounting kit. To do this, stick the protective cushion to the wall-mounting kit first. Then, put the wall-mounting kit on the top panel of the panel PC. Carefully mark the location of the wall-mounting kit screw holes on the wall. -
Page 44: Figure 3-16: Ppc2-C15-Adl Panel Cutout Dimensions
PPC2-Cxxx-ADL Series Panel PC Step 1: Select the position on the panel to mount the PPC-Cxxx-ADL. Step 2: Cut out a section of the panel that corresponds to the rear panel dimensions of the PPC-Cxxx-ADL. The recommended cutout sizes are shown below. Figure 3-16: PPC2-C15-ADL Panel Cutout Dimensions Figure 3-17: PPC2-CW15-ADL Panel Cutout Dimensions Figure 3-18: PPC2-C17-ADL Panel Cutout Dimensions... -
Page 45: Figure 3-19: Ppc2-C19-Adl Panel Cutout Dimensions
PPC2-Cxxx-ADL Series Panel PC Figure 3-19: PPC2-C19-ADL Panel Cutout Dimensions Figure 3-20: PPC2-CW19-ADL Panel Cutout Dimensions Figure 3-21: PPC2-CW22-ADL Panel Cutout Dimensions Page 33... -
Page 46: Figure 3-22: Machine Mounted To Panel
PPC2-Cxxx-ADL Series Panel PC Step 3: Slide the PPC2-Cxxx-ADL Series through the hole until the aluminum frame is flush against the panel (Figure 3-22). Figure 3-22: Machine mounted to panel Step 4: Insert the panel mount kit into the prefabricated holes along the rear edge of the PPC2-Cxxx-ADL series (Figure 3-23). -
Page 47: Arm Mounting
PPC2-Cxxx-ADL Series Panel PC Figure 3-24: Tighten the Mounting Screws Step 6: Slide the PPC2-Cxxx-ADL series with the attached rack/cabinet bracket into a rack or cabinet (Figure 3-25). Figure 3-25: Install into a Rack Step 7: Once the flat panel PC with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-25). -
Page 48: Figure 3-26: Arm Mounting Retention Screw Holes
PPC2-Cxxx-ADL Series Panel PC The PPC2-Cxxx-ADL Series is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 100 mm interface pad. To mount the PPC2-Cxxx- ADL Series on an arm, please follow the steps below. Step 1: The arm is a separately purchased item. -
Page 49: Stand Mounting
PPC2-Cxxx-ADL Series Panel PC Step 4: Secure the PPC2-Cxxx-ADL Series to the interface pad by inserting four retention screws through the mounting arm interface pad and into the PPC2- Cxxx-ADL Series panel PC. Figure 3-27: Arm Mounting (ARM-11-RS) Stand Mounting To mount the PPC2-Cxxx-ADL Series using the stand mounting kit, please follow the steps below. -
Page 50: Serial Device Connection
PPC2-Cxxx-ADL Series Panel PC Step 2: Align the bracket with the screw holes. Step 3: To secure the bracket to the PPC2-Cxxx-ADL Series, insert the retention screws into the screw holes and tighten them. Figure 3-29: Stand Mounting 3.11 Serial Device Connection The PPC2-Cxxx-ADL Series has RS-232/422/484 and RS-232 ports. -
Page 51: Rs-232/422/485 Serial Port
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 3-2: RS-232 Serial Port Pinouts RS-232/422/485 Serial Port The pinouts of the RS-232/422/485 serial ports are listed in the following table. PIN NO. RS-232 RS-422 RS-485 TXD422- TXD485- TXD422+ TXD485+ RXD422+ RXD422-... -
Page 52: Power-On Procedure
PPC2-Cxxx-ADL Series Panel PC All peripheral devices are connected The system is securely mounted Power-on Procedure To power-on the PPC2-Cxxx-ADL Series please follow the steps below: Step 1: Connect the power source to the power inlet on the bottom panel. Step 2: Press the power switch to power up the system. -
Page 53: Software Installation
PPC2-Cxxx-ADL Series Panel PC location is shown in Figure 3-33. Figure 3-33: Clear CMOS Button Location 3.15 Software Installation All the drivers for the PPC2-Cxxx-ADL Series are available on IEI Resource Download Center (https://download.ieiworld.com). Figure 3-34: IEI Resource Download Center Driver Download To download drivers from IEI Resource Download Center, follow the steps below. - Page 54 PPC2-Cxxx-ADL Series Panel PC Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result. Step 3: Click the driver file name on the page and you will be prompted with the ...
- Page 55 PPC2-Cxxx-ADL Series Panel PC NOTE: To install software from the downloaded ISO image file in Windows 10 or 11, double-click the ISO file to mount it as a virtual drive to view its content. Page 43...
-
Page 56: System Maintenance
PPC2-Cxxx-ADL Series Panel PC Chapter System Maintenance Page 44... -
Page 57: Adl System Maintenance Overview
PPC2-Cxxx-ADL Series Panel PC WARNING: Take Anti-Static precautions whenever maintenance is being carried out on the system components. Failure to take anti-static precautions can cause permanent system damage. For more details on anti-static precautions, please refer to Section 3.1. 4.1 PPC-Cxxx-ADL System Maintenance Overview NOTE: When doing maintenance operations on the system, please follow the instructions in this chapter. -
Page 58: The System Doesn't Boot Up
PPC2-Cxxx-ADL Series Panel PC Step 4: Plug the system into a monitor and check to see if anything appears on the screen. If nothing is displayed, contact an IEI sales representative directly. The System Doesn’t Boot Up If the system doesn’t boot up, please do the following: Step 1: Check the power is turned on. -
Page 59: Component Replacement
PPC2-Cxxx-ADL Series Panel PC 4.3 Component Replacement WARNING! Users are not advised to attempt to repair or replace any internal or external components of the PPC-Cxxx-ADL panel PC. If any other components fail or need replacement, contact the IEI reseller or vendor you purchased the PPC-Cxxx-ADL from or contact an IEI sales representative directly. -
Page 60: Interface Connectors
PPC2-Cxxx-ADL Series Panel PC Chapter Interface Connectors Page 48... -
Page 61: Peripheral Interface Connectors
PPC2-Cxxx-ADL Series Panel PC 5.1 Peripheral Interface Connectors The PPC2-Cxxx-ADL Series panel PC motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 5-1&Figure 5-2, The connector pinouts for these connectors are listed in the following sections. -
Page 62: Internal Peripheral Connectors
PPC2-Cxxx-ADL Series Panel PC 5.2 Internal Peripheral Connectors Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the PPC2-Cxx-ADL Panel PC motherboard. Pinouts of these connectors can be found in the following sections. -
Page 63: Battery Connector (Bat1)
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION PS_ON PWR_OK SB5V +12V +12V +3.3V Table 5-2: ATX Power Source Connector (ATX1) Pinouts Battery Connector (BAT1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V Table 5-3: Battery Connector (BAT1) Pinouts Chassis Intrusion (CHASSIS1) PIN NO. -
Page 64: Cpu Power Connector (Cpu12V1)
PPC2-Cxxx-ADL Series Panel PC SATA_RX5+ SATA_RX5- +V5S +V5S SATA_TX5- +V5S SATA_TX5+ +V5S Table 5-6: Mini SATA Connectors (CN1, CN2) Pinouts CPU Power Connector (CPU12V1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V Table 5-7: CPU Power Connector (CPU12V1) Pinouts Debug Connector (DEBUG_SPI1) PIN NO. -
Page 65: I2C Connector (I2C1)
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_MISO DET_FLASH SPI_CLK SPI_MOSI Table 5-10: EC Flash Connector (EC_SPI1) Pinouts I2C Connector (I2C1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V5S Table 5-11: I2C Connector (I2C1) Pinouts IDPM Slot (IDPM1) PIN NO. -
Page 66: Me Flash Connector (Flash1)
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDP_TX0_DN EDP_BKLT_CTRL EDP_TX0_DP EC_EDP_BKLT_EN EC_EDP_VDD_EN EDP_AUX_DN EDP_HPD_R EDP_AUX_DP PLT_RST_N LVDS_EN +V5S +V5S +V5S +V5S +V12S +V12S +V12S +V12S Table 5-12: IDPM Slot (IDPM1) Pinouts ME Flash Connector (FLASH1) PIN NO. DESCRIPTION Open = Disabled (No override) Default Short = Enabled (OVERIDE) -
Page 67: A-Key Slot (Ngff4)
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_TX_DN3 PCIE_TX_DP3 PCIE_2_RX_DN PCIE_2_RX_DP PCIE_TX_DN2 PCIE_TX_DP2 M_1_SSD_SLP PCIE_1_RX_DN PCIE_1_RX_DP PCIE_TX_DN1 PCIE_TX_DP1 PLT_RST_N SRCCLKREQB_13_N PCIE_CLK_DN13 PCIE_CLK_DP13 Module Key +V3P3S_SSD +V3P3S_SSD +V3P3S_SSD Table 5-14: M.2 M-KEY Slot (NGFF1) Pinouts M.2 A-Key Slot (NGFF4) PIN NO. -
Page 68: Sata 6Gb/S Connector (S_Ata1)
PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION CLKREQ_CNV# CNV_RXN0 BT_LED CNV_RXP0 CLK_CNV_RXN CNV_BRI_RX CLK_CNV_RXP CNV_RGI_TX CNV_RGI_RX PCIE_5_RX_DP CNV_BRI_TX PCIE_5_RX_DN CL_RST# CL_DATA PCIE_TX_DP5 CL_CLK PCIE_TX_DN5 PCIE_CLK_DP16 PCIE_CLK_DN16 SUSCLK PLT_RST_N SRCCLKREQB_15# BT_ON PCH_WAKE_N WLAN_OFF CNV_TXN1 CNV_TXP1 CNV_TXN0 CNV_TXP0 CLK_CNV_TXN +V3.3_M2 CLK_CNV_TXP +V3.3_M2... -
Page 69: Sata Power Connector (Sata_Pwr1)
PPC2-Cxxx-ADL Series Panel PC SATA_TX+ SATA RX+ SATA_TX- Table 5-16 : SATA 6Gb/s Connector (S_ATA1) Pinouts SATA Power Connector (SATA_PWR1) PIN NO. DESCRIPTION Table 5-17: SATA Power Connector (SATA_PWR1) Pinouts Touch Panel Connector (TOUCH_USB1) PIN NO. DESCRIPTION +V5S USB2_DM14_L USB2_DP14_L Table 5-18: Touch Panel Connector (TOUCH_USB1) Pinouts USB 2.0 Connector (USB_CN4) PIN NO. -
Page 70: Vr Power Debug Connector (J1)
PPC2-Cxxx-ADL Series Panel PC VR Power Debug Connector (J1) PIN NO. DESCRIPTION MP2960_SCL MP2960_SDA MP2940_SCL MP2940_SDA Table 5-21: VR Power IC Debug Connector (J1) Pinouts Power Button Connector (JP2) PIN NO. DESCRIPTION Table 5-22: Power Button Connector (JP2) Pinouts HDD LED Connector (JP3) PIN NO. -
Page 71: A Regulatory Compliance
PPC2-Cxxx-ADL Series Panel PC Appendix Regulatory Compliance Page 59... - Page 72 PPC2-Cxxx-ADL Series Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2014/30/EU) ◼ Low-Voltage Directive (2014/35/EU) ◼ RoHS II Directive (2011/65/EU, 2015/863/EU) ◼ If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
- Page 73 PPC2-Cxxx-ADL Series Panel PC Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2014/53/EU. Français [French] IEI Integration Corp déclare que l'appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2014/53/EU. Italiano [Italian] IEI Integration Corp dichiara che questo apparecchio è...
- Page 74 PPC2-Cxxx-ADL Series Panel PC Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU. Slovensky [Slovak] IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EU. Suomi [Finnish] IEI Integration Corp vakuuttaa täten että...
- Page 75 PPC2-Cxxx-ADL Series Panel PC FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and ◼ This device must accept any interference received, including interference ◼...
-
Page 76: B Safety Precautions
PPC2-Cxxx-ADL Series Panel PC Appendix Safety Precautions Page 64... -
Page 77: Safety Precautions
PPC2-Cxxx-ADL Series Panel PC WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the PPC-Cxxx-ADL. B.1.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times. -
Page 78: Anti-Static Precautions
PPC2-Cxxx-ADL Series Panel PC ◼ DO NOT: Drop the device against a hard surface. In a site where the ambient temperature exceeds the rated temperature B.1.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the PPC-Cxxx- ADL may result in permanent damage to the PPC-Cxxx-ADL and severe injury to the user. -
Page 79: Product Disposal
PPC2-Cxxx-ADL Series Panel PC B.1.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method. -
Page 80: Maintenance And Cleaning
PPC2-Cxxx-ADL Series Panel PC WARNING: For safety reasons, turn-off the power and unplug the panel PC before cleaning. If you dropped any material or liquid such as water onto the panel PC when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center. - Page 81 PPC2-Cxxx-ADL Series Panel PC ◼ Vacuum cleaner–Using a vacuum specifically designed for computers is one of the best methods of cleaning the device. Dust and dirt can restrict the airflow in the device and cause its circuitry to corrode. ◼ Cotton swabs–Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas.
-
Page 82: C Watchdog Timer
PPC2-Cxxx-ADL Series Panel PC Appendix Watchdog Timer Page 70... - Page 83 PPC2-Cxxx-ADL Series Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
- Page 84 PPC2-Cxxx-ADL Series Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...
-
Page 85: D Hazardous Materials Disclosure
PPC2-Cxxx-ADL Series Panel PC Appendix Hazardous Materials Disclosure Page 73... -
Page 86: Rohs Ii Directive (2015/863/Eu)
PPC2-Cxxx-ADL Series Panel PC D.1.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU). -
Page 87: China Rohs
PPC2-Cxxx-ADL Series Panel PC D.1.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 75...
