Half-size PCISA CPU Card with 22nm Intel® Atom™ On-board SoC,
VGA, iDP, Dual Intel® PCIe GbE, USB 3.0, PCIe Mini,
SATA, mSATA, COM, Audio and RoHS
PCISA-BT
Quick Installation Guide
Version 1.0
Dec 18, 2015
Package List
PCISA-BT package includes the following items:
1 x PCISA-BT single board computer
1 x SATA cable
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2015 Copyright by IEI Integration Corp.
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology PCISA-BT
Summary of Contents for IEI Technology PCISA-BT
- Page 1 PCISA-BT Quick Installation Guide Version 1.0 Dec 18, 2015 Package List PCISA-BT package includes the following items: 1 x PCISA-BT single board computer 1 x SATA cable 1 x Utility CD 1 x QIG (Quick Installation Guide) ©2015 Copyright by IEI Integration Corp.
-
Page 2: Specifications
Specifications SoC: Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W) Intel® Atom™ E3827 on-board SoC (1.75GHz, dual-core, 1MB cache, TDP=8W) Intel® Atom™ E3826 on-board SoC (1.46GHz, dual-core, 1MB cache, TDP=7W) Intel® Atom™ E3825 on-board SoC (1.33GHz, dual-core, 1MB cache, TDP=6W) Intel®... - Page 3 External I/O Interface: 1 x VGA 2 x RJ-45 1 x USB 2.0 1 x USB 3.0 Internal I/O Interface: 1 x IR 1 x KB/MS (1x6 pin) 1 x LPT (2x13 pin) 4 x USB 2.0 (2x4 pin, P=2.54) 1 x RS-422/485 (1x4 pin, P=2.0) 1 x USB 2.0 (180 degree type A) 2 x RS-232 (2x5 pin, P=2.54)
-
Page 4: Ordering Information
Dimensions: 185mm x 128 mm Weight(GW/ NW): 1000g / 250g Ordering Information PCISA-BT-E38451-R10: Half-size PCISA CPU card supports Intel® Atom™ E3845 (10W) on-board SoC with VGA, iDP, Dual Intel® PCIe GbE, USB 3.0, PCIe Mini, SATA, mSATA, COM, Audio and RoHS PCISA-BT-E38251-R10: Half-size PCISA CPU card supports Intel®... - Page 5 V3.17 NOTE: ISA Limitation of PCISA-BT Due to the limitation of Intel® Bay Trail processors, the PCISA-BT does not support the following features: Bus Master Cycles LPC Memory Mapped Transactions IRQ0, IRQ1, IRQ2, IRQ8, IRQ9, IRQ13, IRQ14 ISA Enable (IE) Bit...
-
Page 6: Jumpers Setting And Connectors
Jumpers setting and connectors LABEL FUNCTION ATXCTL1 AT/ATX Power Mode Setting J_CMOS1 Clear CMOS LVDS Power Mode Setting LVDS Backlight Mode Setting LVDS1 Panel type Selection J_ATX_AT1 AT/ATX Power Mode Setting F_PANEL1 PWR & RST Buttons and indicators VGA1 VGA 15-pin Female Connector IR Connector LAN1, LAN2 RJ45 LAN ports... - Page 7 J_CMOS1: Clear CMOS PIN NO. DESCRIPTION Keep CMOS Setup (default) (Normal Operation) Press button Clear CMOS Setup ATXCTL1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short 1-2 AT Power Mode (default) Short 2-3 ATX Power Mode JP2: LVDS Power Mode Setting PIN NO.
- Page 8 SW1: LVDS panel resolution selection * ON=0, OFF=1; Single=S, Dual=D 4-3-2-1 DESCRIPTION 0000 800x600 18-bit Single (Default) 0001 1024x768 18-bit Single 0010 1024x768 24-bit Single 0011 1280x768 18-bit Single 0100 1280x800 18-bit Single 0101 1280x960 18-bit Single 0110 1280x1024 24-bit Dual 0111 1366x768 18-bit Single 1000...
- Page 9 IR1: IR Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1, LAN2: RJ-45 LAN connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MDI0+ LAN1_MDI2+ LAN1_MDI0- LAN1_MDI2- LAN1_MDI1+ LAN1_MDI3+ LAN1_MDI1- LAN1_MDI3- KB_MS1: Keyboard/Mouse Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Mouse Data Mouse Clock Keyboard Data Keyboard Clock USB3, USB4: Internal USB 2.0 connector...
- Page 10 CN2: M-SATA Card Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# +3.3V 1.5V MSATA_CLK# MSATA _CLK PLTRST_N +3.3V PLTRST_N SATA_RX+ +3.3V SATA_RX- 1.5V SMB_CLK SATA_TX- SMB_DATA SATA_TX+ USB_DATA- USB_DATA+ +3.3V +3.3V +3.3V CLINK_CLK CLINK_DATA 1.5V CLINK_RST# MSATA_DET +3.3V CPU_FAN1: CPU Fan Connector PIN NO.
- Page 11 SYS_FAN1: System Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION FANIO +12V DIO1: Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 CPU12V1: +12V Power Connector PIN NO.
- Page 12 SMBus1: SMBUS connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_DATA SMB_CLK I2C_1: I C Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCH_GP38 PCH_GP39 LPT1: Parallel Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# AUTO FORM FEED # DATA0 ERROR# DATA1 INITIALIZE# DATA2...
- Page 13 CN1: EC Debug Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_STB# EC_EPP_AFD# EC_EPP_PD0 EC_EPP_PD1 EC_EPP_INIT# EC_EPP_PD2 EC_EPP_SLIN# EC_EPP_PD3 EC_EPP_PD4 EC_EPP_PD5 EC_EPP_BUSY EC_EPP_PD6 EC_EPP_KSI5 EC_EPP_PD7 EC_EPP_KSI4 JSPI1: Flash SPI ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +1.8V SPI_CS# SPI_SO SPI_CLK SPI_SI JSPI2: Flash EC ROM Connector...
- Page 14 LVDS1: LVDS Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LVDS_DATA0 LVDS_DATA0# LVDS_DATA1 LVDS_DATA1# LVDS_DATA2 LVDS_DATA2# LVDS_CLK1 LVDS_CLK1# LVDS_DATA3 LVDS_DATA3# LVDS_DATA4 LVDS_DATA4# LVDS_DATA5 LVDS_DATA5# LVDS_DATA6 LVDS_DATA6# LVDS_CLK2 LVDS_CLK2# LVDS_DATA7 LVDS_DATA7# VCC_LCD VCC_LCD VCC_LCD VCC_LCD INV1: Backlight inverter connector PIN NO. DESCRIPTION PIN NO.
- Page 15 DP1: Internal Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE3N AUXP AUXN LANE0P AUX_CTRL_DET_D LANE1P LANE0N LANE1N LANE2P +3.3V LANE3P LANE2N COM1, COM2: RS-232 serial port connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM3: RS-422/485 serial port connector DESCRIPTION DESCRIPTION RXD485# RXD485+ TXD485+...
- Page 16 USB1: USB 3.0 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA+ USB3.0RX- USB3.0RX+ AGND USB3.0 TX+ USB3.0 TX-...
- Page 17 Board Layout: Jumper and Connector Locations (Unit: mm)
