PEMUX-XEW1
MODEL:
PEMUX-XEW1
®
®
Full-Size CPU Card Supports LGA2066 Intel
Xeon
W CPU,
Intel® C422 Chipset, DDR4 RDIMM/LRDIMM, 10 GbE, RS-232,
USB 3.1 Gen1, SATA 6Gb/s, M.2, HD Audio and RoHS
User Manual
Page i
Rev. 1.00 – February 19, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEMUX-XEW1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology PEMUX-XEW1

Summary of Contents for IEI Technology PEMUX-XEW1

  • Page 1 PEMUX-XEW1 MODEL: PEMUX-XEW1 ® ® Full-Size CPU Card Supports LGA2066 Intel Xeon W CPU, Intel® C422 Chipset, DDR4 RDIMM/LRDIMM, 10 GbE, RS-232, USB 3.1 Gen1, SATA 6Gb/s, M.2, HD Audio and RoHS User Manual Page i Rev. 1.00 – February 19, 2019...
  • Page 2 PEMUX-XEW1 Revision Date Version Changes February 19, 2019 1.00 Initial release Page ii...
  • Page 3 PEMUX-XEW1 Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 PEMUX-XEW1 Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................13 3.1 P ..............14 ERIPHERAL NTERFACE ONNECTORS 3.1.1 PEMUX-XEW1 Layout ..................14 3.1.2 Peripheral Interface Connectors ..............15 3.1.3 External Interface Panel Connectors ............... 15 3.2 I ..............16 NTERNAL ERIPHERAL ONNECTORS 3.2.1 +12V Power Connector ................... 16 3.2.2 Audio Kit Connector ..................
  • Page 6 PEMUX-XEW1 3.2.11 Mini-SAS Connectors ..................26 3.2.12 SPI Flash Connector ..................27 3.2.13 SPI Flash Connector, EC ................28 3.2.14 TPM Connector ....................29 3.2.15 USB 3.1 Gen 1 Connector ................30 3.2.16 USB DOM Connector ..................31 3.3 E .........
  • Page 7 PEMUX-XEW1 5.1.5 BIOS Menu Bar ....................53 5.2 M ........................54 5.3 A ....................... 55 DVANCED 5.3.1 Trusted Computing ................... 56 5.3.2 ACPI Settings ....................57 5.3.3 F81216AD Super IO Configuration ..............58 5.3.3.1 Serial Port 1 Configuration ............... 58 5.3.3.2 Serial Port 2 Configuration ...............
  • Page 8 PEMUX-XEW1 D WATCHDOG TIMER ....................96 E HAZARDOUS MATERIALS DISCLOSURE ............99 Page viii...
  • Page 9 List of Figures Figure 1-1: PEMUX-XEW1 ......................2 Figure 1-2: Connectors ........................4 Figure 1-3: PEMUX-XEW1 Dimensions (mm) ................5 Figure 1-4: Data Flow Diagram ...................... 6 Figure 3-1: Peripheral Interface Connectors ................14 Figure 3-2: +12V Power Connector Pinout Location ..............16 Figure 3-3: Audio Connector Location ..................
  • Page 10 PEMUX-XEW1 Figure 4-6: IEI Resource Download Center ................46 Figure 4-7: IEI iMAN Web Address ....................49 Figure 4-8: IEI iMAN Web GUI ...................... 50 Page x...
  • Page 11 PEMUX-XEW1 List of Tables Table 1-1: PEMUX-XEW1 Specifications ..................8 Table 2-1: Packing List ......................... 11 Table 2-2: Optional Items ......................12 Table 3-1: Peripheral Interface Connectors ................15 Table 3-2: External Peripheral Connectors ................15 Table 3-3: +12V Power Connector Pinouts ................16 Table 3-4: Audio Connector Pinouts ..................
  • Page 12 PEMUX-XEW1 BIOS Menus BIOS Menu 1: Main ........................54 BIOS Menu 2: Advanced ......................55 BIOS Menu 3: Trusted Computing ....................56 BIOS Menu 4: ACPI Settings ....................... 57 BIOS Menu 5: F81216AD Super IO Configuration ..............58 BIOS Menu 6: Serial Port 1 Configuration Menu ............... 58 BIOS Menu 7: Serial Port 2 Configuration Menu ...............
  • Page 13 PEMUX-XEW1 BIOS Menu 31: Intel® VT for Directed I/O (VT-d) ............... 87 Page xiii...

  • Page 15: Introduction

    PEMUX-XEW1 Chapter Introduction Page 1...

  • Page 16: Introduction

    PEMUX-XEW1 1.1 Introduction Figure 1-1: PEMUX-XEW1 The PEMUX-XEW1 is a full-size CPU card that can provide up to 56-lane PCIe signal to ® ® the backplane. It accepts a Socket LGA2066 Intel Xeon W processor and supports four 288-pin 2666MHz dual-channel ECC DDR4 RDIMM/LRDIMM modules up to 256 GB.

  • Page 17: Features

    PEMUX-XEW1 1.2 Features The PEMUX-XEW1 motherboard features are listed below:  Full-size CPU card supports up to 56-lane PCIe link to the backplane  Supports PCI Express Generation 3.0 ® ®  LGA2066 Intel Xeon W processor family supported ®...

  • Page 18: Connectors

    PEMUX-XEW1 1.3 Connectors The connectors on the PEMUX-XEW1 are shown in the figure below. Figure 1-2: Connectors Page 4...

  • Page 19: Dimensions

    PEMUX-XEW1 1.4 Dimensions The main dimensions of the PEMUX-XEW1 are shown in the diagram below. Figure 1-3: PEMUX-XEW1 Dimensions (mm) Page 5...

  • Page 20: Data Flow

    PEMUX-XEW1 1.5 Data Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram Page 6...

  • Page 21: Technical Specifications

    PEMUX-XEW1 1.6 Technical Specifications The PEMUX-XEW1 technical specifications are listed below. Specification/Model PEMUX-XEW1 Full-size PEMUX CPU card (12 layers) Form Factor ® ® LGA2066 Intel Xeon W processor series CPU Supported ® Intel C422 Four 288-pin dual-channel ECC DDR4 RDIMMs/LRDIMMs Memory supported (system max.

  • Page 22: Table 1-1: Pemux-Xew1 Specifications

    2400 MHz DDR4 ECC RDIMM, running Windows 10 OS) Operating Temperature -20ºC ~ 40ºC (-4ºF ~ 104ºF) Storage Temperature -30ºC ~ 50ºC (-22ºF ~ 122ºF) Operating Humidity 5% ~ 95% (non-condensing) Physical Specifications 338.58 mm x 150.5 mm Dimensions Table 1-1: PEMUX-XEW1 Specifications Page 8...

  • Page 23: Packing List

    PEMUX-XEW1 Chapter Packing List Page 9...

  • Page 24: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the PEMUX-XEW1 is unpacked, please do the following:  Follow the anti-static guidelines above.

  • Page 25: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the PEMUX-XEW1 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 26: Optional Items

    PEMUX-XEW1 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image SATA power cable (P/N: 32102-000100-200-RS) LGA2011 cooler kit (high-performance compatible, 130 W) (P/N: CF-2011B-R10) IPMI 2.0 adapter card with AST2400 BMC chip...

  • Page 27: Connectors

    PEMUX-XEW1 Chapter Connectors Page 13...

  • Page 28: Peripheral Interface Connectors

    PEMUX-XEW1 3.1 Peripheral Interface Connectors This chapter details all the peripheral interface connectors. 3.1.1 PEMUX-XEW1 Layout The figure below shows all the peripheral interface connectors. Figure 3-1: Peripheral Interface Connectors Page 14...

  • Page 29: Peripheral Interface Connectors

    PEMUX-XEW1 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label +12V power connector 8-pin Molex PSU1 Audio kit connector 10-pin header J_AUDIO1 JDIMMA1, JDIMMB1, DDR4 DIMM sockets 288-pin socket JDIMMC1, JDIMMD1 EC debug connector...

  • Page 30: Internal Peripheral Connectors

    PEMUX-XEW1 3.2 Internal Peripheral Connectors The section describes all of the connectors on the PEMUX-XEW1. 3.2.1 +12V Power Connector CN Label: PSU1 8-pin Molex power connector, p=4.2 mm CN Type: CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 This connector provides power to the CPU.

  • Page 31: Audio Kit Connector

    PEMUX-XEW1 3.2.2 Audio Kit Connector CN Label: J_AUDIO1 10-pin header, p=2.00 mm CN Type: CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 This connector allows connection to an external audio kit. Figure 3-3: Audio Connector Location Description Description...

  • Page 32: Ddr4 Dimm Sockets

    PEMUX-XEW1 3.2.3 DDR4 DIMM Sockets CN Label: JDIMMA1, JDIMMB1, JDIMMC1, JDIMMD1 288-pin DDR4 DIMM socket CN Type: CN Location: See Figure 3-4 The DIMM sockets are for DDR4 DIMM memory modules. Figure 3-4: DDR4 DIMM Socket Locations 3.2.4 EC Debug Connector...

  • Page 33: Fan Connector (Cpu)

    PEMUX-XEW1 Description Description KSI0 KSO9 KSO0 KSO10 KSO1 KSO12 KSO2 KSI1 KSO3 KSO11 KSO4 KSI2 KSO5 KSI3 KSO6 KSO7 KSO8 Table 3-5: EC Debug Connector Pinouts 3.2.5 Fan Connector (CPU) CN Label: CPU_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location:...

  • Page 34: Fan Connectors (System)

    PEMUX-XEW1 Description +12V FANIO Table 3-6: CPU Fan Connector Pinouts 3.2.6 Fan Connectors (System) CN Label: SYS_FAN1, SYS_FAN2 4-pin wafer, p=2.54 mm CN Type: CN Location: See Figure 3-7 CN Pinouts: See Table 3-7 The fan connector attaches to a system cooling fan.

  • Page 35: Front Panel Connector

    PEMUX-XEW1 3.2.7 Front Panel Connector CN Label: F_PANEL1 14-pin header, p=2.54 mm CN Type: CN Location: See Figure 3-8 CN Pinouts: See Table 3-8 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 36: Iris-2400 Module Slot

    Figure 3-9: iRIS-2400 Module Slot Location WARNING: The iRIS-2400 module slot is designed to install the iRIS-2400 module only. DO NOT install other modules into the iRIS module slot. Doing so may cause damage to the PEMUX-XEW1. 3.2.9 M.2 2280 Slot, M-Key CN Label: M2_M1 CN Type: M.2 2280 M-key slot...

  • Page 37: Figure 3-10: M.2 2280 Slot Location

    PEMUX-XEW1 Figure 3-10: M.2 2280 Slot Location Description Description +3.3V +3.3V PCIE_RXN3 PCIE_RXP3 DAS/DSS# PCIE_TXN3 +3.3V PCIE_TXP3 +3.3V +3.3V PCIE_RXN2 +3.3V PCIE_RXP2 PCIE_TXN2 PCIE_TXP2 PCIE_RXN1 PCIE_RXP1 PCIE_TXN1 PCIE_TXP1 DEVSLP PCIE_RXN0 Page 23...

  • Page 38: Serial Ports

    PEMUX-XEW1 Description Description PCIE_RXP0 PCIE_TXN0 PCIE_TXP0 PERST# CLKREQ# REFCLKN PEWAKE REFCLKP Notch Notch Notch Notch Notch Notch Notch Notch SUSCLK PEDET +3.3V +3.3V +3.3V Table 3-9: M.2 2280 Connector Pinouts 3.2.10 RS-232 Serial Ports CN Label: COM1, COM2 CN Type: 9-pin wafer, p=1.25 mm...

  • Page 39: Figure 3-11: Rs-232 Serial Port Locations

    PEMUX-XEW1 Figure 3-11: RS-232 Serial Port Locations Description Description Table 3-10: RS-232 Serial Port Pinouts Page 25...

  • Page 40: Mini-Sas Connectors

    PEMUX-XEW1 3.2.11 Mini-SAS Connectors CN Label: MINI_SAS1, MINI_SAS2 36-pin Mini-SAS connector CN Type: CN Location: See Figure 3-12 Each Mini-SAS connector can support four SATA 6Gb/s drives. Figure 3-12: Mini-SAS Connector Locations Page 26...

  • Page 41: Spi Flash Connector

    PEMUX-XEW1 3.2.12 SPI Flash Connector CN Label: JSPI1 6-pin wafer, p=1.25 mm CN Type: CN Location: See Figure 3-13 CN Pinouts: See Table 3-11 The SPI flash connector is used to flash the SPI ROM. Figure 3-13: SPI Flash Connector Location Description +3.3V...

  • Page 42: Spi Flash Connector, Ec

    PEMUX-XEW1 3.2.13 SPI Flash Connector, EC CN Label: EC_SPI1 6-pin wafer, p=1.25 mm CN Type: CN Location: See Figure 3-14 CN Pinouts: See Table 3-12 The SPI flash connector is used to flash the EC ROM. Figure 3-14: SPI EC Flash Connector Location Description +3.3V...

  • Page 43: Tpm Connector

    PEMUX-XEW1 3.2.14 TPM Connector CN Label: TPM1 20-pin header, p=2.54 mm CN Type: CN Location: See Figure 3-15 CN Pinouts: See Table 3-13 The TPM connector connects to a TPM module. Figure 3-15: TPM Connector Location Description Description LCLK LFRAME#...

  • Page 44: Usb 3.1 Gen 1 Connector

    PEMUX-XEW1 3.2.15 USB 3.1 Gen 1 Connector CN Label: USB3-1 19-pin box header, p=2.00 mm CN Type: CN Location: See Figure 3-16 CN Pinouts: See Table 3-14 The USB 3.1 Gen 1 connector connects to USB 3.1 devices. This connector provides two USB 3.1 Gen 1 ports.

  • Page 45: Usb Dom Connector

    PEMUX-XEW1 3.2.16 USB DOM Connector CN Label: USB_DOM1 8-pin header, p=2.54 mm CN Type: CN Location: See Figure 3-17 CN Pinouts: See Table 3-15 The USB DOM connector supports one USB DOM device. Figure 3-17: USB DOM Connector Location Description...

  • Page 46: External Peripheral Interface Connector Panel

    PEMUX-XEW1 3.3 External Peripheral Interface Connector Panel The figure below shows the external peripheral interface connector (EPIC) panel. The EPIC panel consists of the following: Figure 3-18: External Peripheral Interface Connector 3.3.1 10GbE LAN Connector CN Label: LAN_CN1 CN Type:...

  • Page 47: Usb 2.0 And Gbe Combo Connector

    PEMUX-XEW1 Figure 3-19: 10GbE LAN Connector 3.3.2 USB 2.0 and GbE Combo Connector CN Label: LAN_USB1 CN Type: USB Type-A, RJ-45 CN Location: See Figure 3-18 CN Pinouts: See Table 3-17 and Table 3-18 The USB connector can be connected to a USB device.

  • Page 48: Usb 3.1 Gen 1 Connectors

    CN Label: USB_CON1 CN Type: USB 3.1 Gen 1 See Figure 3-18 CN Location: CN Pinouts: See Table 3-20 There are four external USB 3.1 Gen 1 (5 Gb/s) connectors on the PEMUX-XEW1. Description Description VBUS STDA_SSRX_N STDA_SSRX_P GND_DRAIN STDA_SSTX_N STDA_SSTX_P Table 3-20: USB 3.1 Gen 1 Port Pinouts...

  • Page 49: Ipmi Vga Connector

    PEMUX-XEW1 3.3.4 IPMI VGA Connector CN Label: VGA1 15-pin VGA CN Type: CN Location: See Figure 3-18 CN Pinouts: See Table 3-21 With the iRIS-2400 IPMI module installed, the 15-pin VGA connector can connect to a monitor that accepts a standard VGA input.

  • Page 50: Installation

    PEMUX-XEW1 Chapter Installation Page 36...

  • Page 51: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PEMUX-XEW1. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the PEMUX-XEW1 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 52  Turn all power to the PEMUX-XEW1 off: When working with the PEMUX-XEW1, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the PEMUX-XEW1, DO NOT: ...

  • Page 53: Socket Lga2066 Cpu Installation

    PEMUX-XEW1 4.3 Socket LGA2066 CPU Installation WARNING: CPUs are expensive and sensitive components. When installing the CPU please be careful not to damage it in anyway. Make sure the CPU is installed properly and ensure the correct cooling kit is properly installed.
  • Page 54 PEMUX-XEW1 WARNING: Never touch the socket contacts any time when the contacts are exposed as it could cause damage. DO NOT touch the pins at the bottom of the CPU. When handling the CPU, only hold it on the sides.

  • Page 55: Socket Lga2066 Cooling Kit Installation

    PEMUX-XEW1 4.4 Socket LGA2066 Cooling Kit Installation WARNING: DO NOT attempt to install a push-pin cooling fan. The pre-installed support bracket prevents the board from bending and is ONLY compatible with captive screw type cooling fans. The cooling kit can be bought from IEI. The cooling kit has a heat sink and fan.

  • Page 56: Dimm Installation

    PEMUX-XEW1 Step 4: Connect the cooling kit fan cable to the CPU fan connector on the PEMUX-XEW1. Carefully route the cable and avoid heat generating chips and blades.Step 0: 4.5 DIMM Installation To install a DIMM, please follow the steps below and refer to Figure 4-1.

  • Page 57: Iris-2400 Module Installation (Optional)

    To install the iRIS-2400 module, please follow the steps below and refer to Figure 4-2. Figure 4-2: iRIS-2400 Module Installation Step 1: Locate the IPMI module slot. Place the PEMUX-XEW1 on an anti-static pad. Step 2: Align the iRIS-2400 module with the iRIS module slot. Align the notch on the module with the notch on the iRIS module slot.

  • Page 58: System Configuration

    PEMUX-XEW1 Step 3: Insert the iRIS-2400 module. Push the module in at a 20º angle (Figure 4-2). Step 4: Seat the iRIS-2400 module. Gently push downwards and the arms clip into place (Figure 4-2). Step 0: 4.7 System Configuration The system configuration should be performed before installation.

  • Page 59: Load Default Button

    PEMUX-XEW1 4.7.2 Load Default Button To load system default, press the load default button (J_LOAD1). The load default button location is shown below. Figure 4-4: Load Default Button Location 4.7.3 Flash Descriptor Security Override Jumper The flash descriptor security override jumper (J_FLASH1) allows to enable or disable the ME firmware update.

  • Page 60: Software Installation

    0: 4.8 Software Installation All the drivers for the PEMUX-XEW1 are available on IEI Resource Download Center (https://download.ieiworld.com). Type PEMUX-XEW1 and press Enter to find all the relevant software, utilities, and documentation. Figure 4-6: IEI Resource Download Center...

  • Page 61: Driver Download

    4.8.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com. Type PEMUX-XEW1 and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.

  • Page 62: Ipmi Setup Procedure

    The PEMUX-XEW1 features Intelligent Platform Management Interface (IPMI) that helps lower the overall costs of server management by enabling users to maximize IT resources, save time and manage multiple systems. The PEMUX-XEW1 supports IPMI 2.0 through the optional iRIS-2400 module. Follow the steps below to setup IPMI.

  • Page 63: Using The Iei Iman Web Gui

    IP address, follow the steps below: a. Copy the Ipmitool.exe file to a bootable USB flash drive. b. Insert the USB flash drive to the PEMUX-XEW1 c. The PEMUX-XEW1 boots from the USB flash drive d. Enter the following command: ipmitool 20 30 02 01 03 00 00 (there is a space between each two-digit number) e.
  • Page 64 Figure 4-8: IEI iMAN Web GUI NOTE: To understand how to use the IEI iMAN Web GUI, please refer to the iRIS-2400 Web GUI user manual in the utility CD came with the PEMUX-XEW1. The user manual describes each function in detail. Page 50...

  • Page 65: Bios

    PEMUX-XEW1 Chapter BIOS Page 51...

  • Page 66: Introduction

    PEMUX-XEW1 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 67: Getting Help

    PEMUX-XEW1 Function Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option Page...

  • Page 68: Main

    PEMUX-XEW1 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main...

  • Page 69: Advanced

    PEMUX-XEW1 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 70: Trusted Computing

    PEMUX-XEW1  Case Open Detection [Disabled] Use the Case Open Detection option to enable or disable the case open beep function.  Disable the case open beep function Disabled EFAULT  Enable the case open beep function Enabled 5.3.1 Trusted Computing Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM).

  • Page 71: Acpi Settings

    PEMUX-XEW1 5.3.2 ACPI Settings The ACPI Settings menu (BIOS Menu 4) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced ACPI Settings Select ACPI sleep state the system will enter...

  • Page 72: F81216Ad Super Io Configuration

    PEMUX-XEW1 5.3.3 F81216AD Super IO Configuration Use the F81216AD Super IO Configuration menu (BIOS Menu 5) to set or change the configurations for the parallel ports and serial ports. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced...

  • Page 73: Serial Port 2 Configuration

    PEMUX-XEW1  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disable the serial port Disabled  Enable the serial port Enabled EFAULT 5.3.3.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 7) to configure the serial port 2.

  • Page 74: Iwdd H/W Monitor

    PEMUX-XEW1 5.3.4 iWDD H/W Monitor The iWDD H/W Monitor menu (BIOS Menu 8) contains the fan configuration submenu, and displays the system temperature and CPU fan speed. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced PC Health Status...

  • Page 75: Smart Fan Mode Configuration

    PEMUX-XEW1 +3.3V PVCCIN PVCCIO 5.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 9) to configure the CPU/system fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced Smart Fan Mode Configuration...
  • Page 76 PEMUX-XEW1  Auto mode fan start temperature If the CPU temperature is between fan off and fan start, the fan speed change to fan start PWM. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.

  • Page 77: Rtc Wake Settings

    PEMUX-XEW1 5.3.5 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 10) enables the system to wake at the specified time. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event.

  • Page 78: Serial Port Console Redirection

    PEMUX-XEW1 Wake up minute Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. 5.3.6 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 11) allows the console redirection options to be configured.
  • Page 79 PEMUX-XEW1  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled the console redirection function Disabled EFAULT  Enabled the console redirection function Enabled The following options are available in the Console Redirection Settings submenu when the Console Redirection option is enabled.
  • Page 80 PEMUX-XEW1  Parity [None] Use the Parity option to specify the parity bit that can be sent with the data bits for detecting the transmission errors.  None No parity bit is sent with the data bits. EFAULT  The parity bit is 0 if the number of ones in the data Even bits is even.

  • Page 81: Legacy Console Redirection Settings

    PEMUX-XEW1 5.3.6.1 Legacy Console Redirection Settings Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced Legacy Serial Redirection Port [COM1] Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages. --------------------- : Select Screen ↑...

  • Page 82: Usb Configuration

    PEMUX-XEW1 5.3.7 USB Configuration Use the USB Configuration menu (BIOS Menu 13) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option...

  • Page 83: Iei Feature

    PEMUX-XEW1 5.3.8 iEi Feature Use the iEi Feature menu (BIOS Menu 14) to configure One Key Recovery function. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced iEi Feature Auto Recovery Function Reboot and recover Auto Recovery Function...

  • Page 84: Chipset

    PEMUX-XEW1 5.4 Chipset Use the Chipset menu (BIOS Menu 15) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 85: Pch-Io Configuration

    PEMUX-XEW1 5.4.1 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 16) to configure the PCH parameters. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset PCH-IO Configuration PCI Express Configuration settings > PCI Express Configuration > SATA And RST Configuration --------------------- : Select Screen...

  • Page 86: Pci Express Configuration

    PEMUX-XEW1 5.4.1.1 PCI Express Configuration Use the PCI Express Configuration menu (BIOS Menu 17) to configure the PCI Express slots. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset PCI Express Configuration PCIEX4_1 Settings. > PCIEX4_1 Slot ---------------------- : Select Screen...
  • Page 87 PEMUX-XEW1  PCIe Speed [Auto] Use this option to select the support type of the PCI Express slots. The following options are available:  Auto Default  Gen1  Gen2  Gen3  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to enable or disable detecting if a non-compliance PCI Express device is connected to the PCI Express slot.

  • Page 88: Sata And Rst Configuration

    PEMUX-XEW1 5.4.1.2 SATA And RST Configuration Use the SATA And RST Configuration menu (BIOS Menu 19) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
  • Page 89 PEMUX-XEW1  SATA Mode Selection [AHCI] Use the SATA Mode Selection option to determine how the SATA devices operate.  AHCI Configures SATA devices as AHCI device. EFAULT  RAID Configures SATA devices as RAID device.  Hot Plug [Enabled] Use the Hot Plug option to enable or disable the hot plug function.

  • Page 90: Hd Audio Configuration

    PEMUX-XEW1 5.4.1.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 20) to configure the PCH Azalia settings. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset HD Audio Configuration Control Detection of the HD-Audio device.

  • Page 91: Security

    PEMUX-XEW1 5.5 Security Use the Security menu (BIOS Menu 21) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Server Mgmt > Password Description Set Administrator Password If ONLY the Administrator’s password is set,...

  • Page 92: Boot

    PEMUX-XEW1 5.6 Boot Use the Boot menu (BIOS Menu 22) to configure system boot options. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Server Mgmt > Boot Configuration Select the keyboard...
  • Page 93 PEMUX-XEW1  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  OEM Logo displayed instead of POST messages Enabled EFAULT  UEFI Boot [Disabled] Use the UEFI Boot option to enable or disable to boot from the UEFI devices.

  • Page 94: Save & Exit

    PEMUX-XEW1 5.7 Save & Exit Use the Safe & Exit menu (BIOS Menu 23) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset...

  • Page 95: Server Management

    PEMUX-XEW1 5.8 Server Management Use the Server Management menu (BIOS Menu 24) to display the server management status and change the settings. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & >...

  • Page 96: Bios Menu 25: System Event Log

    PEMUX-XEW1 Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Server Mgmt Enabling/Disabling Options Change this to enable or SEL Components [Enabled] disable all features of System Event Logging Erase Settings during boot. Erase SEL [No] When SEL is Full...

  • Page 97: Bmc Network Configuration

    PEMUX-XEW1 5.8.2 BMC Network Configuration Use the BMC Network Configuration menu (BIOS Menu 26) to configure the BMC network parameters. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Server Mgmt BMC network configuration Select to configure LAN channel parameters...

  • Page 98: Socket Configuration

    PEMUX-XEW1  Static Manually sets network parameters. If this option is selected, the following items will be configurable: *Station IP address *Subnet mask *Station MAC address *Router IP address *Router MAC address  DynamicBmcDhcp Obtains BMC network parameters by BMC dynamically.

  • Page 99: Processor Configuration

    PEMUX-XEW1 5.9.1 Processor Configuration Use the Processor Configuration menu (BIOS Menu 28) to view detailed CPU specifications or enable the Intel Virtualization Technology. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. > Socket Configuration Processor Configuration Enables the Vanderpool...

  • Page 100: Iio Configuration

    PEMUX-XEW1  VMX [Disable] Use the VMX option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.  Disable Disables Intel Virtualization Technology.

  • Page 101: Socket0 Configuration

    PEMUX-XEW1 5.9.2.1 Socket0 Configuration Use the Socket0 Configuration menu (BIOS Menu 30) to view the PCIe socket information. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. > Socket Configuration IOU0 (IIO PCIe Br1) [x8x8] IOU1 (IIO PCIe Br2)
  • Page 102 PEMUX-XEW1  Intel® VT for Directed I/O (VT-d) [Disable] Use the Intel® VT for Directed I/O (VT-d) option to enable or disable VT-d capability.  Enables VT-d capability. Enable  Disables VT-d capability. Disable EFAULT Page 88...

  • Page 103: A Regulatory Compliance

    PEMUX-XEW1 Appendix Regulatory Compliance Page 89...
  • Page 104 PEMUX-XEW1 DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ...

  • Page 105: B Product Disposal

    PEMUX-XEW1 Appendix Product Disposal Page 91...
  • Page 106 PEMUX-XEW1 CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 107: Cbios Options

    PEMUX-XEW1 Appendix BIOS Options Page 93...
  • Page 108 PEMUX-XEW1 Below is a list of BIOS configuration options in the BIOS chapter. System Date [xx/xx/xx] ......................54 System Time [xx:xx:xx] ....................... 54 Restore AC Power Loss [Last State] ................. 55 Case Open Detection [Disabled] ..................56 Security Device Support [Disable] ..................56 ACPI Sleep State [S3 (Suspend to RAM)] ................
  • Page 109 PEMUX-XEW1 Quiet Boot [Enabled] ......................79 UEFI Boot [Disabled] ......................79 Launch PXE OpROM [Disabled] ..................79 Option ROM Messages [Force BIOS] ................. 79 Save Changes and Reset ....................80 Discard Changes and Reset ....................80 Restore Defaults ........................80 Save as User Defaults ......................
  • Page 110 PEMUX-XEW1 Appendix Watchdog Timer Page 96...
  • Page 111 PEMUX-XEW1 NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 112 PEMUX-XEW1 NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over?
  • Page 113 PEMUX-XEW1 Appendix Hazardous Materials Disclosure Page 99...
  • Page 114 PEMUX-XEW1 The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 115 PEMUX-XEW1 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...

Table of Contents
