  • Page 1 PCISA-LX CPU Card...
  • Page 2 PCISA-LX CPU Card REVISION HISTORY Model Name PCISA-LX CPU Card Revision Number Description Date of Issue Initial release December 2006 COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 3: Table Of Contents

    VERVIEW 1.1.1 PCISA-LX Applications..................16 1.1.2 PCISA-LX Benefits................... 16 1.1.3 PCISA-LX Features..................16 1.2 PCISA-LX O .................... 17 VERVIEW 1.2.1 PCISA-LX Connectors ..................18 1.2.2 Technical Specifications................... 19 DETAILED SPECIFICATIONS ................21 2.1 O ....................... 22 VERVIEW 2.2 C IEI B ................
  • Page 4 2.19.2 Optional Accessory Items................36 CONNECTORS AND JUMPERS ................. 37 3.1 P ..............38 ERIPHERAL NTERFACE ONNECTORS 3.1.1 PCISA-LX Layout..................... 38 3.1.2 Peripheral Interface Connectors ..............39 3.1.3 External Peripheral Interface Connectors............40 3.1.4 On-board Jumpers ................... 41 3.2 I ..............41 NTERNAL...
  • Page 5 ................76 NSTALLATION ONSIDERATIONS 4.2.1 Installation Notices ..................76 4.3 U ......................77 NPACKING 4.3.1 Unpacking Precautions..................77 4.3.2 Checklist......................78 4.4 PCISA-LX CPU C ..............78 NSTALLATION 4.5 P ..................79 REINSTALLED OMPONENT 4.6 C ..................79 OMPONENTS TO NSTALL 4.7 DIMM M...
  • Page 6 PCISA-LX CPU Card 5.1 I ......................92 NTRODUCTION 5.1.1 Starting Setup....................92 5.1.2 Using Setup ...................... 92 5.1.3 Getting Help..................... 93 5.1.4 Unable to Reboot After Configuration Changes..........93 5.1.5 Main BIOS Menu ..................... 93 5.2 S CMOS F .................. 96...
  • Page 7 Figure 3-20: TFT LCD LVDS Connector Location ............64 Figure 3-21: TFT LCD TTL Connector Location ............66 Figure 3-22: USB Connector Location ..............68 Figure 3-23: PCISA-LX External Peripheral Interface Connector Panel ....69 Figure 3-24: RJ-45 Ethernet Connector ..............71 Figure 3-25: Mini-DIN 6 PS/2 Connector ..............72...
  • Page 8 PCISA-LX CPU Card Figure 4-1: Installing the DIMM Module ..............80 Figure 4-2: Connection of IDE Connector ..............82 Figure 4-3: Jumper Locations..................85 ® Figure 4-4: CompactFlash Card Installation ............89 Figure 6-1: AMD LX/GX CD Main Menu ..............139 Figure 6-2: AMD LX/GX CD Driver Menu..............140 Figure 6-3: Access Windows Control Panel............
  • Page 9 PCISA-LX CPU Card Figure 6-30: InstallShield Wizard Complete Screen ..........166 Figure 6-31: Access Windows Control Panel............167 Figure 6-32: Double Click the System Icon ............168 Figure 6-33: Double Click the Device Manager Tab..........169 Figure 6-34: Device Manager List ................170 Figure 6-35: Search for Suitable Driver..............
  • Page 10 PCISA-LX CPU Card List of Tables Table 1-1: Technical Specifications ................20 Table 2-1: Geode LX Graphics Processor Features ..........27 Table 2-2: Power Consumption .................35 Table 3-1: Peripheral Interface Connectors..............40 Table 3-2: External Peripheral Interface Connectors ..........40 Table 3-3: On-board Jumpers ..................41 Table 3-4: AT Power Connector Pinouts ..............42...
  • Page 11 PCISA-LX CPU Card Table 3-27: RJ-45 Ethernet Connector LEDs............71 Table 3-28: Mini-DIN 6 PS/2 Connector ..............72 Table 3-29: USB Port Pinouts ..................73 Table 3-30: VGA Connector Pinouts .................74 Table 4-1: IEI Provided Cables...................81 Table 4-2: AT Power Select Jumper Settings............86 Table 4-3: COM2 RS-/422/485 Select Settings............86...
  • Page 12 PCISA-LX CPU Card List of BIOS Menus BIOS Menu 1: AwardBIOS CMOS Setup Utility ............94 BIOS Menu 2: Standard CMOS Features ..............96 BIOS Menu 3: IDE Primary Master................99 BIOS Menu 4: Advanced BIOS Features..............102 BIOS Menu 5: Advanced Chipset Features ............110 BIOS Menu 6: Flat Panel Configuration ..............
  • Page 13 PCISA-LX CPU Card Glossary AC ’97 Audio Codec 97 Hard Disk Drive ACPI Advanced Configuration and Integrated Data Electronics Power Interface Input/Output Advanced Power Management ICH4 I/O Controller Hub 4 ARMD ATAPI Removable Media Device Cache Level 1 Cache ASKIR...
  • Page 14 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 14 IEI ® Technology, Corp.

  • Page 15: Introduction

    PCISA -LX CPU Card Chapter Introduction Page 15...

  • Page 16: Pcisa-Lx Cpu Card Overview

    PCISA-LX CPU Card 1.1 PCISA-LX CPU Card Overview The PCISA form factor PCISA-LX is fully equipped with advanced multi-mode I/Os. The PCISA-LX is designed for system manufacturers, integrators, and VARs that want performance, reliability, and quality at a reasonable price. The PCISA-LX is equipped with an on-board low-power consumption and high performance AMD Geode™...

  • Page 17: Pcisa-Lx Overview

    PCISA -LX CPU Card Comes with two high performance 10/100MB Ethernet controllers Supports two SATA channels with transfer rates up to 150Mb/s 1.2 PCISA-LX Overview Figure 1-1: PCISA-LX Overview Figure 1-2: PCISA-LX Solder Side Overview Page 17...

  • Page 18: Pcisa-Lx Connectors

    1 x Suspend power and PSON# signal connector 1 x System fan connector 2 x SATA connectors 2 x USB connectors The PCISA-LX has the following external peripheral interface connectors: 2 x Ethernet connectors 1 x PS/2 keyboard/mouse connector 1 x USB connector...

  • Page 19: Technical Specifications

    The location of these connectors on the CPU card can be seen in Figure 1-1. These connectors are fully described in Chapter 3. 1.2.2 Technical Specifications PCISA-LX technical specifications are listed in Table 1-1. Detailed descriptions of each specification can be found in Chapter 2. SPECIFICATION...

  • Page 20: Table 1-1: Technical Specifications

    PCISA-LX CPU Card SPECIFICATION DESCRIPTION Watchdog Timer Software programmable supports 1~255 sec. system reset Serial ATA (SATA) Two SATA channels with 150Mb/s transfer rates Supports RAID 0, 1 with ALI M5283 Floppy Disk Drive (FDD) Supports one FDD ® Compact Flash...

  • Page 21: Detailed Specifications

    PCISA -LX CPU Card Chapter Detailed Specifications Page 21...

  • Page 22: Overview

    This chapter describes the specifications and onboard features of the PCISA-LX CPU card in detail. 2.2 Compatible IEI Backplanes The PCISA-LX CPU card is compatible with all IEI PCI backplanes. For more information on these backplanes, please visit the IEI website or contact your CPU card reseller or vendor.

  • Page 23: System Chipset

    Wakeup on SMI/INTR 2.5 System Chipset The PCISA-LX CPU card has an AMD Geode™ CS5536 chipset installed. The AMD Geode™ CS5536 is a companion device for the AMD Geode™ LX 800 to create a high-performance, low-power x86 solution for embedded applications.
  • Page 24 PCISA-LX CPU Card 3 host ports 1 host/device Audio Codec 97 (AC97) Controller AC97 specification v2.3 compliant interface to multiple audio codecs: Serial In, Serial Out, Sync Out, Bit Clock In Legacy “PC Beep” support Diverse Device 82xx Legacy Devices...

  • Page 25: Data Flow

    PCISA -LX CPU Card 2.5.1 Data Flow Figure 2-1 shows the data flow between the system chipset, the CPU and other I/O interfaces that can connect to the PCISA-LX CPU card. Figure 2-1: Data Flow Block Diagram Page 25...

  • Page 26: Graphics Support

    PCISA-LX CPU Card 2.6 Graphics Support Table 2-1 lists the PCISA-LX graphics processor features. Feature AMD Geode™ LX Processor Color Depth 8, 16, 32 bpp (A) RGB 4 and 8-bit indexed ROPs 256 (2-src, dest and pattern) BLT Buffers FIFOs in Graphics Processor...

  • Page 27: Memory Support

    PCISA -LX CPU Card Feature AMD Geode™ LX Processor Variable Source Stride Variable Destination Stride Destination Write Bursting Selectable BLT Direction Vertical and Horizontal Yes (constant α, α/pix, or sep. α channel) Alpha BLT VGA Support Decodes VGA Register Pipeline Depth Unlimited Accelerated Rotation BLT 8, 16, 32 bpp...

  • Page 28: Super I/O

    PCISA-LX CPU Card 2.9 Super I/O General Meet LPC Spec. 1.01 Supports LDRQ#(LPC DMA), SERIRQ (Serial IRQ) Integrated Hardware Monitor functions Compliant with Microsoft® PC2000/PC2001 Hardware Design Guide Supports DPM (Device Power Management), ACPI Programmable configuration settings Single 24 or 48 MHz clock input It is 3.3V level but 5V tolerance support...
  • Page 29 PCISA -LX CPU Card • 5, 6, 7 or 8-bit characters • Even, odd or no parity bit generation/detection • 1, 1.5 or 2 stop bits generation Internal diagnostic capabilities: • Loop-back controls for communications link fault isolation • Break, parity, overrun, framing error simulation Programmable baud rate generator allows division of 1.8461 MHz and 24 MHz by 1 to (216-1) Maximum baud rate up to 921k bps for 14.769 MHz and 1.5M bps for 24...
  • Page 30 PCISA-LX CPU Card Supports binary and BCD arithmetic 6 MHz, 8 MHz, 12 MHz, or 16 MHz operating frequency Serial Flash ROM Interface Supports up to 8M bits flash ROM General Purpose I/O Ports 48 programmable general purpose I/O ports...

  • Page 31: Ethernet

    PCISA -LX CPU Card 2.10 Ethernet The Realtek RTL8100C is a single-chip Fast Ethernet controller. It is enhanced with an ACPI (Advanced Configuration Power Interface) management function for PCI in order to provide efficient power management for advanced operating systems with OSPM (Operating System Directed Power Management).

  • Page 32: Drive Interfaces

    2 x IDE devices 1 x FDD 2.11.1 SATA Drives The PCISA-LX supports two, first generation SATA drives with transfer rates of up to 150Mb/s. 2.11.2 IDE HDD Interfaces The PCISA-LX system chipset IDE controller supports up to two HDDs with the following...

  • Page 33: Audio Codec

    PCISA -LX CPU Card 2.13 Audio Codec The PCISA-LX has an integrated REALTEK ALC203 CODEC. The ALC203 is a 20-bit DAC and 18-bit ADC full-duplex AC'97 2.3 compatible stereo audio CODEC designed for PC multimedia systems, including host/soft audio, and AMR/CNR based designs. ALC203 features are listed below.

  • Page 34: Real Time Clock

    2.14 Real Time Clock 256-byte battery backed CMOS RAM 2.15 System Monitoring The PCISA-LX CPU card is capable of self-monitoring various aspects of its operating status including: CPU, chipset, and battery voltage, +3.3V, +5V, and +12V CPU and board temperatures (by the corresponding embedded sensors) Page 34 IEI ®...

  • Page 35: Bios

    PCISA -LX CPU Card 2.16 BIOS The PCISA-LX uses a licensed copy of Phoenix Award BIOS. The features of the flash BIOS used are listed below: SMIBIOS (DMI) compliant Console redirection function support PXE (Pre-Boot Execution Environment) support USB booting support 2.17 Operating Temperature and Temperature Control...

  • Page 36: Packaged Contents And Optional Accessory Items

    PCISA-LX CPU Card 2.19 Packaged Contents and Optional Accessory Items 2.19.1 Package Contents When you unpack the PCISA-LX CPU card, you should find the following components. 1 x PCISA-LX single board computer 1 x Mini jumper pack 1 x ATA66/100 flat cable...

  • Page 37: Connectors And Jumpers

    PCISA -LX CPU Card Chapter Connectors and Jumpers Page 37...

  • Page 38: Peripheral Interface Connectors

    PCISA-LX CPU Card 3.1 Peripheral Interface Connectors Section 3.1.1 shows peripheral interface connector locations. Section 3.1.2 lists all the peripheral interface connectors seen in Section 3.1.1. 3.1.1 PCISA-LX Layout Figure 3-1 shows the on-board peripheral connectors and on-board jumpers. Figure 3-1: Connector and Jumper Locations Page 38 IEI ®...

  • Page 39: Peripheral Interface Connectors

    PCISA -LX CPU Card 3.1.2 Peripheral Interface Connectors Table 3-1 shows a list of the peripheral interface connectors on the PCISA-LX. Detailed descriptions of these connectors can be found in Section 3.2. Connector Type Label AT power connector 4-pin wafer connector...

  • Page 40: External Peripheral Interface Connectors

    8-pin header USB connector 8-pin header Table 3-1: Peripheral Interface Connectors 3.1.3 External Peripheral Interface Connectors Table 3-2 lists the external peripheral interface connectors on the PCISA-LX. Detailed descriptions of these connectors can be found in Section 3.3. Connector Type Label...

  • Page 41: On-Board Jumpers

    Internal peripheral connectors are found on the CPU card and are only accessible when the CPU card is outside of the chassis. This section has complete descriptions of all the internal peripheral connectors on the PCISA-LX. 3.2.1 AT Power Connector...

  • Page 42: Atx Power Button Connector

    PCISA-LX CPU Card Figure 3-2: AT Power Connector Location PIN NO. DESCRIPTION +12V Table 3-4: AT Power Connector Pinouts 3.2.2 ATX Power Button Connector CN Label: CN24 CN Type: 2-pin wafer connector CN Location: See Figure 3-3 CN Pinouts: See Table 3-5 The power button connector is connected to the power button on the external chassis.

  • Page 43: Audio Connector (10-Pin)

    PCISA -LX CPU Card Figure 3-3: ATX Power Button Connector Location PIN NO. DESCRIPTION +PWRBTN# Table 3-5: ATX Power Button Connector Pinouts 3.2.3 Audio Connector (10-pin) CN Label: CN Type: 10-pin box header CN Location: See Figure 3-4 CN Pinouts: See Table 3-6 The 10-pin audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 44: Battery Connector

    PCISA-LX CPU Card Figure 3-4: Audio Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION LINE_OUT-R LINE_IN-R LINE_OUT-L LINE_IN-L MIC-IN Table 3-6: Audio Connector Pinouts 3.2.4 Battery Connector CN Label: CN29 CN Type: 2-pin wafer connector CN Location: See Figure 3-5...

  • Page 45: Compact Flash ® Connector

    PCISA -LX CPU Card Figure 3-5: Battery Connector Location PIN NO. DESCRIPTION Battery+ Battery- Table 3-7: Battery Connector Pinouts ® 3.2.5 Compact Flash Connector CN Label: CN28 (solder side) CN Type: 50-pin header (2x25) CN Location: See Figure 3-6 CN Pinouts: See Table 3-8 Page 45...

  • Page 46: Figure 3-6: Compact Flash ® Connector Location

    PCISA-LX CPU Card ® Figure 3-6: Compact Flash Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND VCC-IN CHECK1 DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0#...

  • Page 47: Table 3-8: Compact Flash ® Connector Pinouts

    PCISA -LX CPU Card GROUND IOR# IOW# VCC_COM IRQ15 VCC_COM VCC_COM CSEL HDD_RESET IORDY SDREQ SDACK# HDD_ACTIVE# DATA 0 66DET DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 VCC-IN CHECK2 GROUND ® Table 3-8: Compact Flash Connector Pinouts Page 47...

  • Page 48: Fan Connector (+5V)

    PCISA-LX CPU Card 3.2.6 Fan Connector (+5V) CN Label: CN20 CN Type: 3-pin wafer CN Location: See Figure 3-7 CN Pinouts: See Table 3-9 The cooling fan connector provides a 5V, 500mA current to a system cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed.

  • Page 49: Floppy Disk Connector

    PCISA -LX CPU Card 3.2.7 Floppy Disk Connector CN Label: CN14 CN Type: 34-pin box header CN Location: See Figure 3-8 CN Pinouts: See Table 3-10 The floppy disk connector connects to a floppy disk drive. Figure 3-8: 34-pin FDD Connector Location Page 49...

  • Page 50: Gpio Connector

    PCISA-LX CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION DENSEL INDEX# MOA# DSA# DIR# STEP# WDATA# WGATE# TRACK0# RDATA# HEAD# DSKCHG# Table 3-10: 34-pin FDD Connector Pinouts 3.2.8 GPIO Connector CN Label: CN16 CN Type: 10-pin box header (2x5) CN Location:...

  • Page 51: Ide Connector

    40-pin box header (2x20) CN Type: CN Location: See Figure 3-10 CN Pinouts: See Table 3-12 One 40-pin IDE device connector on the PCISA-LX CPU card supports connectivity to Ultra ATA/133 IDE devices with data transfer rates up to 133MB/s. Page 51...

  • Page 52: Figure 3-10: Ide Device Connector Location

    PCISA-LX CPU Card Figure 3-10: IDE Device Connector Location DESCRIPTION DESCRIPTION RESET# Page 52 IEI ® Technology, Corp.

  • Page 53: Keyboard/Mouse Connector

    PCISA -LX CPU Card IOW# IOR# ACK# CABLEID CS0# CS1# ASP# Table 3-12: Primary IDE Connector Pinouts 3.2.10 Keyboard/Mouse Connector CN Label: 6-pin wafer connector CN Type: CN Location: See Figure 3-11 CN Pinouts: See Table 3-13 The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2 Y-cable to add keyboard and mouse functionality to the system.

  • Page 54: Lcd Inverter Power Connector

    PCISA-LX CPU Card Figure 3-11: Keyboard/Mouse Connector Location PIN NO. DESCRIPTION MSDATA MSCLK KBDATA KBCLK Table 3-13: Keyboard/Mouse Connector Pinouts 3.2.11 LCD Inverter Power Connector CN Label: CN21 CN Type: 5-pin wafer CN Location: See Figure 3-12 CN Pinouts: See Table 3-14 The inverter connector is connected to the LCD backlight.

  • Page 55: Led Connector

    PCISA -LX CPU Card Figure 3-12: LCD Inverter Connector Location PIN NO. DESCRIPTION ADJ (Def : GND) +12V BL_EN Table 3-14: Inverter Connector Pinouts 3.2.12 LED Connector CN Label: CN19 CN Type: 6-pin wafer connector CN Location: See Figure 3-13 CN Pinouts: See Table 3-15 Page 55...

  • Page 56: Parallel Port Connector

    PCISA-LX CPU Card Figure 3-13: LED Connector Location PIN NO. DESCRIPTION Power LED+ Power LED- HDD LED+ HDD LED- Table 3-15: LED Connector Pinouts 3.2.13 Parallel Port Connector CN Label: CN15 CN Type: 26-pin box header CN Location: See Figure 3-14...

  • Page 57: Figure 3-14: Parallel Port Connector Location

    PCISA -LX CPU Card Figure 3-14: Parallel Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT Table 3-16: Parallel Port Connector Pinouts Page 57...

  • Page 58: Reset Button Connector

    PCISA-LX CPU Card 3.2.14 Reset Button Connector CN Label: CN25 CN Type: 2-pin wafer connector CN Location: See Figure 3-15 CN Pinouts: See Table 3-17 The reset button connector is connected to the reset button on the external chassis. Figure 3-15: Reset Button Connector Location PIN NO.

  • Page 59: Serial Port (Com1) Connector

    PCISA -LX CPU Card 3.2.15 RS-232 Serial Port (COM1) Connector CN Label: CN17 CN Type: 2 x 5-pin box header CN Location: See Figure 3-16 CN Pinouts: See Table 3-18 The CN17 serial port connector connects to RS-232 serial port devices. Figure 3-16: RS-232 Serial Port Connector Location Page 59...

  • Page 60: Rs-232/422/485 Com Serial Port (Com2, Com3) Connector

    PCISA-LX CPU Card DESCRIPTION DESCRIPTION Table 3-18: RS-232 Serial Port Connector Pinouts 3.2.16 RS-232/422/485 COM Serial Port (COM2, COM3) Connector CN Label: CN18 CN Type: 2 x 7-pin box header CN Location: See Figure 3-17 CN Pinouts: See Table 3-19 Pins 1-10 (COM-2) comply with RS-232 standards.

  • Page 61: Sata Drive Connectors

    PCISA -LX CPU Card Figure 3-17: RS-232/422/485 Serial Port Connector Location DESCRIPTION DESCRIPTION DCD# DSR# RTS# CTS# DTR# TxD485+ TxD485- RxD485+ RxD485- Table 3-19: RS-232/422/485 Serial Port Connector Pinouts 3.2.17 SATA Drive Connectors CN Label: CN12 and CN13 CN Type: 7-pin SATA drive connector CN Location: See Figure 3-18...

  • Page 62: Suspend Power And Pson# Signal Connector

    PCISA-LX CPU Card The two SATA drive connectors are connected to two first generation SATA drives. First generation SATA drives transfer data at speeds as high as 150Mb/s. Figure 3-18: SATA Drive Connector Locations PIN NO. DESCRIPTION TX0+ TX0- RX0-...

  • Page 63: Figure 3-19: Suspend Power And Pson# Signal Connector Location

    PCISA -LX CPU Card Figure 3-19: Suspend Power and PSON# Signal Connector Location PIN NO. DESCRIPTION PSON# SUS_5V Table 3-21: Suspend Power and PSON# Signal Connector Pinouts Page 63...

  • Page 64: Tft Lcd Lvds Output Connector

    PCISA-LX CPU Card 3.2.19 TFT LCD LVDS Output Connector CN Label: CN27 CN Type: 20-pin crimp connector CN Location: See Figure 3-20 CN Pinouts: See Table 3-22 This connector is connected to a TFT LCD LVDS display device. Figure 3-20: TFT LCD LVDS Connector Location Page 64 IEI ®...

  • Page 65: Tft Lcd Ttl Output Connector

    PCISA -LX CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION CLK- CLK+ LCD_VCC LCD_VCC LCD_VCC LCD_VCC Table 3-22: TFT LCD LVDS Connector Pinouts 3.2.20 TFT LCD TTL Output Connector CN Label: CN26 CN Type: 40-pin crimp connector CN Location: See Figure 3-21 CN Pinouts: See Table 3-23 This connector is connected to a TFT LCD TTL display device.

  • Page 66: Figure 3-21: Tft Lcd Ttl Connector Location

    PCISA-LX CPU Card Figure 3-21: TFT LCD TTL Connector Location Page 66 IEI ® Technology, Corp.

  • Page 67: Usb Connectors

    PCISA -LX CPU Card PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCD_VCC LCD_VCC LCD_VCC LCD_VCC VSYNC HSYNC LCD_EN DISP_EN Table 3-23: TFT LCD TTL Connector Pinouts 3.2.21 USB Connectors CN Label: CN6 and CN8 CN Type: 8-pin header (2x4) CN Location: See Figure 3-22 CN Pinouts: See Table 3-24 for CN6 pinouts...

  • Page 68: External Peripheral Interface Connector Panel

    PCISA-LX CPU Card The 2x4 USB pin connectors provide connectivity to USB 2.0 ports. Each USB connector can support two USB devices. An additional USB port is found on the rear panel. The USB ports are used for I/O bus expansion.

  • Page 69: Figure 3-23: Pcisa-Lx External Peripheral Interface Connector Panel

    PCISA -LX CPU Card Figure 3-23 shows the PCISA-LX external peripheral interface connector panel. The peripheral connectors are connected to external devices when the PCISA-LX is installed in a chassis. The peripheral connectors on the panel are: 1 x PS/2 keyboard and mouse mini-DIN connector...

  • Page 70: Lan Connectors

    CN Pinouts: See Table 3-26 The PCISA-LX is equipped with two built-in GbE Ethernet controllers. The controllers can connect to the LAN through two RJ-45 LAN connectors. There are two LEDs on the connector indicating the status of LAN. The pin assignments are listed in the following...

  • Page 71: Mini-Din 6 Ps/2 Connector

    CN Pinouts: See Table 3-28 The PCISA-LX CPU card has a mini-DIN 6 PS/2 connector on the mounting bracket for easy connection to a PS/2 keyboard or PS/2 mouse. The card comes with a cable to convert the mini-DIN 6 PS/2 into two mini-DIN 6 PS/2 connectors for keyboard and mouse connection.

  • Page 72: Usb Connector

    CN Type: CN Location: See Figure 3-23 (labeled number 3) CN Pinouts: See Table 3-29 The PCISA-LX has a one rear panel USB port. This port connects to both USB 2.0 and USB 1.1 devices. Page 72 IEI ® Technology, Corp.

  • Page 73: Vga Connector

    PCISA -LX CPU Card PIN NO. DESCRIPTION Table 3-29: USB Port Pinouts 3.3.4 VGA connector CN Label: CN Type: HD-D-sub 15 female connector CN Location: See Figure 3-23 (labeled number 4) CN Pinouts: See Table 3-30 A 15-pin VGA connector connects to standard displays. Figure 3-26: VGA Connector PIN NO.

  • Page 74: Table 3-30: Vga Connector Pinouts

    PCISA-LX CPU Card HSYNC VSYNC Table 3-30: VGA Connector Pinouts Page 74 IEI ® Technology, Corp.

  • Page 75: Installation

    PCISA -LX CPU Card Chapter Installation Page 75...

  • Page 76: Anti-Static Precautions

    4.1 Anti-static Precautions Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PCISA-LX. (Dry climates are especially susceptible to ESD.) It is therefore critical that whenever the PCISA-LX (or any other electrical component) is handled, the following anti-static precautions are strictly adhered to.

  • Page 77: Unpacking

    Contact the reseller or vendor CPU card was purchased from. 4.3.1 Unpacking Precautions Some components on PCISA-LX are very sensitive to static electricity and can be damaged by a sudden rush of power. To protect it from being damaged during the...

  • Page 78: Checklist

    1 x Utility CD 1 x QIG (quick installation guide) If one or more of these items are missing, contact the reseller or vendor PCISA-LX was purchased from and do not proceed any further with the installation. 4.4 PCISA-LX CPU Card Installation...

  • Page 79: Preinstalled Component

    CPU and DIMM modules. 4.5 Preinstalled Component The component listed below is preinstalled on the PCISA-LX. 4.6 Components to Install To install the PCISA-LX, the following components must be installed or connected to the PCISA-LX: DIMM module Peripheral devices 4.7 DIMM Module Installation...

  • Page 80: Dimm Module Installation

    PCISA-LX CPU Card 4.7.2 DIMM Module Installation The PCISA-LX CPU card has one DDR SDRAM DIMM socket. To install a DIMM module, follow the instructions below and refer to Figure 4-1. Step 1: Make sure the two handles of the DIMM socket are in the "open" position, leaning outward (Figure 4-1).

  • Page 81: Peripheral Device Connection

    PCISA -LX CPU Card 4.8 Peripheral Device Connection Cables provided by IEI that connect peripheral devices to the board are listed in Table 4-1. Cables not included in the kit must be separately purchased. Quantity Type ATA 66/100 HDD cable Audio cable Dual RS-232 cables KB/MS Y cable...

  • Page 82: Com2-Com3 Rs-232 Serial Port Installation

    PCISA-LX CPU Card Figure 4-2: Connection of IDE Connector NOTE: When two EIDE disk drives are connected together, back-end jumpers on the drives must be used to configure one drive as a master and the other as a slave. 4.8.2 COM2-COM3 RS-232 Serial Port Installation The cable used to connect the CPU card to an RS-232 serial port is a 10-pin header to male D-sub 9 connector.

  • Page 83: Lcd Backlight Installation

    PCISA -LX CPU Card 4.8.3 LCD Backlight Installation To connect an LCD backlight (inverter) to the CPU card, follow the instruction below. Step 1: Connect the 5-pin connector end of the LCD backlight cable to the CN21 header on the CPU card. A keyed pin on the connector prevents it from being connected incorrectly.Step 0: 4.8.4 Power Connection To connect the CPU card to a power supply, follow the instruction below.

  • Page 84: Jumper Settings

    OPEN a jumper means removing the plastic clip from a jumper. Before the PCISA-LX is installed in the system, the jumpers must be set in accordance with the desired configuration. The PCISA-LX CPU card has five on-board jumpers.

  • Page 85: At Power Select Jumper

    PCISA -LX CPU Card Figure 4-3: Jumper Locations 4.9.1 AT Power Select Jumper Jumper Label: Jumper Type: 2-pin header Jumper Settings: See Table 4-2 Jumper Location: See Figure 4-3 The AT/ATX power button connector is used to connect a chassis power On/Off button using an adapter cable and is configured through the JP5 jumper, which controls the connection to a power supply.

  • Page 86: Com2 Rs-422/485 Select Jumper

    PCISA-LX CPU Card Description Short AT Mode (Default) Open ATX Mode Table 4-2: AT Power Select Jumper Settings 4.9.2 COM2 RS-422/485 Select Jumper Jumper Label: Jumper Type: 3-pin header Jumper Settings: See Table 4-3 Jumper Location: See Figure 4-3 The RS-422/485 select jumper sets the communication protocol used by the second serial communications port (COM2) as RS-422 or RS-485.

  • Page 87: Lcd Voltage Select Jumper

    PCISA -LX CPU Card Description Short1-2 Normal Output (Default) Short 2-3 Inverted Output Table 4-4: LCD Clock Jumper Settings 4.9.4 LCD Voltage Select Jumper WARNING! Making the wrong setting on this jumper may cause irreparable damage to both the CPU card and the LCD screen connected to the on-board connector.

  • Page 88: Pci Vio Voltage Select Jumper

    Configuration options can be found through the BIOS configuration utility. To install a CFII card, follow the instructions below. Step 1: Turn the PCISA-LX over so that the CFII card socket is facing up. Step 2: Carefully insert the CFII card into the socket.

  • Page 89: Inserting The Cpu Card

    After the DIMM module has been installed and after the internal peripheral connectors have been connected to the peripheral devices and the jumpers have been configured, the PCISA-LX can be inserted onto a PCISA slot on the backplane. To insert the CPU card to a backplane, follow the instructions below.

  • Page 90: Rear Panel Connectors

    PCISA-LX CPU Card 4.12 Rear Panel Connectors 4.12.1 Keyboard and Mouse Connection A PS/2 keyboard and a PS/2 mouse can be connected to the appropriate PS/2 connector on the rear panel. 4.12.2 Ethernet Connection The rear panel RJ-45 connectors can be connected to an external LAN and communicate with data transfer rates up to 10Mbps and 100Mbps.

  • Page 91: Bios Settings

    PCISA -LX CPU Card Chapter BIOS Settings Page 91...

  • Page 92: Introduction

    PCISA-LX CPU Card 5.1 Introduction A licensed copy of Phoenix Award BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 93: Getting Help

    PCISA -LX CPU Card Function Previous values for the page menu items Fail-safe defaults for the current page menu items Optimized defaults for the current page menu items Menu in BIOS Save changes and Exit BIOS Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.
  • Page 94 PCISA-LX CPU Card BIOS Menu 1: AwardBIOS CMOS Setup Utility NOTE: The following sections will completely describe the menus listed below and the configuration options available to users. The following menu options are seen in BIOS Menu 1. Standard CMOS Features: Changes the basic system configuration.

  • Page 95: Load Fail-Safe Defaults

    PCISA -LX CPU Card Load Fail-Safe Defaults Select this option to load failsafe default values for each BIOS parameter in the setup menus. Press F6 for this operation on any page. Load Optimized Defaults Select this option to load optimal default values for each BIOS parameter in the setup menus.

  • Page 96: Standard Cmos Features

    PCISA-LX CPU Card 5.2 Standard CMOS Features Use the Standard CMOS Features BIOS menu (BIOS Menu 2) to set basic BIOS configuration options. BIOS Menu 2: Standard CMOS Features Date [Day mm:dd:yyyy] The Date option sets the system date. Time [hh/mm/ss] The Time option sets the system time.

  • Page 97: Drive A [1.44M, 3.5In]

    PCISA -LX CPU Card IDE device configurations are changed or set in the IDE Configuration menu (BIOS Menu 3). If an IDE device is detected, and one of the above listed two BIOS configuration options is selected, the IDE configuration options shown in Section 5.2.1 appear. Drive A [1.44M, 3.5in] Use the Drive A configuration option to specify the floppy drive type installed in the system.

  • Page 98: Ide Primary Master/Slave

    PCISA-LX CPU Card All Errors Whenever BIOS detects a non-fatal error the system is stopped and the user prompted. The system boot is not stopped for any errors No Errors that may be detected. All, But Keyboard The system boot does not stop for a keyboard EFAULT error;...

  • Page 99: Ide Hdd Auto-Detection [Press Enter]

    PCISA -LX CPU Card BIOS Menu 3: IDE Primary Master IDE HDD Auto-Detection [Press Enter] Use the IDE HDD Auto-Detection option to enable BIOS to automatically detect the IDE settings. Select IDE HDD Auto-Detection and press E . BIOS automatically detects NTER the HDD type.

  • Page 100: Access Mode [Auto]

    PCISA-LX CPU Card Auto Setting this option allows the device to be automatically EFAULT detected by the BIOS. Selecting this option allows manual configuration of the Manual device on the IDE channel in BIOS. Access Mode [Auto] The Access Mode option can only be configured if the IDE Primary Master is set to either Manual or Auto.

  • Page 101: Advanced Bios Features

    PCISA -LX CPU Card Head The Head specification indicates how many logical heads are on the HDD installed in the system. Precomp The Precomp specification indicates on what track the write precompensation begins. Landing Zone The Landing Zone specification indicates where the disk head will park itself after the system powers off.

  • Page 102: Virus Warning [Disabled]

    PCISA-LX CPU Card BIOS Menu 4: Advanced BIOS Features Virus Warning [Disabled] NOTE: Many disk diagnostic programs can cause the above warning message to appear when the program attempts to access the boot sector table. If you are running such a program, it is recommended that the virus protection function be disabled beforehand.

  • Page 103: Cpu Internal Cache [Enabled]

    PCISA -LX CPU Card Enabled Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector or HDD partition table. Disabled No warning message appears when there is an attempt EFAULT to access the boot sector or HDD partition table.

  • Page 104: Sata Boot Rom Control [Disabled]

    PCISA-LX CPU Card SATA Boot ROM Control [Disabled] Use the SATA Boot ROM Control option to configure SATA IDE use in DOS mode. Disabled Disables SATA IDE use in DOS mode. EFAULT Enabled Enables SATA IDE use in DOS mode.

  • Page 105: Boot Other Device [Enabled]

    PCISA -LX CPU Card Boot Other Device [Enabled] Use the Boot Other Device option to determine whether the system uses a second or third boot device if the first boot device is not found. Disabled The system does not look for second and third boot devices if the first one is not found.

  • Page 106: Boot Up Numlock Status [On]

    PCISA-LX CPU Card Boot Up Numlock Status [On] Use the Boot Up Numlock Status option to specify the default state of the numeric keypad. The keys on the keypad are not activated. Activates the keys on the keypad. EFAULT Gate A20 Option [Fast] Use the Gate A20 Option option to set if the keyboard controller or the chipset controls the Gate A20 switching.

  • Page 107: Typematic Delay (Msec) [250]

    PCISA -LX CPU Card 6 characters per second EFAULT 8 characters per second 10 characters per second 12 characters per second 15 characters per second 20 characters per second 24 characters per second 30 characters per second Typematic Delay (Msec) [250] The Typematic Rate option can only be configured if the Typematic Rate Setting is enabled.

  • Page 108: Os Select For Dram > 64Mb [Non-Os2]

    PCISA-LX CPU Card NOTE: To disable security, select the password setting in the Main Menu. When asked to enter a password, don’t type anything, press E and the security is disabled. Once the security is NTER disabled, the system boots and Setup can be accessed.

  • Page 109: Small Logo (Epa) Show [Disabled]

    PCISA -LX CPU Card NOTE: To disable security, select the password setting in the Main Menu. When asked to enter a password, do not type anything, press E and the security is disabled. Once the security is NTER disabled, the system boots and Setup can be accessed. Small Logo (EPA) Show [Disabled] Use the Small Logo (EPA) Show option to specify if the Environmental Protection Agency (EPA) logo appears during the system boot-up process.

  • Page 110: Advanced Chipset Features

    PCISA-LX CPU Card 5.4 Advanced Chipset Features Use the Advanced Chipset Features menu (BIOS Menu 5) to change chipset configuration options. BIOS Menu 5: Advanced Chipset Features CPU Frequency [500MHz] Use the CPU Frequency option to set the CPU frequency. The CPU Frequency options...

  • Page 111: Cas Latency [Auto]

    PCISA -LX CPU Card Auto (D EFAULT DDR 200 DDR 266 DDR 333 CAS Latency [Auto] Use the CAS Latency Time option to set the Column Address Strobe (CAS) delay time. The CAS Latency Time options are: Auto (D EFAULT 1.5 nanoseconds 2.0 nanoseconds 2.5 nanoseconds...

  • Page 112: Output Display [Panel & Crt]

    PCISA-LX CPU Card Output Display [Panel & CRT] Use the Output Display configuration to specify the display devices the system is connected to. The Output Display options are: Flat Panel CRT (D EFAULT Panel & CRT Flat Panel Configuration [Press Enter] Use the Flat Panel Configuration option to open the Flat Panel Configuration menu.

  • Page 113: Flat Panel Configuration

    PCISA -LX CPU Card 5.4.1 Flat Panel Configuration Use the Flat Panel Configuration menu (BIOS Menu 6) to set the configuration settings for the flat panel screen connected to the system. BIOS Menu 6: Flat Panel Configuration Flat Panel Type [Auto] Use the Flat Panel Type option to specify the type of flat panel screen connected to the system.

  • Page 114: Resolution [800 X 600]

    PCISA-LX CPU Card Resolution [800 x 600] The Resolution option can only be configured if the Flat Panel Type option is not set to Auto. Use the Resolution option to set the resolution of the flat panel screen connected to the system. The Resolution options are:...

  • Page 115: Hsync Polarity [Low]

    PCISA -LX CPU Card 60Hz (D EFAULT 70Hz 72Hz 75Hz 85Hz 90Hz 100Hz HSYNC Polarity [Low] The HSYNC Polarity option can only be configured if the Flat Panel Type option is not set to Auto. Use the HSYNC Polarity option to set the polarity of the HSYNC signal to the panel.

  • Page 116: Integrated Peripherals

    PCISA-LX CPU Card Active Only Free running (D EFAULT 5.5 Integrated Peripherals Use the Integrated Peripherals menu (BIOS Menu 7) to change the configuration options for the attached peripheral devices. BIOS Menu 7: Integrated Peripherals On-Chip IDE Channel 1 [Enabled] The On-Chip IDE Channel 1 option is enabled and is NOT user configurable.

  • Page 117: Ide Udma [Auto]

    PCISA -LX CPU Card Auto The computer selects the correct mode. EFAULT Mode 0 PIO mode 0 selected with a maximum transfer rate of 3.3MBps. Mode 1 PIO mode 1 selected with a maximum transfer rate of 5.2MBps. Mode 2 PIO mode 2 selected with a maximum transfer rate of 8.3MBps.

  • Page 118: It8888 Isa Decode Memory [Press Enter]

    PCISA-LX CPU Card IT8888 ISA Decode Memory [Press Enter] Press Enter to open the IT8888 ISA Decode Memory menu. The IT8888 ISA Decode Memory options are shown in Section 5.5.2. IDE HDD Block Mode [Enabled] If the drive connected to the system supports block mode, use the IDE HDD Block Mode option to enable the system to detect the optimal number of block read/writes per sector the system IDE drive can support.

  • Page 119: Onboard Serial Port 2 [2F8/Irq3]

    PCISA -LX CPU Card Onboard Serial Port 2 [2F8/IRQ3] Use the Onboard Serial Port 2 option to select the I/O address and IRQ for the onboard serial port 2. The serial port can be disabled or the I/O address and the IRQ can be automatically selected by the BIOS.

  • Page 120: Parallel Port Mode [Spp]

    PCISA-LX CPU Card Parallel Port Mode [SPP] Use the Parallel Port Mode option to select parallel port operation mode. The parallel port operates in the standard parallel port EFAULT (SPP) mode. This parallel port mode works with most parallel port devices but is slow.

  • Page 121: Ecp Mode Use Dma [3]

    PCISA -LX CPU Card x ECP Mode Use DMA [3] The ECP Mode Use DMA option is only available if the Parallel Port Mode option is set to ECP mode. Use the ECP Mode Use DMA option to specify the DMA channel the parallel port must use in the ECP mode.

  • Page 122: It8888 Isa Decode Io

    PCISA-LX CPU Card 5.5.1 IT8888 ISA Decode IO Use the IT8888 ISA Decode IO menu (BIOS Menu 8) to set the IO memory range for the onboard ISA. BIOS Menu 8: IT8888 ISA Decode IO Page 122 IEI ® Technology, Corp.

  • Page 123: Decode Io Space N [Enabled]

    PCISA -LX CPU Card The IT8888 ISA Decode IO menu has the following common options: Decode I/O Space N Decode I/O Speed N Decode I/O Addr. N [15:0] Decode I/O Size N Where N is an integer in the set [1, 2, 3, 4, 5] and represents a set for the PCI-104 devices that are attached to the system.

  • Page 124: It8888 Isa Decode Memory

    PCISA-LX CPU Card Decode IO Size N [Fast Speed] Use the Decode IO Size N option to specify the size of the ISA bus. The following options are available: 1 Byte 2 Bytes 4 Bytes 8 Bytes 16 Bytes 32 Bytes...

  • Page 125: Decode Memory Space N [Enabled]

    PCISA -LX CPU Card The IT8888 ISA Decode IO menu has the following common options: Decode Memory Space N Decode Memory Speed N Decode Memory Addr. N [15:0] Decode Memory Size N Where N is an integer in the set [1, 2, 3, 4, 5] and represents a memory set for the PCI-104 devices that are attached to the system.

  • Page 126: Power Management Setup

    PCISA-LX CPU Card Decode Memory Size N [xx] Use the Decode Memory Size N option to specify the memory size of the ISA bus. The following options are available: 16 KB 32 KB 64 KB 128 KB 256 KB 512 KB...

  • Page 127: Acpi Function [Disabled]

    PCISA -LX CPU Card x ACPI Function [Disabled] The ACPI Function is enabled when the Power Management option is set to ACPI; otherwise, it is disabled. Disabled ACPI function disabled EFAULT ACPI function enabled Enabled ACPI Suspend Type [S1 (POS)] The ACPI Suspend Type BIOS option specifies the sleep state the system enters when not being used.

  • Page 128: Suspend Mode [Disabled]

    PCISA-LX CPU Card Disabled (D EFAULT 1 Sec 5 Sec 10 Sec 15 Sec 30 Sec 45 Sec 1 Min 5 Min 10 Min 15 Min 30 Min 45 Min 60 Min 90 Min 120 Min x Suspend Mode [Disabled] The Suspend Mode option can only be selected if the Power Management option is set to Legacy.

  • Page 129: Soft-Off By Pwr-Bttn [Instant-Off]

    PCISA -LX CPU Card 60 Min 90 Min 120 Min Soft-Off by PWR-BTTN [Instant-Off] Use the Soft-Off by PWR-BTTN option to enabled the system to enter a very low-power-usage state when the power button is pressed. When the power button is pressed, the system is Instant-Off EFAULT immediately shutdown.

  • Page 130: Pnp/Pci Configurations

    PCISA-LX CPU Card 5.7 PnP/PCI Configurations Use the PnP/PCI Configurations menu (BIOS Menu 11) to set the plug and play, and PCI options. BIOS Menu 11: PnP/PCI Configurations PNP OS Installed [No] The PNP OS Installed option determines whether the Plug and Play devices connected to the system are configured by the operating system or the BIOS.

  • Page 131: Resources Controlled By [Auto (Escd)]

    PCISA -LX CPU Card Disabled ESCD will not be reconfigured EFAULT Enabled ESCD will be reconfigured after you exit setup Resources Controlled By [Auto (ESCD)] Use the Resources Controlled By option to either manually configure all the boot and plug and play devices, or allow BIOS to configure these devices automatically. If BIOS is allowed to configure the devices automatically IRQs, DMA and memory base address fields cannot be set manually.
  • Page 132 PCISA-LX CPU Card BIOS Menu 12: IRQ Resources The IRQ Resources menu has the following options: IRQ-3 assigned to IRQ-4 assigned to IRQ-5 assigned to IRQ-7 assigned to IRQ-10 assigned to IRQ-11 assigned to The above options all have the following options.

  • Page 133: Memory Resources [Press Enter]

    PCISA -LX CPU Card x Memory Resources [Press Enter] The Memory Resources menu (BIOS Menu 13) can only be accessed if the Resources Controlled By option is set to Manual. Use Memory Resources to select a base address and the length for the memory area used by a peripheral that requires high memory. BIOS Menu 13: Memory Resources The menu has two configurable options: Reserved Memory Base...

  • Page 134: Pc Health Status

    PCISA-LX CPU Card D800 DC00 x Reserved Memory Length [8K] The Reserved Memory Length option can only be accessed if the Reserved Memory Base option is not set to N/A. The Reserved Memory Length specifies the amount of memory reserved for the peripheral device. The Reserved Memory Length options:...

  • Page 135: Fan Speed

    PCISA -LX CPU Card BIOS Menu 14: PC Health Status The following system parameters are monitored by the PC Health Status menu: Fan Speed The following fan speed is monitored: Current CPU Fan Speed Voltages The following voltages are monitored: Vcore VccMem +3.3 V...
  • Page 136 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 136 IEI ® Technology, Corp.

  • Page 137: Driver Installation

    PCISA -LX CPU Card Chapter Driver Installation Page 137...

  • Page 138: Available Software Drivers

    All five drivers can be found on the CD that came with the CPU card. To install the drivers please follow the instructions in the sections below. Insert the CD into the system that contains the PCISA-LX CPU card. NOTE: If your system does not run the "autorun"...

  • Page 139: Figure 6-1: Amd Lx/Gx Cd Main Menu

    PCISA -LX CPU Card Step 4: From the AMD LX/GX Driver CD main menu (Figure 6-1), click PCISA-LX. Figure 6-1: AMD LX/GX CD Main Menu Page 139...

  • Page 140: Figure 6-2: Amd Lx/Gx Cd Driver Menu

    Select any item from the list to view more information on the driver installation, or select Manual to navigate to the PCISA-LX user manual. Step 0: The following sections fully describe the driver installation procedures for the PCISA-LX CPU card. Page 140...

  • Page 141: Vga Driver

    PCISA -LX CPU Card 6.3 VGA Driver To install the VGA driver follow the steps below. Step 1: Open Windows Control Panel (Figure 6-3). Figure 6-3: Access Windows Control Panel Page 141...

  • Page 142: Figure 6-4: Double Click The System Icon

    PCISA-LX CPU Card Step 2: Double click the System icon (Figure 6-4). Figure 6-4: Double Click the System Icon Page 142 IEI ® Technology, Corp.

  • Page 143: Figure 6-5: Double Click The Device Manager Tab

    PCISA -LX CPU Card Step 3: Double click the Device Manager tab (Figure 6-5). Figure 6-5: Double Click the Device Manager Tab Page 143...

  • Page 144: Figure 6-6: Device Manager List

    PCISA-LX CPU Card Step 4: A list of system hardware devices appears (Figure 6-6). Figure 6-6: Device Manager List Step 5: Expand the Display Adapters category (Figure 6-7). Right click the adapter and select Properties. NOTE: If the Display Adapters category is not available, navigate to X:\VGA\LX800\XP\VGA 2.01.05 (where X:\ is the system CD...

  • Page 145: Figure 6-7: Expand The Display Adapters Category

    PCISA -LX CPU Card Figure 6-7: Expand the Display Adapters Category Page 145...

  • Page 146: Figure 6-8: Update Driver

    PCISA-LX CPU Card Step 6: From the Driver tab of the Properties window, click Update Driver (Figure 6-8) or, click Reinstall Driver if Update Driver is not seen. Figure 6-8: Update Driver Page 146 IEI ® Technology, Corp.

  • Page 147: Figure 6-9: Upgrade Device Driver Wizard

    PCISA -LX CPU Card Step 7: The Upgrade Device Driver Wizard appears (Figure 6-9). Click N continue. Figure 6-9: Upgrade Device Driver Wizard Page 147...

  • Page 148: Figure 6-10: Search For Suitable Driver

    PCISA-LX CPU Card Step 8: The Install Hardware Device Driver screen appears (Figure 6-10). Select the Search for a suitable driver for my device radio button and click N continue. Figure 6-10: Search for Suitable Driver Page 148 IEI ® Technology, Corp.

  • Page 149: Figure 6-11: Locate Driver Files

    PCISA -LX CPU Card Step 9: Select Specify a Location in the Locate Driver Files window (Figure 6-11). Click to continue. Figure 6-11: Locate Driver Files Page 149...

  • Page 150: Figure 6-12: Location Browsing Window

    PCISA-LX CPU Card Step 10: Click Browse and navigate to the X:\AMD\LX800\XP\VGA 2.01.05 directory, where “X:” is the system CD drive (Figure 6-12). Figure 6-12: Location Browsing Window Step 11: Click OK to continue. Step 12: A driver files location menu window appears. Click N to continue.

  • Page 151: Audio Driver Installation

    PCISA -LX CPU Card 6.4 Audio Driver Installation To install the audio driver please follow the steps below. Step 1: Open Windows Control Panel (Figure 6-13). Figure 6-13: Access Windows Control Panel Page 151...

  • Page 152: Figure 6-14: Double Click The System Icon

    PCISA-LX CPU Card Step 2: Double click the System icon (Figure 6-14). Figure 6-14: Double Click the System Icon Page 152 IEI ® Technology, Corp.

  • Page 153: Figure 6-15: Double Click The Device Manager Tab

    PCISA -LX CPU Card Step 3: Double click the Device Manager tab (Figure 6-15). Figure 6-15: Double Click the Device Manager Tab Page 153...

  • Page 154: Figure 6-16: Device Manager List

    PCISA-LX CPU Card Step 4: A list of system hardware devices appears (Figure 6-16). Figure 6-16: Device Manager List Step 5: Double click the listed device that has question marks next to it. (This means Windows does not recognize the device).

  • Page 155: Figure 6-17: Search For Suitable Driver

    PCISA -LX CPU Card Step 6: The Device Driver Wizard appears (Figure 6-17). Click N to continue. Figure 6-17: Search for Suitable Driver Page 155...

  • Page 156: Figure 6-18: Locate Driver Files

    PCISA-LX CPU Card Step 7: Select “Specify a Location” in the Locate Driver Files window (Figure 6-18). Click N to continue. Figure 6-18: Locate Driver Files Page 156 IEI ® Technology, Corp.

  • Page 157: Lan Driver

    PCISA -LX CPU Card Step 8: Select “X:\ Audio\GeodeLX_XP_XPe_WDM_Audio_v2.03.00” directory in the location browsing window, where “X:\” is the system CD drive (Figure 6-19). Figure 6-19: Location Browsing Window Step 9: Click OK to continue. A driver files location menu window appears. Select the LXWDMAu.inf file and click O to continue.

  • Page 158: Figure 6-20: Locate The Setup Program Icon

    PCISA-LX CPU Card Step 3: Locate the Setup program icon (Figure 6-20). Figure 6-20: Locate the Setup Program Icon Step 4: Double click the Setup program icon in Figure 6-20. Step 5: The Install Shield Wizard is prepared to guide the user through the rest of the process (Figure 6-21).

  • Page 159: Figure 6-22: Install Wizard Welcome Screen

    PCISA -LX CPU Card Step 6: Once initialized, the Install Wizard welcome screen appears (Figure 6-22). Figure 6-22: Install Wizard Welcome Screen Step 7: Click N to continue the installation or C to stop the installation. ANCEL Step 8: The Install Wizard starts to install the LAN driver. Page 159...

  • Page 160: Figure 6-23: Installing Screen

    PCISA-LX CPU Card Step 9: Once the installation is complete, the InstallShield Wizard Complete screen appears (Figure 6-23). Figure 6-23: Installing Screen Step 10: Click F to complete the installation and exit the Install Shield Wizard. INISH Page 160 IEI ® Technology, Corp.

  • Page 161: Sata/Raid Driver

    PCISA -LX CPU Card Step 11: Once the installation process is complete, the computer may be restarted immediately or later. Select the preferred option and click F to complete the INISH installation process and exit the Install Shield Wizard (Figure 6-24). Step 0: Figure 6-24: Restart the Computer 6.6 SATA/RAID Driver...

  • Page 162: Figure 6-25: Locate The Setup Program Icon

    PCISA-LX CPU Card Step 2: Locate the Setup program icon (Figure 6-25). Figure 6-25: Locate the Setup Program Icon Page 162 IEI ® Technology, Corp.

  • Page 163: Figure 6-26: Preparing Setup Screen

    PCISA -LX CPU Card Step 3: The Install Shield Wizard (Figure 6-26) is prepared to guide the user through the rest of the process. Figure 6-26: Preparing Setup Screen Step 4: Once initialized, the Install Wizard welcome screen appears (Figure 6-27). Figure 6-27: Install Wizard Welcome Screen Step 5: Click N...

  • Page 164: Figure 6-28: Installing Screen

    PCISA-LX CPU Card Step 6: The Install Wizard starts to install the driver (Figure 6-28). Figure 6-28: Installing Screen Page 164 IEI ® Technology, Corp.

  • Page 165: Figure 6-29: Raid Driver Digital Signal

    PCISA -LX CPU Card Step 7: A “Digital Signal Not Found” screen appears (Figure 6-29). Click Y continue the installation process. Figure 6-29: RAID Driver Digital Signal Page 165...

  • Page 166: Figure 6-30: Installshield Wizard Complete Screen

    PCISA-LX CPU Card Step 8: Once the installation is complete, the InstallShield Wizard Complete screen appears (Figure 6-30). Figure 6-30: InstallShield Wizard Complete Screen Step 9: Once the installation process is complete, the computer may be restarted immediately or later. Select the preferred option and click F...

  • Page 167: Isa Driver

    PCISA -LX CPU Card 6.7 ISA Driver To install the IT8888 ISA Bridge driver please follow the steps below: Step 1: Open Windows Control Panel (Figure 6-31). Figure 6-31: Access Windows Control Panel Page 167...

  • Page 168: Figure 6-32: Double Click The System Icon

    PCISA-LX CPU Card Step 2: Double click the System icon (Figure 6-32). Figure 6-32: Double Click the System Icon Page 168 IEI ® Technology, Corp.

  • Page 169: Figure 6-33: Double Click The Device Manager Tab

    PCISA -LX CPU Card Step 3: Double click the Device Manager tab (Figure 6-33). Figure 6-33: Double Click the Device Manager Tab Page 169...

  • Page 170: Figure 6-34: Device Manager List

    PCISA-LX CPU Card Step 4: A list of system hardware devices appears (Figure 6-34). Figure 6-34: Device Manager List Step 5: Double click the listed device that has question marks next to it. (This means Windows does not recognize the device).

  • Page 171: Figure 6-35: Search For Suitable Driver

    PCISA -LX CPU Card Step 6: The Device Driver Wizard appears (Figure 6-35). Click N to continue. Figure 6-35: Search for Suitable Driver Page 171...

  • Page 172: Figure 6-36: Locate Driver Files

    PCISA-LX CPU Card Step 7: Select “Specify a Location” in the Locate Driver Files window (Figure 6-36). Click N to continue. Figure 6-36: Locate Driver Files Page 172 IEI ® Technology, Corp.

  • Page 173: Figure 6-37: Location Browsing Window

    PCISA -LX CPU Card Step 8: Select “X:\IT8888” directory in the location browsing window, where “X:\” is the system CD drive (Figure 6-37). Figure 6-37: Location Browsing Window Click OK to continue. A driver files location menu window appears. Select the ite.inf file and click O to continue.
  • Page 174 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 174 IEI ® Technology, Corp.
  • Page 175 PCISA -LX CPU Card Appendix BIOS Menu Options Page 175...
  • Page 176 PCISA-LX CPU Card A.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 5. Load Fail-Safe Defaults ..................95 Load Optimized Defaults..................95 Set Supervisor Password ..................95 Set User Password ....................95 Save & Exit Setup ....................95 Exit Without Saving ....................95 Date [Day mm:dd:yyyy] ..................96...
  • Page 177 PCISA -LX CPU Card Boot Device ......................104 Boot Other Device [Enabled] ................105 Swap Floppy Drive [Disabled] ................105 Boot Up Floppy Seek [Disabled] ............... 105 Boot Up Numlock Status [On] ................106 Gate A20 Option [Fast]..................106 Typematic Rate Setting [Disabled]..............106 Typematic Rate (Chars/sec) [6] .................
  • Page 178 PCISA-LX CPU Card Drive PIO Mode [Auto]..................116 IDE UDMA [Auto]....................117 IDE DMA transfer access [Enabled]..............117 IT8888 ISA Decode IO [Press Enter] ..............117 IT8888 ISA Decode Memory [Press Enter] ............118 IDE HDD Block Mode [Enabled] ................ 118 Onboard FDC Controller [Enabled]..............
  • Page 179 PCISA -LX CPU Card x IRQ Resources [Press Enter]................131 x Memory Resources [Press Enter] ..............133 Reserved Memory Base [N/A]................133 x Reserved Memory Length [8K]............... 134 PCI/VGA Palette Snoop [Disabled]..............134 Fan Speed......................135 Voltages ....................... 135 Page 179...
  • Page 180 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 180 IEI ® Technology, Corp.
  • Page 181 PCISA -LX CPU Card Appendix Watchdog Timer Page 181...
  • Page 182 PCISA-LX CPU Card NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for more sophisticated operating systems, e.g., Windows® and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 183 PCISA -LX CPU Card NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...
  • Page 184 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 184 IEI ® Technology, Corp.
  • Page 185 PCISA -LX CPU Card Appendix Address Mapping Page 185...
  • Page 186 PCISA-LX CPU Card C.1 IO Address Map I/O address Description Range 000-01F DMA Controller 020-021 Interrupt Controller 040-043 System time 060-06F Keyboard Controller 070-07F System CMOS/Real time Clock 080-09F DMA Controller 0A0-0A1 Interrupt Controller 0C0-0DF DMA Controller 0F0-0FF Numeric data processor...
  • Page 187 PCISA -LX CPU Card C.3 IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 ACPI IRQ2 Available IRQ10 IRQ3 COM2 IRQ11 LAN/USB2.0/SATA IRQ4 COM1 IRQ12 PS/2 mouse IRQ5 SMBus Controller IRQ13 IRQ6 IRQ14 Primary IDE IRQ7 Available IRQ15 Secondary IDE Table C-3: IRQ Mapping Table...
  • Page 188 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 188 IEI ® Technology, Corp.
  • Page 189 PCISA -LX CPU Card Appendix External AC’97 Audio CODEC Page 189...
  • Page 190 PCISA-LX CPU Card D.1 Introduction The motherboard comes with an onboard Realtek ALC203 CODEC. Realtek ALC203 is a 20-bit DAC and 18-bit ADC full-duplex AC'97 2.3 compatible stereo audio CODEC with a variable sampling rate. D.1.1 Accessing the AC’97 CODEC The CODEC is accessed through two phone jacks on the rear panel of the motherboard.
  • Page 191 PCISA -LX CPU Card Figure D-1: Control Panel Sound Effect Manager D.2 Sound Effect Configuration D.2.1 Accessing the Sound Effects Manager To access the Sound Effects Manager, please do the following: Step 1: Install the audio CODEC driver. Step 2: Click either: The Sound Effect Manager icon in the Notification Area of the system task bar (Figure D-2), or...
  • Page 192 PCISA-LX CPU Card Step 3: The Sound Effect Manager icon in the Control Panel (Figure D-3). Figure D-3: Sound Effect Manager Icon [Control Panel] Page 192 IEI ® Technology, Corp.
  • Page 193 PCISA -LX CPU Card Step 4: The sound effect manager appears (Figure D-4). Figure D-4: Sound Effects Manager (ALC203) NOTE: The Sound Effect Manager shown in Figure D-4 is for the Realtek ALC203 audio CODEC. Different CODECs may have different sound manager appearances.
  • Page 194 PCISA-LX CPU Card NOTE: The Karaoke Mode is configured in the Sound Effect menu. To access Karaoke configuration settings, click on the Sound Effect menu tab. Sound Effect Karaoke Mode Equalizer Speaker Configuration Speaker Test S/PDIF-In S/PDIF-Out Connector Sensing HRTF Demo...
  • Page 195 PCISA -LX CPU Card The Key adjustment up or down arrow icons enables users to define a key that fits a certain vocal range. Equalizer Selection:- Preset equalizer settings enable easy audio range settings. Ten frequency bands can be configured. Speaker Configuration:- Multi-channel speaker settings are configured in this menu.
  • Page 196 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 196 IEI ® Technology, Corp.
  • Page 197 PCISA -LX CPU Card Appendix ® RAID for SATA Page 197...
  • Page 198 PCISA-LX CPU Card E.1 Introduction The ALi M5283 SATA RAID chipset can control parallel ATA (PATA) and serial ATA (SATA) disks. The ALi controller supports PATA UDMA transfer mode up to mode 6 and SATA 1 disk drives. The ALi M5283 also has a cost-effective RAID functionality that can increase the data read/write speed and provide protection to data by distributing mirrored duplicates of data onto two disk drives (RAID 1).
  • Page 199 PCISA -LX CPU Card CAUTION: Do not accidentally disconnect the SATA drive cables. Carefully route the cables within the chassis to avoid system down time. E.2 Features and Benefits Supports RAID levels 0, 1, and JBOD Supports connectivity to two disk drives Supported Operating Systems include: Windows®...
  • Page 200 PCISA-LX CPU Card Step 3: Save and Exit BIOS. After the SATA ROM Support BIOS option is enabled, save and exit the BIOS. Step 4: Reboot the system. Reboot the system after saving and exiting the BIOS. Step 5: Press Ctrl-A. When the screen in Figure E-1 appears press Ctrl-A to enter the ALi RAID BIOS setup program.
  • Page 201 PCISA -LX CPU Card Figure E-2: RAID BIOS Setup Utility Step 7: Configure the RAID settings. Use the RAID BIOS Setup Utility in Figure E-2 to configure the RAID array. Brief descriptions are given below. Step 8: Install the OS. After the RAID array has been configured (see below) install the OS.
  • Page 202 PCISA-LX CPU Card Step 1: Select “Create RAID 0 Striping for Performance”. Use the arrow keys to highlight Create RAID0 Striping for Performance and press E . A flashing NTER ‘S’ appears on the Drive Menu where the member drives to be included in the RAID 0 array can be chosen.
  • Page 203 PCISA -LX CPU Card NOTE: 1. To reduce the chance of losing data, ALi imposes certain limitations on the RAID configuration options. PATA drives connected on the same IDE channel cannot be selected as the members of a RAID 0 array. Avoid mixing PATA and SATA disk drives in a RAID 0 array.
  • Page 204 PCISA-LX CPU Card E.4.2 Create RAID 1 Mirroring for Reliability WARNING! All data previously stored on the member drives of a RAID configuration is destroyed during the RAID initialization process. If “used” drives are used to create a RAID array, make sure the data has been moved or backed up before creating a RAID array out of the disk drives.
  • Page 205 PCISA -LX CPU Card NOTE: To reduce the chance of losing data, ALi imposes certain limitations on the RAID configuration options. PATA drives connected on the same IDE channel cannot be selected as the members of a RAID 1 array. Avoid mixing PATA and SATA disk drives in a RAID 1 array.
  • Page 206 PCISA-LX CPU Card WARNING! All data previously stored on the member drives of a RAID configuration is destroyed during the RAID initialization process. If “used” drives are used to create a RAID array, make sure the data has been moved or backed up before creating a RAID array out of the disk drives.
  • Page 207 PCISA -LX CPU Card E.4.4 Stripe Size Changing the stripe size effects RAID 0 arrays. Configurable options are: 64K (default) Select a small stripe size if the I/Os to the hard drives are small and occur randomly. Choose a larger stripe size if the I/Os are mostly large and come in sequential orders, e.g., A/V playback and editing applications.
  • Page 208 PCISA-LX CPU Card E.4.6 Delete All RAID Setting & Partition WARNING! If a RAID configuration is deleted, all data previously stored on the member drives of the RAID configuration will also be deleted. Step 1: Delete RAID Settings. Use the arrow keys to highlight Delete All RAID Setting &...
  • Page 209 PCISA -LX CPU Card NOTE: A status bar will indicate the rebuild progress. Rebuild consumes considerable system resources and the time required for rebuilding a RAID array may vary depending on the size of stored data, disk drive capacity, and drive performance.
  • Page 210 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 210 IEI ® Technology, Corp.

  • Page 211: Index

    PCISA -LX CPU Card Index Page 211...
  • Page 212 PCISA-LX CPU Card ® RAID ........197 IDE Connector ........51 AMD CS5536 ........19 Internal Peripheral Connectors ... 41 AMD Geode™ LX 800....16, 19 IO Address Map ........ 186 AMD LX 800........22 ISA Driver......... 138 AT Power Connector......41 AT Power Select Jumper .....
  • Page 213 PCISA -LX CPU Card Connector........62 RAID Options ........201 Realtek ALC203........ 190 Technical Specifications ..... 19 REALTEK ALC203 ......33 TTL ... 16, 18, 19, 40, 65, 66, 67, 83 Reset Button Connector ...... 58 RoHS........... 16 RS-232 Serial Port (COM1) Connector ............
  • Page 214 PCISA-LX CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK Page 214 IEI ® Technology, Corp.

Table of Contents
