PPC2-Cxxx-ADL Series Panel PC
MODEL:
MODEL:
PPC2-Cxxx-ADL Series
Series
Panel PC equips 12th Gen Intel® Core™ i9/i7/i5/i3 or
Pentium® Processor, Dual-Channel DDR4 SO-DIMM, One
M.2 E Key & One M.2 M Key Expansion Slots, SATA 6Gb/s,
IP 65 Compliant Front Panel and RoHS Compliant
Rev. 1.01 – August 15, 2023
e
User Manual
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC2-C ADL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology PPC2-C ADL Series

Summary of Contents for IEI Technology PPC2-C ADL Series

  • Page 1 PPC2-Cxxx-ADL Series Panel PC MODEL: MODEL: PPC2-Cxxx-ADL Series Series Panel PC equips 12th Gen Intel® Core™ i9/i7/i5/i3 or Pentium® Processor, Dual-Channel DDR4 SO-DIMM, One M.2 E Key & One M.2 M Key Expansion Slots, SATA 6Gb/s, IP 65 Compliant Front Panel and RoHS Compliant User Manual Page i Rev.
  • Page 2 PPC2-Cxxx-ADL Series Panel PC Revision Date Version Changes December 28, 2023 1.00 Initial release August 15, 2023 1.01 Update Spec, add BIOS chapter Page ii...
  • Page 3 PPC2-Cxxx-ADL Series Panel PC Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 PPC2-Cxxx-ADL Series Panel PC Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. Vorsicht! Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. Attention! La mise au rebut ou le recyclage de ce produit sont généralement soumis aux lois et/ou directives de respect de l'environnement.
  • Page 5 PPC2-Cxxx-ADL Series Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6 PPC2-Cxxx-ADL Series Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 7: Table Of Contents

    PPC2-Cxxx-ADL Series Panel PC Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................4 RONT ANEL 1.5 R ......................4 ANEL 1.6 B ......................
  • Page 8 PPC2-Cxxx-ADL Series Panel PC 3.10 M ..................29 OUNTING THE YSTEM 3.10.1 Wall Mounting ....................30 3.10.2 Panel and Rack Installation ................32 3.10.3 Arm Mounting ....................37 3.10.4 Stand Mounting ....................38 3.11 S ................. 39 ERIAL EVICE ONNECTION 3.11.1 RS-232 Serial Ports ..................
  • Page 9 PPC2-Cxxx-ADL Series Panel PC 5.3.1 Case Open Detection ..................58 5.3.2 CPU Configuration ..................58 5.3.3 Trusted Computing ................... 62 5.3.4 RTC Wake Settings ................... 63 5.3.5 F81966 Super IO Configuration ..............64 5.3.5.1 Serial Port 1 Configuration ............... 65 5.3.5.2 Serial Port 2 Configuration ...............
  • Page 10 PPC2-Cxxx-ADL Series Panel PC 6.2.4 Fan Connectors (CPU_FAN1/2, SYS_FAN1/2) ..........99 6.2.5 Mini SATA Connectors (CN1, CN2) ..............99 6.2.6 CPU Power Connector (CPU12V1) .............. 100 6.2.7 Debug Connector (DEBUG_SPI1) ..............100 6.2.8 DMC6000 Connector (DMC6000_CN1) ............100 6.2.9 EC Flash Connector (EC_SPI1) ..............100 6.2.10 I2C Connector (I2C1) ..................
  • Page 11 PPC2-Cxxx-ADL Series Panel PC List of BIOS BIOS Menu 1: Main (1/3) .......................54 BIOS Menu 2: Main (2/3) .......................54 BIOS Menu 3: Main (3/3) .......................55 BIOS Menu 4: Advanced ......................57 BIOS Menu 5: CPU Configuration (1/2)..................58 BIOS Menu 6: CPU Configuration (2/2)..................59 BIOS Menu 7: Trusted Computing Configuration ..............62 BIOS Menu 8: RTC Wake Settings ....................63 BIOS Menu 9: F81866 Super IO Configuration ................64...
  • Page 12 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 31: SATA Configuration ...................89 BIOS Menu 32: HD Audio Configuration ..................90 BIOS Menu 33: Security (1/2) .......................91 BIOS Menu 34: Security (2/2) .......................92 BIOS Menu 35: Boot ........................93 BIOS Menu 36: Save & Exit ......................94 Page xii...
  • Page 13 PPC2-Cxxx-ADL Series Panel PC List of Figures Figure 1-1: PPC-Cxxx-ADL Panel PC .................... 2 Figure 1-2: Front Panel ........................4 Figure 1-3: Rear View ........................4 Figure 1-4: Bottom Panel ....................... 5 Figure 1-5: PPC2-C15-ADL Dimensions (Unit: mm) ..............9 Figure 1-6: PPC2-CW15-ADL Dimensions (Unit: mm) ..............10 Figure 1-7: PPC2-C17-ADL Dimensions (Unit: mm) ..............11 Figure 1-8: PPC2-C19-ADL Dimensions (Unit: mm) ..............12...
  • Page 14 PPC2-Cxxx-ADL Series Panel PC Figure 3-22: Machine mounted to panel ..................35 Figure 3-23: Installation Panel Mount Kit ...................35 Figure 3-24: Tighten the Mounting Screws ................36 Figure 3-25: Install into a Rack ....................36 Figure 3-26: Arm Mounting Retention Screw Holes ..............37 Figure 3-27: Arm Mounting (ARM-11-RS) ...................38 Figure 3-28: Stand Mounting Retention Screw Holes ...............38 Figure 3-29: Stand Mounting .......................39...
  • Page 15 PPC2-Cxxx-ADL Series Panel PC List of Tables Table 1-1: Model Variations ......................3 Table 1-2: PPC2-C15/CW15/C17-ADL Specifications ..............6 Table 1-3: PPC2-CW19/C19/CW22-ADL Specifications .............. 8 Table 2-1: Package List ........................17 Table 2-2: Optional Items ......................18 Table 3-1: AT/ATX Mode Selection .....................29 Table 3-2: RS-232 Serial Port Pinouts ..................40 Table 3-3: RS-232/422/485 Serial Port (COM3) Pinouts ............40 Table 5-1: Peripheral Interface Connectors ................98...

  • Page 17: Introduction

    PPC2-Cxxx-ADL Series Panel PC Chapter Introduction Page 1...

  • Page 18: Overview

    PPC2-Cxxx-ADL Series Panel PC 1.1 Overview Figure 1-1: PPC-Cxxx-ADL Panel PC The PPC-Cxxx-ADL panel PC is powered by 12th Gen Intel® Core™ i9/i7/i5/i3 and Pentium® Processor. The PPC-Cxxx-ADL is a heavy industrial panel PC with rugged and trendy design which can be applied in harsh industrial environments and enriches aesthetic experience at the same time.

  • Page 19: Model Variations

    PPC2-Cxxx-ADL Series Panel PC 1.2 Model Variations The model variations of the PPC2-Cxxx-ADL Series panel PC series are listed below. Size Resolutions Processor Model 15" 1024x768 Intel ® Pentium ® Gold G7400 PPC2-C15-ADL-P/4G-R10 15" 1024x768 Intel ® Core™ i3-12100 PPC2-C15-ADL-i3/4G-R10 ®...

  • Page 20: Front Panel

    PPC2-Cxxx-ADL Series Panel PC Anti-glare and anti-UV touchscreen ◼ Support gloved and wet hand operation ◼ Supports dual 2.5G Ethernet port ◼ HDMI 2.0 display output ◼ RoHS compliant design ◼ 1.4 Front Panel The front side of the PPC-Cxxx-ADL (Figure 1-2) is a flat panel LCD touchscreen surrounded by an aluminum frame.

  • Page 21: Bottom Panel

    PPC2-Cxxx-ADL Series Panel PC 1.6 Bottom Panel An overview of the bottom panel is shown in Figure 1-4. Figure 1-4: Bottom Panel 1.7 Technical Specifications PPC2-C15-ADL PPC2-CW15-ADL PPC2-C17-ADL LCD Display 15” (4:3) 15.6” (16:9) 17” (5:4) Max. Resolution 1024 (W) x 768 (H) 1920 (W) x 1080 (H) 1280 (W) x 1024 (H) Brightness...

  • Page 22: Table 1-2: Ppc2-C15/Cw15/C17-Adl Specifications

    PPC2-Cxxx-ADL Series Panel PC LAN1: Intel® I225 + LAN2: Intel® I225 Ethernet 1 x PCIe Gen4 x16 Slot with x16 Signal (Only support single-slot expansion card, Maximum length: 169mm, power is limited to 70W or less) Expansion 1 x M.2 E-Key 2230 (PCIe Gen3 x1 + CNVIo + USB 2.0) 1 x M.2 M Key 2242/2280 NVMe (PCIe Gen3 x4) VESA 100mm x 100mm Mounting...
  • Page 23 PPC2-Cxxx-ADL Series Panel PC PPC2-CW19-ADL PPC2-C19-ADL PPC2-CW22-ADL LCD Display 18.5” (16:9) 19” (5:4) 21.5” (16:9) Max. Resolution 1920 (W) x 1080 (H) 1280 (W) x 1024 (H) 1920 (W) x 1080 (H) Brightness 400 cd/m² 350 cd/m² 350 cd/m² Contrast Ratio 1000:1 41.66736111 1000:1...

  • Page 24: Table 1-3: Ppc2-Cw19/C19/Cw22-Adl Specifications

    PPC2-Cxxx-ADL Series Panel PC Smart fan (2 x CPU fan, 2 x System fan) Thermal Solution Intel® Platform Trust Technology Watchdog Timer Software Programmable Support 1~255 sec. system reset Operating Temperature -10ºC ~ 60ºC -10ºC ~ 50ºC (with air flow) Storage Temperature -20ºC ~ 60ºC Humidity...

  • Page 25: Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8 Dimensions 1.8.1 PPC2-C15-ADL Dimensions Figure 1-5: PPC2-C15-ADL Dimensions (Unit: mm) Page 9...

  • Page 26: Ppc2-Cw15-Adl Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8.2 PPC2-CW15-ADL Dimensions Figure 1-6: PPC2-CW15-ADL Dimensions (Unit: mm) Page 10...

  • Page 27: Ppc2-C17-Adl Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8.3 PPC2-C17-ADL Dimensions Figure 1-7: PPC2-C17-ADL Dimensions (Unit: mm) Page 11...

  • Page 28: Ppc2-C19-Adl Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8.4 PPC2-C19-ADL Dimensions Figure 1-8: PPC2-C19-ADL Dimensions (Unit: mm) Page 12...

  • Page 29: Ppc2-Cw19-Adl Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8.5 PPC2-CW19-ADL Dimensions Figure 1-9: PPC2-CW19-ADL Dimensions (Unit: mm) Page 13...

  • Page 30: Ppc2-Cw22-Adl Dimensions

    PPC2-Cxxx-ADL Series Panel PC 1.8.6 PPC2-CW22-ADL Dimensions Figure 1-10: PPC2-CW22-ADL Dimensions (Unit: mm) Page 14...

  • Page 31: Unpacking

    PPC2-Cxxx-ADL Series Panel PC Chapter Unpacking Page 15...

  • Page 32: Unpacking

    PPC2-Cxxx-ADL Series Panel PC 2.1 Unpacking To unpack the panel PC, follow the steps below: WARNING! The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the panel PC has been properly installed. This ensures the screen is protected during the installation process.

  • Page 33: Packing List

    PPC2-Cxxx-ADL Series Panel PC 2.2 Packing List NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the PPC-Cxxx-ADL was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 34: Optional Items

    PPC2-Cxxx-ADL Series Panel PC 2.3 Optional Items The following items are optional accessories for the PPC-Cxxx-ADL: PPC2-C15/CW15/C17/C19/CW19/CW22-ADL Item Part No. Description ARM-31-RS VESA 75/100 desk arm Stand STAND-C19-R10 VESA 75/100 easy stand Wall AFLWK-19B Wall mounting kit WIN10-IOTE2019-H-RS Win10 IoT Ent LTSC 2019 MultiLang OEI High End Wi-Fi Kit EMB-WIFI-KIT02I3-R10 2T2R M.2 Wi-Fi module, Wi-Fi 6E &...

  • Page 35: Installation

    PPC2-Cxxx-ADL Series Panel PC Chapter Installation 3.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the maintenance of the PPC-Cxxx- ADL may result in permanent damage to the PPC-Cxxx-ADL and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the power module.

  • Page 36: Installation Precautions

    PPC2-Cxxx-ADL Series Panel PC 3.2 Installation Precautions During installation, be aware of the precautions below: Read the user manual: The user manual provides a complete description ◼ of the PPC-Cxxx-ADL, installation instructions and configuration options. DANGER! Disconnect Power: Power to the PPC-Cxxx-ADL must be ◼...

  • Page 37: Installation Procedure

    PPC2-Cxxx-ADL Series Panel PC Wi-Fi Kit ◼ 3.4 Installation Procedure To properly install the PPC-Cxxx-ADL, the following steps must be followed. Detailed descriptions of these instructions are listed in the sections that follow. Step 1: Unpacking the PPC-Cxxx-ADL panel PC Step 2: Install an SSD (if necessary).

  • Page 38: Figure 3-1: Ppc2-Cxxx-Adl Series Back Cover Retention Screws

    PPC2-Cxxx-ADL Series Panel PC Figure 3-1: PPC2-Cxxx-ADL Series Back Cover Retention Screws Page 22...

  • Page 39: Solid-State Drive Installation

    PPC2-Cxxx-ADL Series Panel PC 3.6 Solid-State Drive Installation One 2.5” SATA HDD drive can be installed in the PPC-Cxxx-ADL. To install the HDD into the system, please follow the steps below. Step 1: Remove the back cover see Figure 3-1. Step 2: Remove the three screws securing the hard drive bracket to remove the hard drive bracket.

  • Page 40: Figure 3-3: Hdd Retention Screws

    PPC2-Cxxx-ADL Series Panel PC Figure 3-3: HDD Retention Screws Step 4: Install the HDD and bracket back into the system. See Figure 3-4. Figure 3-4: Install the HDD and Bracket Step 5: Connect the SATA cable. See Figure 3-5. Figure 3-5: SATA Cable Step 6: Re-install the rear cover and secure it with screws.

  • Page 41: Dimm Installation (Optional)

    PPC2-Cxxx-ADL Series Panel PC 3.7 DIMM Installation (Optional) To install a DIMM, please follow the steps below and refer to Figure 3-7. Step 1: Remove the rear cover. See Section 3.5 above. Step 2: Locate the DIMM slots as shown in Figure 3-6. Figure 3-6: DIMM Slot Locations Step 3: Open the two handles outwards as far as they can.

  • Page 42: Installation (Optional)

    PPC2-Cxxx-ADL Series Panel PC Step 5: Once aligned, press down until the DIMM is properly seated. Clip the two handles into place. See Figure 3-7. Step 6: To remove a DIMM, push both handles outward. The memory module is ejected by a mechanism in the socket.

  • Page 43: Figure 3-9: Press The End Of The M.2 Retaining Clip

    PPC2-Cxxx-ADL Series Panel PC Figure 3-9: Press the End of The M.2 Retaining Clip Step 4: Insert M.2 card. The notch at the end of the M.2 card needs to be aligned with the notch of the fixed buckle (Figure 3-10). Figure 3-10: Insert M.2 Card Step 5: Secure the M.2 card.

  • Page 44: Figure 3-11: Securing The M.2 Card

    PPC2-Cxxx-ADL Series Panel PC Figure 3-11: Securing the M.2 Card Step 6: Re-install the rear cover. Page 28...

  • Page 45: At/Atx Mode Selection

    PPC2-Cxxx-ADL Series Panel PC 3.9 AT/ATX Mode Selection AT and ATX power modes can both be used on the PPC-Cxxx-ADL panel PC. The selection is made through an AT/ATX switch on the I/O interface panel. The system is set to ATX mode by default. The switch is shown below. Figure 3-12: AT/ATX Mode Selection AT/ATX Switch ATX (Default)

  • Page 46: Wall Mounting

    PPC2-Cxxx-ADL Series Panel PC Stand mounting The mounting methods are described in the following sections. 3.10.1 Wall Mounting To mount the PPC-Cxxx-ADL series panel PC onto a wall, please follow the steps below. Step 1: Select the location on the wall for the wall-mounting bracket. Step 2: Carefully mark the locations of the four bracket screw holes on the wall.

  • Page 47: Figure 3-14: Mount The Chassis

    PPC2-Cxxx-ADL Series Panel PC Step 8: Carefully insert the screws through the holes and gently pull the monitor downwards until the monitor rests securely in the slotted holes. Ensure that all four of the mounting screws fit snuggly into their respective slotted holes. NOTE: In the diagram below the bracket is already installed on the wall.

  • Page 48: Panel And Rack Installation

    PPC2-Cxxx-ADL Series Panel PC Figure 3-15: Secure the Chassis 3.10.2 Panel and Rack Installation To mount the PPC-Cxxx-ADL panel PC into a panel, please follow steps 1-5. For rack and cabinet installation, please follow Steps 1-7. NOTE: For the PPC-Cxxx-ADL panel PC, five mounting brackets must be installed (three along the bottom and one along each side).

  • Page 49: Figure 3-16: Ppc2-C15-Adl Panel Cutout Dimensions

    PPC2-Cxxx-ADL Series Panel PC Figure 3-16: PPC2-C15-ADL Panel Cutout Dimensions Figure 3-17: PPC2-CW15-ADL Panel Cutout Dimensions Figure 3-18: PPC2-C17-ADL Panel Cutout Dimensions Page 33...

  • Page 50: Figure 3-19: Ppc2-C19-Adl Panel Cutout Dimensions

    PPC2-Cxxx-ADL Series Panel PC Figure 3-19: PPC2-C19-ADL Panel Cutout Dimensions Figure 3-20: PPC2-CW19-ADL Panel Cutout Dimensions Figure 3-21: PPC2-CW22-ADL Panel Cutout Dimensions Page 34...

  • Page 51: Figure 3-22: Machine Mounted To Panel

    PPC2-Cxxx-ADL Series Panel PC Step 3: Slide the PPC2-Cxxx-ADL Series through the hole until the aluminum frame is flush against the panel (Figure 3-22). Figure 3-22: Machine mounted to panel Step 4: Insert the panel mount kit into the prefabricated holes along the rear edge of the PPC2-Cxxx-ADL series (Figure 3-23).

  • Page 52: Figure 3-24: Tighten The Mounting Screws

    PPC2-Cxxx-ADL Series Panel PC Figure 3-24: Tighten the Mounting Screws Step 6: Slide the PPC2-Cxxx-ADL series with the attached rack/cabinet bracket into a rack or cabinet (Figure 3-25). Figure 3-25: Install into a Rack Step 7: Once the flat panel PC with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-25).

  • Page 53: Arm Mounting

    PPC2-Cxxx-ADL Series Panel PC 3.10.3 Arm Mounting The PPC2-Cxxx-ADL Series is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 100 mm interface pad. To mount the PPC2-Cxxx- ADL Series on an arm, please follow the steps below. Step 1: The arm is a separately purchased item.

  • Page 54: Stand Mounting

    PPC2-Cxxx-ADL Series Panel PC Step 4: Secure the PPC2-Cxxx-ADL Series to the interface pad by inserting four retention screws through the mounting arm interface pad and into the PPC2- Cxxx-ADL Series panel PC. Figure 3-27: Arm Mounting (ARM-11-RS) 3.10.4 Stand Mounting To mount the PPC2-Cxxx-ADL Series using the stand mounting kit, please follow the steps below.

  • Page 55: Serial Device Connection

    PPC2-Cxxx-ADL Series Panel PC Step 2: Align the bracket with the screw holes. Step 3: To secure the bracket to the PPC2-Cxxx-ADL Series, insert the retention screws into the screw holes and tighten them. Figure 3-29: Stand Mounting 3.11 Serial Device Connection The PPC2-Cxxx-ADL Series has RS-232/422/484 and RS-232 ports.

  • Page 56: Rs-232/422/485 Serial Port

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 3-2: RS-232 Serial Port Pinouts 3.11.2 RS-232/422/485 Serial Port The pinouts of the RS-232/422/485 serial ports are listed in the following table. PIN NO. RS-232 RS-422 RS-485 TXD422- TXD485- TXD422+ TXD485+ RXD422+...

  • Page 57: Power-On Procedure

    PPC2-Cxxx-ADL Series Panel PC All peripheral devices are connected The system is securely mounted 3.12.2 Power-on Procedure To power-on the PPC2-Cxxx-ADL Series please follow the steps below: Step 1: Connect the power source to the power inlet on the bottom panel. Step 2: Press the power switch to power up the system.

  • Page 58: Software Installation

    PPC2-Cxxx-ADL Series Panel PC location is shown in Figure 3-33. Figure 3-33: Clear CMOS Button Location 3.15 Software Installation All the drivers for the PPC2-Cxxx-ADL Series are available on IEI Resource Download Center (https://download.ieiworld.com). Figure 3-34: IEI Resource Download Center 3.15.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below.
  • Page 59 PPC2-Cxxx-ADL Series Panel PC Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result. Step 3: Click the driver file name on the page and you will be prompted with the ...
  • Page 60 PPC2-Cxxx-ADL Series Panel PC NOTE: To install software from the downloaded ISO image file in Windows 10 or 11, double-click the ISO file to mount it as a virtual drive to view its content. Page 44...

  • Page 61: System Maintenance

    PPC2-Cxxx-ADL Series Panel PC Chapter System Maintenance Page 45...

  • Page 62: Adl System Maintenance Overview

    PPC2-Cxxx-ADL Series Panel PC WARNING: Take Anti-Static precautions whenever maintenance is being carried out on the system components. Failure to take anti-static precautions can cause permanent system damage. For more details on anti-static precautions, please refer to Section 3.1. 4.1 PPC-Cxxx-ADL System Maintenance Overview NOTE: When doing maintenance operations on the system, please follow the instructions in this chapter.

  • Page 63: The System Doesn't Boot Up

    PPC2-Cxxx-ADL Series Panel PC Step 4: Plug the system into a monitor and check to see if anything appears on the screen. If nothing is displayed, contact an IEI sales representative directly. 4.2.2 The System Doesn’t Boot Up If the system doesn’t boot up, please do the following: Step 1: Check the power is turned on.
  • Page 64 PPC2-Cxxx-ADL Series Panel PC Page 48...

  • Page 65: Bios

    PPC2-Cxxx-ADL Series Panel PC Chapter BIOS Page 49...

  • Page 66: Introduction

    PPC2-Cxxx-ADL Series Panel PC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 67: Using Setup

    PPC2-Cxxx-ADL Series Panel PC 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 5.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 5-1. Function Up arrow Move to previous item Down arrow Move to next item Left arrow...

  • Page 68: Touch Navigation

    PPC2-Cxxx-ADL Series Panel PC 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Load the factory default values in order to achieve Optimized Defaults the best performance. Back Return to the previous menu.

  • Page 69: Unable To Reboot After Configuration Changes

    PPC2-Cxxx-ADL Series Panel PC 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults. Use the clear CMOS button described in Chapter 3. 5.1.5 BIOS Menu Bar The menu bar on top of the BIOS screen has the following main items: ⚫...

  • Page 70: Main

    PPC2-Cxxx-ADL Series Panel PC 5.2 Main The Main BIOS menu (BIOS Menu 1 & BIOS Menu 2 & BIOS Menu 3) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/3) BIOS Menu 2: Main (2/3) Page 54...
  • Page 71 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 3: Main (3/3) ➔ BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include: ▪ BIOS Vendor: Installed BIOS vendor ▪...
  • Page 72 PPC2-Cxxx-ADL Series Panel PC ▪ Name: Displays the Processor Details ▪ Type: Displays the Processor Type ▪ Speed: Displays the Processor Speed ▪ ID: Displays the Processor ID ▪ Stepping: Displays the Processor Stepping Package: Displays the Processor Package ▪ Number of Efficient-cores: Displays number of Efficient-cores cores ▪...

  • Page 73: Advanced

    PPC2-Cxxx-ADL Series Panel PC Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 4) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction.

  • Page 74: Case Open Detection

    PPC2-Cxxx-ADL Series Panel PC 5.3.1 Case Open Detection ➔ Case Open Detection [Disabled] When the Case Open Detection is enabled, if anyone opens the computer's chassis, or case, Windows will notify the user with a pop-up message the next time he turns on his computer.
  • Page 75 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 6: CPU Configuration (2/2) ➔ Intel (VMX) Virtualization Technology [Enabled] Use the Intel (VMX) Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.
  • Page 76 PPC2-Cxxx-ADL Series Panel PC ➔ Active Efficient Cores [All] Use the Active Efficient Cores BIOS option to enable numbers of E-cores in the processor package. ➔ Enable all E-cores in the processor package. EFAULT ➔ Enable zero E-core in the processor package. ➔...
  • Page 77 PPC2-Cxxx-ADL Series Panel PC ➔ C states [Disabled] Use the C states option to enable or disable CPU power management which allows CPU to go to C states when it is not 100% utilized. ➔ Disabled EFAULT Disables CPU power management ➔...

  • Page 78: Trusted Computing

    PPC2-Cxxx-ADL Series Panel PC 5.3.3 Trusted Computing Use the Trusted Computing menu (BIOS Menu 7)to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 7: Trusted Computing Configuration ➔ Security Device Support [Enable] Use the Security Device Support option to enable or disable BIOS support for security device.

  • Page 79: Rtc Wake Settings

    PPC2-Cxxx-ADL Series Panel PC 5.3.4 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 8) configures RTC wake event. BIOS Menu 8: RTC Wake Settings Wake system with Fixed Time [Enabled] ➔ Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event.

  • Page 80: F81966 Super Io Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5 F81966 Super IO Configuration Use the F81966 Super IO Configuration menu (BIOS Menu 9) to set or change the configurations for serial ports. BIOS Menu 9: F81866 Super IO Configuration Page 64...

  • Page 81: Serial Port 1 Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 10) to configure the serial port. BIOS Menu 10: Serial Port 1 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 82: Serial Port 2 Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 11) to configure the serial port. BIOS Menu 11: Serial Port 2 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 83: Serial Port 3 Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5.3 Serial Port 3 Configuration Use the Serial Port 3 Configuration menu (BIOS Menu 12) to configure the serial port. BIOS Menu 12: Serial Port 3 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 84: Serial Port 4 Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5.4 Serial Port 4 Configuration Use the Serial Port 4 Configuration menu (BIOS Menu 13) to configure the serial port. BIOS Menu 13: Serial Port 4 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 85: Serial Port 5 Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.5.5 Serial Port 5 Configuration Use the Serial Port 5 Configuration menu (BIOS Menu 14) to configure the serial port. BIOS Menu 14: Serial Port 5 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 86: Ec Kb9068 H/W Monitor

    PPC2-Cxxx-ADL Series Panel PC RS422 The serial port mode is RS-422 RS485 The serial port mode is RS-485 5.3.6 EC KB9068 H/W Monitor The EC KB9068 H/W Monitor menu (BIOS Menu 15 & BIOS Menu 16) contains the smart fan mode configuration submenu and shows the state of H/W real-time operating temperature, fan speeds and system voltages.
  • Page 87 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 16: EC KB9068 H/W Monitor (2/2) ➔ PC Health Status The following system parameters and values are shown. The system parameters that are monitored are: ▪ System Temperatures: CPU Temperature System Temperature1 System Temperature2 ▪...

  • Page 88: Smart Fan Mode Configuration

    PPC2-Cxxx-ADL Series Panel PC +DC_IN +3.3VSB ➔ Tcc Activation Offset [0] Offset from factory set Tcc activation temperature at which the Thermal Control Circuit must be activated. Tcc will be activated at: Tcc Activation Temp-Tcc Activation Offset.Tcc Activation Offset range is 0 to 63. 5.3.6.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu ( BIOS Menu...
  • Page 89 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 18: Smart Fan Mode Configuration (2/2) CPU_FAN Smart Fan Control [Auto Mode] ➔ Use the CPU_FAN Smart Fan Control option to configure the CPU Smart Fan. ➔ Manual Mode The fan spins at the speed set in Manual Mode settings.
  • Page 90 PPC2-Cxxx-ADL Series Panel PC ➔ CPU_FAN Start PWM Use the CPU_FAN Start PWM option to set the PWM start value. Use the + or – key to change the value or enter a decimal number between 1 and 100. ➔ SYS_FAN1 Smart Fan Control [Auto Mode] Use the SYS_FAN1 Smart Fan Control option to configure the System Smart Fan.

  • Page 91: Serial Port Console Redirection

    PPC2-Cxxx-ADL Series Panel PC 5.3.7 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 19 & BIOS Menu 20) allows the console redirection options to be configured. Console Redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port. BIOS Menu 19: Serial Port Console Redirection (1/2) Page 75...

  • Page 92: Console Redirection Settings

    PPC2-Cxxx-ADL Series Panel PC BIOS Menu 20: Serial Port Console Redirection (2/2) ➔ Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function. ➔ Disabled Disabled the console redirection function EFAULT ➔ Enabled Enabled the console redirection function The Console Redirection Settings submenu will be available when the Console Redirection option is enabled.
  • Page 93 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 21: COM Console Redirection Settings ➔ Terminal Type [ANSI] Use the Terminal Type option to specify the remote terminal type. ➔ VT100 The target terminal type is VT100 ➔ VT100+ The target terminal type is VT100+ ➔...
  • Page 94 PPC2-Cxxx-ADL Series Panel PC ➔ 57600 Sets the serial port transmission speed at 57600. ➔ 115200 Sets the serial port transmission speed at 115200. EFAULT ➔ Data Bits [8] Use the Data Bits option to specify the number of data bits. ➔...

  • Page 95: Nvme Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.3.8 NVMe Configuration BIOS Menu 22 Use the NVMe Configuration ( ) menu to display the NVMe controller and device information. BIOS Menu 22: NVMe Configuration Page 79...

  • Page 96: Chipset

    PPC2-Cxxx-ADL Series Panel PC 5.4 Chipset Use the Chipset menu (BIOS Menu 23) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 23: Chipset Page 80...

  • Page 97: System Agent (Sa) Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 24) to configure the System Agent (SA) parameters. BIOS Menu 24: System Agent (SA) Configuration ➔ VT-d [Enabled] Use the VT-d option to enable or disable the VT-d capability. ➔...

  • Page 98: Memory Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 25) to view memory information. BIOS Menu 25: Memory Configuration 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 26) menu to configure the video device connected to the system.
  • Page 99 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 26: Graphics Configuration ➔ Primary Display [Auto] Use the Primary Display option to select the primary graphics controller the system uses. The following options are available: Auto Default IGFX ➔ Internal Graphics [Enabled] Use the Internal Graphics option to configure whether to keep IGFX enabled. If user wants to support dual display by internal graphics and external graphics, this Internal Graphics Page 83...
  • Page 100 PPC2-Cxxx-ADL Series Panel PC option should be set to Enabled and the above Primary Display option should be set to IGFX. ➔ Auto Auto mode ➔ Disabled Disables IGFX. ➔ Enabled Default Enables IGFX. ➔ DVMT Pre-Allocated [160M] Use the DVMT Pre-Allocated option to set the amount of system memory allocated to the integrated graphics processor when the system boots.

  • Page 101: Pch-Io Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 27) to configure the PCH parameters. BIOS Menu 27: PCH-IO Configuration ➔ Auto Power Button Function [Disabled (AT)] Use the Auto Power Button Function BIOS option to show the power mode state. Use the J_ATX_AT1 to switch the AT/ATX power mode.

  • Page 102: Pci Express Configuration

    PPC2-Cxxx-ADL Series Panel PC USB Power SW1(LAN1/LAN2_USB1B) [+5VDUAL] Use the USB Power SW1 to enable or disable the USB Power. +5VDUAL means keep USB port’s power when S5. +5V means USB Port no power when S5. ➔ +5VDUAL keep USB port’s power when S5. EFAULT ➔...

  • Page 103: Pcie Root Port Setting

    PPC2-Cxxx-ADL Series Panel PC BIOS Menu 29: PCI Express Configuration (2/2) 5.4.2.1.1 PCIe Root Port Setting Use the M2_M(x4), M2_A submenu (BIOS Menu 30) to configure the PCI Root Port Setting. Page 87...
  • Page 104 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 30: PCIe Slot Configuration Submenu PCIe Speed [Auto] Use the PCIe Speed option to specify the PCI Express port speed. Configuration options are listed below. ➔ Auto Auto mode. EFAULT ➔ Gen1 Configure PCIe Speed to Gen1. ➔...

  • Page 105: Sata Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 31) to change and/or set the configuration of the SATA devices installed in the system. BIOS Menu 31: SATA Configuration SATA Mode Selection [AHCI] Use the SATA Mode Selection option to determine how the SATA devices operate. ➔...

  • Page 106: Hd Audio Configuration

    PPC2-Cxxx-ADL Series Panel PC 5.4.2.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 32) to configure the PCH Azalia settings. BIOS Menu 32: HD Audio Configuration HD Audio [Enabled] Use the HD Audio option to enable or disable the High Definition Audio controller. ➔...

  • Page 107: Security

    PPC2-Cxxx-ADL Series Panel PC 5.5 Security Use the Security menu (BIOS Menu 33 & BIOS Menu 34) to set system and user passwords. BIOS Menu 33: Security (1/2) Page 91...
  • Page 108 PPC2-Cxxx-ADL Series Panel PC BIOS Menu 34: Security (2/2) Administrator Password Use the Administrator Password to set or change an administrator password. User Password Use the User Password to set or change a user password. Page 92...

  • Page 109: Boot

    PPC2-Cxxx-ADL Series Panel PC 5.6 Boot Use the Boot menu (BIOS Menu 35) to configure system boot options. BIOS Menu 35: Boot 5.6.1 Boot Configuration Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. ➔...

  • Page 110: Save & Exit

    PPC2-Cxxx-ADL Series Panel PC 5.7 Save & Exit Use the Save & Exit menu (BIOS Menu 36) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 36: Save & Exit Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.
  • Page 111 PPC2-Cxxx-ADL Series Panel PC Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options. Page 95...

  • Page 112: Interface Connectors

    PPC2-Cxxx-ADL Series Panel PC Chapter Interface Connectors Page 96...

  • Page 113: Peripheral Interface Connectors

    PPC2-Cxxx-ADL Series Panel PC 6.1 Peripheral Interface Connectors The PPC2-Cxxx-ADL Series panel PC motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 6-1&Figure 6-2, The connector pinouts for these connectors are listed in the following sections.

  • Page 114: Internal Peripheral Connectors

    PPC2-Cxxx-ADL Series Panel PC 6.2 Internal Peripheral Connectors Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the PPC2-Cxx-ADL Panel PC motherboard. Pinouts of these connectors can be found in the following sections.

  • Page 115: Battery Connector (Bat1)

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION PS_ON PWR_OK SB5V +12V +12V +3.3V Table 6-2: ATX Power Source Connector (ATX1) Pinouts 6.2.2 Battery Connector (BAT1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V Table 6-3: Battery Connector (BAT1) Pinouts 6.2.3 Chassis Intrusion (CHASSIS1) PIN NO.

  • Page 116: Cpu Power Connector (Cpu12V1)

    PPC2-Cxxx-ADL Series Panel PC SATA_RX5+ SATA_RX5- +V5S +V5S SATA_TX5- +V5S SATA_TX5+ +V5S Table 6-6: Mini SATA Connectors (CN1, CN2) Pinouts 6.2.6 CPU Power Connector (CPU12V1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V Table 6-7: CPU Power Connector (CPU12V1) Pinouts 6.2.7 Debug Connector (DEBUG_SPI1) PIN NO.

  • Page 117: I2C Connector (I2C1)

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_MISO DET_FLASH SPI_CLK SPI_MOSI Table 6-10: EC Flash Connector (EC_SPI1) Pinouts 6.2.10 I2C Connector (I2C1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V5S Table 6-11: I2C Connector (I2C1) Pinouts 6.2.11 IDPM Slot (IDPM1) PIN NO.

  • Page 118: Me Flash Connector (Flash1)

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDP_TX0_DN EDP_BKLT_CTRL EDP_TX0_DP EC_EDP_BKLT_EN EC_EDP_VDD_EN EDP_AUX_DN EDP_HPD_R EDP_AUX_DP PLT_RST_N LVDS_EN +V5S +V5S +V5S +V5S +V12S +V12S +V12S +V12S Table 6-12: IDPM Slot (IDPM1) Pinouts 6.2.12 ME Flash Connector (FLASH1) PIN NO. DESCRIPTION Open = Disabled (No override) Default Short = Enabled (OVERIDE)

  • Page 119: A-Key Slot (Ngff4)

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_TX_DN3 PCIE_TX_DP3 PCIE_2_RX_DN PCIE_2_RX_DP PCIE_TX_DN2 PCIE_TX_DP2 M_1_SSD_SLP PCIE_1_RX_DN PCIE_1_RX_DP PCIE_TX_DN1 PCIE_TX_DP1 PLT_RST_N SRCCLKREQB_13_N PCIE_CLK_DN13 PCIE_CLK_DP13 Module Key +V3P3S_SSD +V3P3S_SSD +V3P3S_SSD Table 6-14: M.2 M-KEY Slot (NGFF1) Pinouts 6.2.14 M.2 A-Key Slot (NGFF4) PIN NO.

  • Page 120: Sata 6Gb/S Connector (S_Ata1)

    PPC2-Cxxx-ADL Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION CLKREQ_CNV# CNV_RXN0 BT_LED CNV_RXP0 CLK_CNV_RXN CNV_BRI_RX CLK_CNV_RXP CNV_RGI_TX CNV_RGI_RX PCIE_5_RX_DP CNV_BRI_TX PCIE_5_RX_DN CL_RST# CL_DATA PCIE_TX_DP5 CL_CLK PCIE_TX_DN5 PCIE_CLK_DP16 PCIE_CLK_DN16 SUSCLK PLT_RST_N SRCCLKREQB_15# BT_ON PCH_WAKE_N WLAN_OFF CNV_TXN1 CNV_TXP1 CNV_TXN0 CNV_TXP0 CLK_CNV_TXN +V3.3_M2 CLK_CNV_TXP +V3.3_M2...

  • Page 121: Sata Power Connector (Sata_Pwr1)

    PPC2-Cxxx-ADL Series Panel PC SATA_TX+ SATA RX+ SATA_TX- Table 6-16 : SATA 6Gb/s Connector (S_ATA1) Pinouts 6.2.16 SATA Power Connector (SATA_PWR1) PIN NO. DESCRIPTION Table 6-17: SATA Power Connector (SATA_PWR1) Pinouts 6.2.17 Touch Panel Connector (TOUCH_USB1) PIN NO. DESCRIPTION +V5S USB2_DM14_L USB2_DP14_L Table 6-18: Touch Panel Connector (TOUCH_USB1) Pinouts...

  • Page 122: Vr Power Debug Connector (J1)

    PPC2-Cxxx-ADL Series Panel PC 6.2.20 VR Power Debug Connector (J1) PIN NO. DESCRIPTION MP2960_SCL MP2960_SDA MP2940_SCL MP2940_SDA Table 6-21: VR Power IC Debug Connector (J1) Pinouts 6.2.21 Power Button Connector (JP2) PIN NO. DESCRIPTION Table 6-22: Power Button Connector (JP2) Pinouts 6.2.22 HDD LED Connector (JP3) PIN NO.

  • Page 123: A Regulatory Compliance

    PPC2-Cxxx-ADL Series Panel PC Appendix Regulatory Compliance Page 107...
  • Page 124 PPC2-Cxxx-ADL Series Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2014/30/EU) ◼ Low-Voltage Directive (2014/35/EU) ◼ RoHS II Directive (2011/65/EU, 2015/863/EU) ◼ If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 125 PPC2-Cxxx-ADL Series Panel PC Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2014/53/EU. Français [French] IEI Integration Corp déclare que l'appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2014/53/EU. Italiano [Italian] IEI Integration Corp dichiara che questo apparecchio è...
  • Page 126 PPC2-Cxxx-ADL Series Panel PC Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU. Slovensky [Slovak] IEI Integration Corp týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EU. Suomi [Finnish] IEI Integration Corp vakuuttaa täten että...
  • Page 127 PPC2-Cxxx-ADL Series Panel PC FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and ◼ This device must accept any interference received, including interference ◼...

  • Page 128: B Safety Precautions

    PPC2-Cxxx-ADL Series Panel PC Appendix Safety Precautions Page 112...

  • Page 129: Safety Precautions

    PPC2-Cxxx-ADL Series Panel PC WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the PPC-Cxxx-ADL. B.1.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times.

  • Page 130: Anti-Static Precautions

    PPC2-Cxxx-ADL Series Panel PC ◼ DO NOT: Drop the device against a hard surface. In a site where the ambient temperature exceeds the rated temperature B.1.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the PPC-Cxxx- ADL may result in permanent damage to the PPC-Cxxx-ADL and severe injury to the user.

  • Page 131: Product Disposal

    PPC2-Cxxx-ADL Series Panel PC B.1.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 132: Maintenance And Cleaning

    PPC2-Cxxx-ADL Series Panel PC WARNING: For safety reasons, turn-off the power and unplug the panel PC before cleaning. If you dropped any material or liquid such as water onto the panel PC when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center.
  • Page 133 PPC2-Cxxx-ADL Series Panel PC ◼ Vacuum cleaner–Using a vacuum specifically designed for computers is one of the best methods of cleaning the device. Dust and dirt can restrict the airflow in the device and cause its circuitry to corrode. ◼ Cotton swabs–Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas.

  • Page 134: C Watchdog Timer

    PPC2-Cxxx-ADL Series Panel PC Appendix Watchdog Timer Page 118...
  • Page 135 PPC2-Cxxx-ADL Series Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 136 PPC2-Cxxx-ADL Series Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 137: D Hazardous Materials Disclosure

    PPC2-Cxxx-ADL Series Panel PC Appendix Hazardous Materials Disclosure Page 121...

  • Page 138: Rohs Ii Directive (2015/863/Eu)

    PPC2-Cxxx-ADL Series Panel PC D.1.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 139: China Rohs

    PPC2-Cxxx-ADL Series Panel PC D.1.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 123...

This manual is also suitable for:

Ppc2-cw19-adlPpc2-c19-adlPpc2-cw22-adlPpc2-c15-adlPpc2-cw15-adlPpc2-c17-adl

Table of Contents
