MGC-25 Getting Started Guide
2-4

System Idle Display

When there are no actions being performed via the LCD Display or no alarms
detected, the following information is displayed:
Product Name
•
IP Address
•
Configuration Name
•
Active Alarms Status
•
This display is shown whenever there have not been any actions performed
via the LCD Display for 30 seconds.

Main Menu

To access the Main Menu from the System Idle display, press any button.
The Main Menu in the LCD window includes four options:
Active Alarms - displays network and system errors, if any
•
Net Status - displays the status of each network connection
•
IP Configuration - displays the IP address, Subnet Mask and Default
•
Gateway addresses. You can configure these values.
System Reset - resets the system
•
To access an option, scroll with the up/down (
option is selected, and then press the Select ( ) button.
/ ) buttons until the desired
