Supply Display Leds; Ethernet/Switch Diagnostic Leds - Fronius Profinet Robacta TX Operating Instructions Manual

Error code Reason
4 pulses
5 pulses
6 pulses
14 pulses
15 pulses
16 pulses
Supply display
LED
LEDs
Left LED off
Right LED off
Ethernet/Switch
LED
diagnostic LEDs
Link/Act
10 / 100 MBaud
28
Cause
for error
0 pulses Communication bus data er-
ror, break behind the bus cou-
pler
n pulses Break behind bus terminal n
n pulses Communication bus error
during register communication
with bus terminal n
0 pulses Initialization error
1 pulse Internal data error
4 pulses DIP switch incorrect for BootP Set 1-8 to the -Off- position
8 pulses Internal data error
16 pulses IP socket error
n pulses nth bus terminal has an incor-
rect format
n pulses Number of bus terminals no
longer matches
n pulses Length of communication bus
data no longer matches
Meaning
No power to bus coupler
No + 24 V power supply connected to the power contacts
DC
On
Physical connection
available
100 MBaud
Remedy
Check whether or not the n+1
bus terminal is inserted cor-
rectly, replace if necessary
Check whether or not the 9010
bus terminal is inserted
Replace nth bus terminal
Replace bus coupler
Turn bus coupler off/on
Turn bus coupler off/on
Turn bus coupler off/on
Restart bus coupler. If the er-
ror reoccurs, replace the bus
terminal.
Restart bus coupler. If the er-
ror reoccurs, reset the factory
settings using the KS2000
configuration software.
Restart bus coupler. If the er-
ror reoccurs, reset the factory
settings using the KS2000
configuration software.
Flashing Off
Communication No physical connection
available available
- 100 MBaud
