Serial no. Signal designation
A03 Cleaning motor up
A04 Cut wire
A05 Robacta TX cover valve 1
A06 Robacta TX cover valve 2
A07 'C-Act. 3' signal 1
A08 Not used
A09 Change torch neck valve 1 Activates the torch neck change
A10 Reserve relay OUT
A11 Not used
A12 Not used
A13 Not used
A14 Not used
A15 Not used
A16 Not used
Signal description
Signal available as an option.
"Cleaning motor up " signal only for Robacta
Reamer V:
- Activates the upward movement of the
cleaning motor
Signal available as an option.
- Activates the wire cutter
Signal available as an option.
- Opens and closes a Robacta TX cover
Signal available as an option.
- Opens and closes a Robacta TX cover
Reserve signal for actuator
-
Reserve signal for actuator (relay contact)
-
-
-
-
-
-
