1.1

Introduction

The IntelliPAX is a panel mounted, multi-place intercom expansion unit used to add up to six extra
stations to an intercom system. Please read this manual completely before installation to minimize the risk
of damage to the unit and to become familiar with all the features.
1.2

Scope

This manual contains installation and operational instructions for the following PS Engineering units:
IntelliPAX Part
Number
11606
11606R
11616
11616R
11636R
11636R
11636R
11636R
11636R
1.3

Description

The IntelliPAX (11616 series) is an intercom expansion unit that works with the PM1000II and PM1200
intercoms while the 11636 series works with the PMA8000E and PAC45A. These expansion units contain
PS Engineering's proprietary intercom protocol, IntelliVox®. This system a patented technique that
provides automatic VOX for each of the six individual microphones, eliminating manual squelch
adjustments. Because of the automatic squelch, the unit can be blind mounted.
The "R" designates the remote mounted version.
Part number 11636R is intended to function with PMA8000E.
The part number "R" version is designed for remote, or blind mounting.
1.4 Approval Basis **NONE**
None. It is the installer's responsibility to determine the applicable approval basis for this installation. This
unit is not designed for use in any flight crew situations, and has no effect on any critical aircraft systems.
There is no significant weight or electrical load presented to the aircraft.
200-250-0006
Section I – General Information
Description
Panel Mount Expansion
Remote Mount Expansion
Panel Mount Expansion
Remote Mount Expansion
Remote Mount Expansion
Remote Mount Expansion
Remote Mount Expansion
Remote Mount Expansion
Remote Mount Expansion
Page
Application
Model Number Application Part Number
PAC24 050-240-0100/ 0400/ 0500
PAC24 050-240-0100/ 0400/ 0500
PM1000II
PM1000II
PMA8000C
050-890-0414 /-0417
PMA8000E 050-890-0514 /-0517
PMA8000G
PAR200B
HUB45A
1-1
11922
11922
050-890-0313
050-890-0914
050-890-0918
050-228-0302
050-045-1001
Rev. 1, Sept. 2022
