PS Engineering, Inc. IntelliPAX Expansion Unit the Publications Manager at PS Engineering, Inc., 9800 Martel Road, Lenoir City, TN 37772. Phone (865) 988-9800 www.ps-engineering.com Table of Contents SECTION I – GENERAL INFORMATION NTRODUCTION COPE ESCRIPTION PPROVAL ASIS PECIFICATIONS QUIPMENT REQUIRED BUT NOT SUPPLIED SECTION II –...
Please read this manual completely before installation to minimize the risk of damage to the unit and to become familiar with all the features. Scope This manual contains installation and operational instructions for the following PS Engineering units: Model Description...
PS Engineering, Inc. IntelliPAX Expansion Unit Specifications Input power: from main unit Headphone Impedance: 150-1000 typical Audio Distortion: <10% @ 35 mW into 150 load Aircraft Radio Impedance: 1000 typical 3 dB Mic Frequency Response: 350 Hz — 6000 Hz...
PS Engineering, Inc. IntelliPAX Expansion Unit Section II – Installation General Information The IntelliPAX comes with all necessary hardware for a typical installation. The unit is installed either in the panel (11606, 11616, 11626) or mounted blindly (11606R, 11616R or 11626R). If panel mounted, it can be installed near the main unit, or near the passengers.
Cable harness wiring To complete the installation, a wire harness must be made as shown in Appendix C. PS Engineering can make a custom-tailored wiring harness for the installer. All harnesses use Mil-spec quality components with professional techniques, and are fully tested before shipment.
After wiring is complete, verify power is ONLY on pin 1 of the connector, and ground on pin 14 (with main unit operating. Failure to do so will cause serious internal damage and void PS Engineering's warranty. With all units plugged in and operating, verify that all active stations can communicate on the intercom, and that any music sources are present, and the SoftMute inhibit control operates correctly (if installed).
It is also a good idea to keep the microphone out of a direct wind path. Moving your head through a vent air stream may cause the IntelliVox® to open momentarily. This is normal. PS Engineering, Inc. recommends installation of a Microphone Muff Kit from Oregon Aero (1-800-888- 6910). This will optimize IntelliVox® performance.
In order for the factory warranty to be valid, the installations in a certified aircraft must be accomplished by a FAA- certified avionics shop and authorized PS Engineering dealer. If the unit is being installed by a non-certified individual in an experimental aircraft, a factory-made harness must be used for the warranty to be valid.
Aircraft equipment list, weight and balance amended. Compass compensation checked. A copy of the operation instructions, contained in PS Engineering document 200-250-( ), revision ( ), Dated ( ), is placed in the aircraft records. All work accomplished listed on Work Order...
Page 11
PS Engineering, Inc. IntelliPAX Expansion Unit Appendix B Installation 5.480 Ø0.136 4.000 3.500 4.725 Figure 6-1 Remote unit outline 200-250-0005 Page Rev. 14, Jan. 2012...
Page 12
PS Engineering, Inc. IntelliPAX Expansion Unit Appendix C Wiring Information PAC24 PM1000 PMA7000 Series IntelliPAX Unit has Female Sub-D DB-25 Standard PM1200 Series Expansion Power In Expansion Power Expansion Audio In (R) Audio (R) from Main Unit Expansion Audio In (L)
Page 13
PS Engineering, Inc. IntelliPAX Expansion Unit PMA8000E Dual Audio Panel Expansion Pilot Audio Panel Copilot Audio Expansion Audio Input Panel Expansion Lo Expansion Power Expansion Unit #1 11636 Copilot Panel Ground Lug Expansion Audio Output (L) Expansion Audio Output (R)
