PS Engineering IntelliPAX 11616R Installation And Operation Manual

Intercom expansion unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
9800 Martel Road
Lenoir City, TN 37772
IntelliPAX
Intercom Expansion Unit
Unit Part Numbers
11616, 11616R
for use with intercom systems
11636R
for use with PAR200B, PMA8000C, PMA8000G, PMA8000E &
PAC45A
Passenger Intercom System
With IntelliVox®
Installation and Operation Manual
US Patent No. 6,493,450
Document P/N 200-250-0006
Rev. 1, Sept. 2022
PS Engineering, Inc. 2022 ©
Copyright Notice
Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engineering, Inc.
is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Martel Road, Lenoir City, TN
37772. Phone (865) 988-9800 www.ps-engineering.com
i
200-250-0006
Page
Rev. 1, Sept. 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliPAX 11616R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PS Engineering IntelliPAX 11616R

Summary of Contents for PS Engineering IntelliPAX 11616R

  • Page 1 Copyright Notice Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engineering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Martel Road, Lenoir City, TN 37772.

  • Page 2: Table Of Contents

    Table of Contents SECTION I – GENERAL INFORMATION NTRODUCTION COPE ESCRIPTION PPROVAL ASIS PECIFICATIONS QUIPMENT REQUIRED BUT NOT SUPPLIED SECTION II – INSTALLATION ENERAL NFORMATION NPACKING AND PRELIMINARY INSPECTION QUIPMENT INSTALLATION PROCEDURES ABLE HARNESS WIRING 2.4.1 LECTRICAL OISE SSUES 2.4.2 OWER EQUIREMENTS 2.4.3...

  • Page 3: Section I - General Information

    Please read this manual completely before installation to minimize the risk of damage to the unit and to become familiar with all the features. Scope This manual contains installation and operational instructions for the following PS Engineering units: IntelliPAX Part Application...

  • Page 4: Specifications

    Specifications Input power: from main unit 150-1000  typical Headphone Impedance: <10% @ 35 mW into 150  load Audio Distortion: 1000  typical Aircraft Radio Impedance: 350 Hz — 6000 Hz 3 dB Mic Frequency Response: 3 dB Music Frequency Response: 200 Hz to 15 kHz Unit weight: 7.2 Ounces (0.20 kg)

  • Page 5: Section Ii - Installation

    Section II – Installation General Information The IntelliPAX comes with all necessary hardware for a typical installation. The unit is installed either in the panel (11606, 11616, 11626) or mounted blindly (11606R, 11616R, 11626R, 11636R or 11645). If panel mounted, it can be installed near the main unit, or near the passengers. If blind mounted, it can be mounted nearly anywhere.

  • Page 6: Equipment Installation Procedures

    Cable harness wiring To complete the installation, a wire harness must be made as shown in Appendix C. PS Engineering can make a custom-tailored wiring harness for the installer. All harnesses use Mil-spec quality components with professional techniques, and are fully tested before shipment.

  • Page 7: Power Requirements

    After wiring is complete, verify power is ONLY on pin 1 of the connector, and ground on pin 14 (with main unit operating. Failure to do so will cause serious internal damage and void PS Engineering's warranty. With all units plugged in and operating, verify that all active stations can communicate on the intercom, and that any music sources are present, and the SoftMute inhibit control operates correctly (if installed).

  • Page 8: Section Iii - Operation

    It is also a good idea to keep the microphone out of a direct wind path. Moving your head through a vent air stream may cause the IntelliVox® to open momentarily. This is normal. PS Engineering, Inc. recommends installation of a Microphone Muff Kit from Oregon Aero (1-800-888- 6910). This will optimize IntelliVox® performance.

  • Page 9: Section Iv Warranty And Service

    PS Engineering, Inc. warrants this product to be free from defect in material and workmanship for a period of one year from the date of sale. During this one-year warranty period, PS Engineering, Inc., at its option, will send a replacement unit at our expense if the unit should be determined to be defective after consultation with a factory technician.

  • Page 10: Appendix A Instructions For Faa Form 337 And Airworthinessa

    Aircraft equipment list, weight and balance amended. Compass compensation checked. A copy of the operation instructions, contained in PS Engineering document 200-250-( ), revision ( ), Dated ( ), is placed in the aircraft records. All work accomplished listed on Work Order...
  • Page 11 Appendix B Installation 5.480 Ø0.136 4.000 3.500 4.725 200-250-0006 Page Rev. 1, Sept. 2022...
  • Page 12 Appendix C Wiring Information PM1000 IntelliPAX Unit has Female Sub-D DB-25 PM1200 Series Expansion Power In Expansion Power Expansion Audio In (R) Audio (R) from Main Unit Expansion Audio In (L) Audio (L) from Main Unit Expansion Audio Output Audio to Main Unit Expansion Ground Expansion Ground See unit Installation manual...
  • Page 13 PMA8000C IntelliPAX Unit has Female Sub-D DB-25 PMA8000E Expansion Power In Expansion Power J2-41 Expansion Audio In (R) J1-41 Audio (R) from Main Unit Expansion Audio In (L) Audio (L) from Main Unit J1-40 Expansion Audio Output J2-37 Audio to Main Unit Expansion Ground Expansion Ground J2-38...
