Chapter 4: BIOS Setup
IDE Configuration
This section is used to configure the SATA drives.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
IDE Configuration
Serial-ATA (SATA) [Enabled]
SATA Speed Support [Gen2]
SATA Mode [IDE Mode]
[Enabled]
Serial-ATA Port 0
SATA Port0 HotPlug [Disabled]
Serial-ATA Port 1 [Enabled]
[Disabled]
SATA Port1 HotPlug
SATA Port0
TOSHIBA MQ01AB (320.0GB)
SATA Port1
Not Present
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial-ATA (SATA)
Enables or disables the SATA controller.
SATA Speed Support
Configures the SATA controller as Gen1 or Gen2.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
SATA Mode
Configures the SATA as IDE or AHCI mode.
IDE
Enable / Disable Serial ATA AHCI
Serial-ATA Port 0
Enables or disables SATA port 0.
→←: Select Screen
SATA Port0 HotPlug
↑↓: Select Item
Enter: Select
Enables or disables hot pluggable support on SATA port 0.
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
Serial-ATA Port 1
F4: Save & Exit
ESC: Exit
Enables or disables SATA port 1.
SATA Port1 HotPlug
Enables or disables hot pluggable support on SATA port 1.
57
This option configures the Serial ATA drives as Parallel ATA
physical storage device.
This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
