Chapter 4: BIOS Setup
Serial Port 1 Configuration
This section is used to configure serial port 1.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=248h; IRQ=5;
Onboard Serial Port Mode [RS232]
Terminal resistor [Enabled]
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Onboard Serial Port Mode
Select this to change the serial port mode to RS232, RS422, RS485 or RS485
Auto.
Terminal Resistor
Enables or disables the terminal resistor.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Serial Port 2 Configuration
This section is used to configure serial port 2.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Serial Port
Enables or disables the serial port.
Onboard Serial Port Mode
Select this to change the serial port mode to RS232, RS422, RS485 or RS485
Auto.
Terminal Resistor
Enables or disables the terminal resistor.
53
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
Serial Port 2 Configuration
Serial Port [Enabled]
Device Settings IO=2F8h; IRQ=3;
Onboard Serial Port Mode [RS232]
Terminal resistor [Enabled]
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
