Chapter 3: System Setup
If you are installing the 802.11b/g QN-MU-A0028 wireless mini card
2. Tighten screws onto the mounting holes to secure the bracket.
module (half-size), before proceeding with the installation, please assemble
the Wi-Fi module bracket first by following the instructions below:
1. Align the mounting holes on the Wi-Fi mini card module to the
mounting holes on the Wi-Fi module bracket.
Mounting Holes
Wi-Fi Module Bracket
40
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
APPC 3154 User Manual
