Chapter 1: Product Introduction
▪ Vibration:
– IEC 68 2-64 (w/ HDD)
– 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
▪ Shock:
– IEC 68 2-27
– HDD: 20G @ wall mount, half sine, 11ms
▪ Operating temperature: 0°C to 50°C
▪ Storage temperature: -5°C to 60°C
▪ Operating humidity: 10%~90% relative humidity, non-condensing
Limits to be at 90% RH at max 50°C
▪ Dimension: 359.8 x 282.7 x 60mm
▪ Weight: 3.3kg
Certifications
▪ CE approval
▪ FCC Class A
OS Support Lists
▪ Windows 10 64-bit
▪ Windows 8 32-bit/64-bit
▪ Windows 7 32-bit/64-bit
▪ WinCE 7.0
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
3
APPC 3154 User Manual
