Summary of Contents for Viking Range 3 Series

  • Page 1 Installation GUIDE 3 SERIES VDWU324SS FDWU324 5 SERIES VDWU524SS VDWU524WSSS FDWU524WS FDWU524 7 SERIES VDWU724SS FDWU724...
  • Page 2: Table Of Contents

    INTRODUCTION ___________________________________________________________ 3 1. IMPORTANT SAFETY INSTRUCTIONS ______________________________________ 3 1.1 INSPECT THE DISHWASHER _____________________________________________ 4 2. TOOLS WHICH MAY BE NEEDED __________________________________________ 5 3. MATERIALS WHICH MAY BE NEEDED ______________________________________ 6 4. MATERIALS SUPPLIED ___________________________________________________ 6 4.1 PARTS SUPPLIED ______________________________________________________ 6 4.2 MANUAL BAG __________________________________________________________ 6 4.3 DISHWASHER PARTS BAG 1 _____________________________________________ 6 4.4 DISHWASHER PARTS BAG 2 _____________________________________________ 6...
  • Page 3: Introduction

    To prevent accidents, which could NOTICE : cause serious injury or death, as Read these installation instructions well as machine damage read these completely before installing and follow instructions before installation and / or them carefully. Save these installation use. instructions and pass them on to any future user.
  • Page 4: Inspect The Dishwasher

    • Dishwasher must be secured to adjacent NOTICE : cabinetry using the brackets provided. • The dishwasher drain hose must be Failure to do this may cause damage to installed with a drain loop at least 28” property or bodily injury. (710mm) off...
  • Page 5: Tools Which May Be Needed

    2. TOOLS WHICH MAY BE NEEDED Flat head Screwdriver 3. MATERIALS WHICH MAY BE NEEDED (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. Elbow with 3/4”...
  • Page 6: Materials Supplied

    4. MATERIALS SUPPLIED 4.1 PARTS SUPPLIED 4.4 DISHWASHER PARTS BAG 2 Parts for your dishwasher will come in several plastic bags. (SELECT MODELS) Check your parts bags shown In addition to the manual bag to make sure you have all the and the dishwasher parts bag parts as listed to the left.
  • Page 7: Dishwasher Specifications

    5. DISHWASHER SPECIFICATIONS 5.1 TECHNICAL FEATURES Permissible water pressure 4.35 - 145 psi (0.3 - 10 bars) Electrical connection 120 V (volts), 12 A (amps), 60Hz (hertz) Total power 1400 W (watts) Heater power 1100 W (watts) NOTICE : Because we continually strive to improve our products, we may change our specifications and design without prior notice.
  • Page 8: Enclosure Preparation

    6. ENCLOSURE PREPARATION 6.1 FOAM RUBBER INSTALLATION Open the foam insulation tape and follow the instructions in it. This step is not imperative, but it will help you improve your soundproofing 6.2 ELECTRICAL PREPARATION WARNING The dishwasher is designed for an electrical supply of 120 V, 60 Hz, AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated for 15 amperes.
  • Page 9: Steam Protective Foil

    6.3 STEAM PROTECTION FOIL Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. FITTING THE PROTECTION FOIL Before applying the steam protection foil to the underside of the countertop, clean the area with...
  • Page 10: Installing The Side Plugs

    6.4 INSTALLING THE SIDE PLUGS Install the 4 spacers (v) into the openings on each side of the dishwasher as shown. 6.5 INSTALLING THE SIDE TRIM NOTE Side trim may or may not have notches already cut. If there are no notches, you will need to measure and cut notches as shown in diagram below to match side plug locations before installing.
  • Page 11: Connecting The Water Lines

    7 CONNECTING THE WATER LINE 7.1 PREPARING THE WATER CONNECTION (A) Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve.
  • Page 12: Adjusting The Height

    7.3 ADJUSTING HEIGHT If the height of the enclosure is 33 7/8” to 35 7/8” (861 mm - 911mm) adjust feet as shown. Adjust the front foot level by hand to balance and raise the dishwasher to the enclosure height. Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height.
  • Page 13: Preparing The Custom Door

    8 PREPARING THE CUSTOM DOOR Height (wooden door: (h): 30” (760mm) Width (w): 23 ¼” to 23 ½” (592mm - 595mm) Thickness (t): ¾ “ (19mm) Weight (max): 19 lbs / 9 kg Ø2 X 14 mm Ø2 X 14 mm Mid.
  • Page 14 If there is a handle, attach as shown. Open the tape as shown and stick it on the door...
  • Page 15: Installing The Custom Door

    8.1 INSTALLING THE CUSTOM DOOR Open the remaining adhesive on the top surface of the tape as shown. (Step 1) Place the wheels you attached to the custom panel in the previous step on the product door as shown (Step 2). Position the custom panel by sliding the wheels down (Step 3).
  • Page 16: Securing To The Cabinetry

    9 SECURING TO THE CABINETRY 9.1 READJUSTING FOOT LEVELS Now that the dishwasher is in the cabinet you must readjust the feet to bring the dishwasher up to the required height and attach it underneath the countertop. 1. Readjust the front foot levels with adjusting wrench to balance the dishwasher and raise it up under the countertop, make sure the unit is level.
  • Page 17: Securing To The Cabinet

    9.3 SECURING THE DISHWASHER TO THE COUNTER If unable to secure dishwasher using the mounting brackets as shown due to cabinet or countertop design, an alternative method is to secure the dishwasher using 4 screws thru the side into the cabinet.
  • Page 18: Drain Hose Connection, Water Supply & Electrical

    10 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL CONNECTIONS 10.1 DRAIN HOSE CONNECTION Connect the drain hose to the drain plumbing. 1. Use the supplied rubber connection hose and drain hose clamps to connect the dishwasher drain hose to the plumbing drain connection. 2.
  • Page 19: Drain Installation

    10.3 DRAIN INSTALLATIONS UNDER THE SINK DRAIN Install a Y-branch tail pipe. (Figure A) NOTICE : You must add a loop at least 28” (710mm) above the floor of the cabinet and above the drain connection in the drain hose to prevent waste water from not draining properly, and causing either poor washing results or a bad odor.
  • Page 20: Water Line Connection

    10.4 WATER LINE CONNECTION (1.2 cm) (1.9 cm) (1.9 cm) (1.9 cm)
  • Page 21: Electrical Connection

    10.5 ELECTRICAL CONNECTION WARNING WARNING • Make sure the voltage and frequency listed Improper connection of the equipment- on the data plate correspond with the grounding conductor can result in a risk household electrical supply. This data must of electric shock. Check with a qualified correspond to prevent injury and machine electrician or service representative if damage.
  • Page 22: Final Installation

    11 FINAL INSTALLATION 11.1 INSTALLING THE TOE KICK INSULATION AND TOE KICK Now that you have successfully installed the dishwasher, you need to attach the toe kick to the dishwasher. The two piece toe kick can be adjusted to the height and depth needed for your kitchen.
  • Page 23 4. Apply gray cotton insulation to the metal panel below the door,ensuring the toe kick brackets come through the cutouts, and the felt touches the floor. 5. Remove the backing from the adhesive strip on the insulation that is already attached to the bottom of the dishwasher door.
  • Page 24: Installer Checklist

    11.2 ADJUSTING THE KICK PLATE • Check whether the bottom of the door (A) hits the kitchen cabinet base (B) . • If the door hits the cabinet base cut the necessary section out of the base (B). • Apply silicone or sealant to the cut edge of the kitchen cabinet base or paint so it does not absorb moisture.
  • Page 25: Troubleshooting

    13 TROUBLESHOOTING: Notice : • If your dishwasher is not operating The screen does not come on: properly after following these steps: • Check to make sure the breaker to the Contact your dealer to schedule an dishwasher is in the on position. authorized service agent to inspect your •...
  • Page 26: Service Information

    Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-845-4641, or write to: VIKING RANGE, LLC PREFERRED SERVICE 111 Front Street Greenwood, Mississippi 38930 USA Record the information indicated below.
  • Page 28 Viking Range, LLC 111Front Street Greenwood, Mississippi 38930 (662)455-1200 For more product information call 1-888-845-4641 or visit our website at vikingrange.com 068681-000D EN (030123)
