Page 1: Installation Guide
Installation Guide 1 & 3 Series Built-In Dishwashers... -
Page 2: Table Of Contents
Table of Contents Important Safety Instructions __________________________________________________________3 Tools Which May Be Needed _________________________________________________________5 Materials Which May Be Needed ______________________________________________________6 Materials Supplied ___________________________________________________________________7 Parts Supplied ___________________________________________________________________7 Dishwasher Specifications ____________________________________________________________8 Enclosure Preparation ________________________________________________________________9 Electrical Preparation _____________________________________________________________9 Preparation for Installing Mounting Brackets_________________________________________9 Adjusting Height _________________________________________________________________9 Installing the Side Trim Strips _____________________________________________________10 Preparing the Water Connection __________________________________________________11 Drain Preparation _______________________________________________________________12... -
Page 3: Important Safety Instructions
IMPORTANT – Please Read and Follow In addition to these instructions, the WARNING dishwasher shall be installed: • In accordance with all local codes or, in absence of a local code, Read these installation instructions • In the United States, with the national completely before installing and Electric Code, follow them carefully. - Page 4 IMPORTANT– Please Read and Follow • DO NOT operate the appliance if damaged, malfunctioning, partially disassembled, or if it has missing or broken parts. • Also follow the safety instructions of the use and care guide. • To reduce the risk of electric shock, fire, or injury to persons, the installer must ensure that the dishwasher is completely enclosed at the time of installation.
-
Page 5: Tools Which May Be Needed
General Information Tools Which May Be Needed Pipe Wrench Wire Cutter Drill Hole Saw Hammer Wire Stripper (T20) Tape Measure Torx Screwdriver Phillips Screwdriver Adjustable Wrench Slot Screwdriver Scissors Level Brush Pencil... -
Page 6: Materials Which May Be Needed
General Information Materials Which May Be Needed Hot Water Supply Line – Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. 90° elbow with 3/8” N.P.T. male threads on one leg, and sized to fit your water supply line (copper tubing/compression fitting, or braided hose) on the other leg. -
Page 7: Materials Supplied
General Information Parts Supplied Parts for your dishwasher will come in several plastic bags. Check your parts bags to make sure you have all the parts as listed below. Materials Supplied Dishwasher Parts Bag 1 Dishwasher Parts Bag 2 This dishwasher bag comes with v. -
Page 8: Dishwasher Specifications
Specifications Built-In Dishwasher Overall Width 23-9/16” (59.8 cm) Overall Height from Floor 33-7/8 (86.0 cm) min. to 35-7/8" (91.1 cm) max. Overall Depth from Rear without door panel – 21 5/8” (54.9 cm) with door panel – 22 3/16” (156.4 cm) Cutout Width 24"... -
Page 9: Enclosure Preparation
Enclosure Preparation Electrical Preparation WARNING The dishwasher is designed for an electrical supply of 120V, 60Hz, AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated for 15 amperes. Preparation for Installing Mounting Brackets WARNING Dishwasher must be secured to adjacent cabinetry using the mounting brackets provided. -
Page 10: Installing The Side Trim Strips
Enclosure Preparation • Adjust the front foot level with the adjusting wrench to balance and raise the dishwasher to the enclosure height. • Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height. NOTICE •... -
Page 11: Preparing The Water Connection
Installation Preparation Preparing the Water Connection (A) • Install an easily accessible shut-off valve • Check with your plumbing supply sources (not supplied) in the water supply line. All for the proper hose and 90° elbow and solder connections must be made before necessary fittings for the water supply line. -
Page 12: Drain Preparation
Installation Preparation Drain Preparation The dishwasher drain hose may be connected to the drain plumbing in one of three ways, (Figures A, B, C): NOTICE • Either one of the above methods must be used or the dishwasher will not operate properly. -
Page 13: Steam Protection Foil
Installation Preparation Steam Protection Foil Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. Fitting the Protection Foil •... -
Page 14: Installation
Installation Placement of Dishwasher into the Opening Now place the dishwasher into the opening and get ready to connect all hoses and electrical connections. CAUTION Make sure all hoses are pulled through the side opening of the cabinet, no hoses are kinked, and all slack is taken out as shown in the figure to the left. -
Page 15: Preparation Of Water Supply
Installation Preparation of Water Supply Left Side Water Supply Connection • Before pushing the dishwasher into the cabinet, you must place water supply hoses into the channel of the dishwasher (Figure A). • Place the supplied clips into the channel (Figure B) so that you can move these clips along the channel (Figure C) and fix by pressing on (Figure D) so that you... - Page 16 Installation • After installing one clip for each side, push the dishwasher into the cabinet (Figure E). • Note that while pushing the dishwasher into the cabinet, water supply hose must move in the channel to the front (Figure F). •...
- Page 17 Installation Water supply may be connected to the dishwasher in one of two ways: • With metal braided hose. • With copper tubing. CAUTION • Hot water supply line: Use minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. •...
-
Page 18: Electrical Connection
Installation Electrical Connection Grounding Instructions WARNING This appliance must be grounded. In the event of a malfunction or breakdown, • Make sure the voltage and frequency grounding will reduce the risk of electrical listed on the data plate correspond shock by providing a path of least resistance with the household electrical supply. -
Page 19: Readjusting Foot Levels
Installation Readjusting Leveling Legs Now that the dishwasher is in the cabinet, you must readjust the leveling legs to bring the dishwasher up to the required height and attach it underneath the countertop. • Readjust the front leveling leg with adjusting wrench to balance the dishwasher and raise it up under the countertop;... - Page 20 Installation If the enclosure height is below 33-1/16” (84.0cm), use only (o) labeled kickplate (kickplate without slots). Installation should be done following the steps illustrated in the Figures A, B, and C respectively. 1. Bend tabs on kickplate (o) inwards (A). 2.
-
Page 21: Installing A Custom Panel
Installation Installing a Custom Panel Measure the height and width of the enclosure (Figure A) and the kickplate. Determine how big the wooden door can be. For example, if the height is 33-7/8” (86.0cm) and if the kickplate is 3-15/16” (10.0cm), the door cannot be taller than 29-15/16”... - Page 22 Installation 3. Mark the wooden door as shown in the drawing (Figure C). 4. Place the plastic mounting brackets over the marked holes. Align the bottom of the bracket with the horizontal line. Align the middle of the bracket with the center line using the “V” cut in the bracket.
- Page 23 Installation Ø " (3,5mm) 5. Attach the two mounting brackets to the 6. Mount the wooden door onto the dishwasher wooden door with 4 screws (Ø 1/8”x5/8” with the plastic mounting brackets which you (Ø 3.55mmx14mm). have attached. Ø 3 / 16 " (4mm) 7.
- Page 24 Installation 11. Check whether the bottom of the door hits the kickplate of the kitchen cabinet (Figure A). 11. 1. If the door hits the kickplate, cut the necessary section out of the kickplate (Figure B). 11. 2 Apply silicon or sealant to the cut edge of the kitchen cabinet kickplate or paint so it does not absorb...
- Page 25 Installation NOTICE If you have a European kitchen or want to install a wooden kickplate to match your kitchen, please refer to one of the two drawings given below. Follow the same instructions on the brackets as for the removable kickplate. Installation should be done following the steps illustrated in the Figures A, B, C, and D respectively.
-
Page 26: Installer Checklist
Installer Checklist and Final Instructions Your installer must have completed and Self-Help Hints checked the following: The screen does not come on: KThe dishwasher is square and level. • Check to make sure the breaker to the KThe dishwasher is fastened securely to the dishwasher is in the on position. -
Page 27: Service & Registration
All servicing should be referred to a qualified technician. Contact Viking Range, LLC, 1-888-845-4641, for the nearest service parts distributor in your area or write to:... - Page 28 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our web site in the US (www.vikingrange.com) or in Canada (www.brigade.ca). F21366 EN (041515)
