- Page 1 Installation GUIDE 3 SERIES VDWU324SS FDWU324 5 SERIES VDWU524SS VDWU524WSSS FDWU524WS FDWU524 7 SERIES VDWU724SS FDWU724...
-
Page 3: Table Of Contents
To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use. CONTENTS INTRODUCTION 1. IMPORTANT SAFETY INSTRUCTIONS 1.1 INSPECT THE DISHWASHER 2. TOOLS WHICH MAY BE NEEDED 3. -
Page 4: Introduction
INTRODUCTION NOTICE : The dishwasher should be installed by an insured NOTICE : licensed plumber, contractor or trained installer. Please read this installation manual and particularly Installation performed by persons other than this the safety instruction completely and carefully. They could result in improper installation and property will save you time and effort and help to ensure damage. -
Page 5: Inspect The Dishwasher
NOTICE : • The dishwasher drain hose must be installed with a drain loop at least 28” (710mm) off the cabinet floor; otherwise the dishwasher may not drain properly. • This dishwasher is intended for residential use only, and should not be used in commercial establishments. -
Page 6: Tools Which May Be Needed
2. TOOLS WHICH MAY BE NEEDED Wire Cutter Pipe wrench Drill Wire Stripper Hole Saw Hammer Torx Screwdriver Phillips Screwdriver Tape Measure Scot Screwdriver Scissors Adjustable Wrench Brush Pencil Level 3. MATERIALS WHICH MAY BE NEEDED (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/8”... -
Page 7: Materials Supplied
4. MATERIALS SUPPLIED 4.1 PARTS SUPPLIED Parts for your dishwasher will come in several plastic bags. Check your parts bags shown to make sure you have all the parts as listed to the left. 4.2 MANUAL BAG The dishwasher comes with a manual bag containing: •... -
Page 8: Dishwasher Specifications
5. DISHWASHER SPECIFICATIONS BUILT-IN ” 2 1 ⅝ 2 3 ⁄ ” m m ) ( 5 9 8 m ( 5 5 0 2 4 ” m m ) ( 6 1 0 2 3 ⅝ “ - 2 4 ( 6 0 0 “... -
Page 9: Technical Features
5.1 TECHNICAL FEATURES Permissible water pressure 4.35 - 145 psi (0.3 - 10 bars) Electrical connection 120 V (volts), 12 A (amps), 60Hz (hertz) Required Curcuit Breaker 15 A(amps), Dedicated Total power 1400 W (watts) Heater power 1100 W (watts) NOTICE : Because we continually strive to improve our products, we may change our specifications and design without prior notice. -
Page 10: Steam Protection Foil
6.3 STEAM PROTECTION FOIL Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. -
Page 11: Leveling
7. LEVELING 7.1 ADJUSTING HEIGHT Adjust the front foot level by hand or slotted screwdriver to balance and raise the dishwasher to the enclosure height. Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height. -
Page 12: Installing The Side Trim Strips
8.2 INSTALLING THE SIDE TRIM STRIPS NOTICE : • Make sure you are using the correct side of the trim. The flexible material should be facing forward (Figure A). TOP VIEW Remove the adhesive tape (Figure Place the trim strips on the front edge of the side walls (Figure 8.3 PREPARATION FOR INSTALLING MOUNTING BRACKETS WARNING... -
Page 13: Connecting The Water Line
9. CONNECTING THE WATER LINE 9.1 PREPARING THE WATER CONNECTION Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve. Water can also be supplied to the dishwasher by using a flexible braided hose line. -
Page 14: Placement Of Dishwasher Into The Opening
NOTICE : After connections are made turn on the water supply to check for leaks. 9.2. PLACEMENT OF DISHWASHER INTO THE OPENING Before placing the machine in the cabinet, remove the hose holders from the back of the machine as shown in the figure. -
Page 15: Preparing The Custom Panel
10. PREPARING THE CUSTOM PANEL (For Integrated Models) If the custom panel flush with the top of the display as shown in Figure A, place the template as in Method A. If the custom panel and extends above it as shown in Figure B, measure down from the top edge of the panel the distance you wish to extend above the display and place the template there as in Method B. - Page 16 METHOD A 1/8” bit, 1/2” deep Ø2 X 14 mm Supplied Template 1/8” bit, 1/2” deep Ø2 X 14 mm Custom Door Stud & Screw Mid. Point Height (h) : 27 9/16 ” to 29 15/16 ” (700 mm - 760 mm) Width (w) : 23 5/16 ”...
- Page 17 METHOD B 1/8” bit, 1/2” deep Ø2 X 14 mm 1/8” bit, 1/2” deep Supplied Template Ø2 X 14 mm Custom Door Stud & Screw Mid. Point Height (h) : 27 9/16 ” to 29 15/16 ” (700 mm - 760 mm) Width (w) : 23 5/16 ”...
-
Page 18: Installing The Custom Panel Handle
10.1 INSTALLING THE CUSTOM PANEL HANDLE Install the custom panel handle as shown if there is a handle. Be sure to screw in the screw fully. 10.2 PREPARING THE PRODUCT DOOR Peel the protective cover off one side of the adhesive strip and apply it to the location of the dishwasher door as shown in the figure. -
Page 19: Installing The Custom Panel
10.3 INSTALLING THE CUSTOM PANEL Remove the outer protective cover on both adhesive strips as shown. (Figure A) Take the panel and slide the mounting studs into the channels on each side of the door as shown. Slide the panel down to place it. (Figure B) Hold it as shown and squeeze the bottom of the panel to the door engaging the adhesive strips secure the bottom of the panel . -
Page 20: Securing The Custom Panel
10.4 SECURING THE CUSTOM PANEL Remove the plastic plugs located in the fifth screw position from the top on each side. Secure the custom panel to the product through hole 5 with the one in 5/8 inch (Ø 4mm x 42mm) supplied screws on each side. -
Page 21: Securing To The Cabinetry
11. SECURING TO THE CABINETRY 11.1 READJUSTING FOOT LEVELS Now that the dishwasher is in the cabinet you must readjust the feet to bring the dishwasher up to the required height and attach it underneath the countertop. 1. Readjust the front foot levels with slotted screwdriver or hand to balance the dishwasher and raise it up under the countertop, make sure the unit is level. -
Page 22: Attaching The Corner Brackets
11.2 ATTACHING THE CORNER BRACKETS Make sure the machine is level with the counter. The machine should not be ahead or behind the counter. If your counter is wooden, fix the mounting brackets on the right and left sides under the bench with the screws provided as shown in (A). -
Page 23: Securing The Cabinet To The Counter
11.3 SECURING THE CABINET TO THE COUNTER Fix the machine from the inside of the cabinet at the four points indicated with the screws provided. -
Page 24: Connecting The Drain Line
12. CONNECTING THE DRAIN LINE 12.1 CONNECTION INFORMATION 1/2" 3/4" (20,9 mm) (26,4 mm) 3/4" 3/4" (26,4 mm) (26,4 mm) min: 0,05 MPa/0,5 Bar max: 1 Mpa/10 Bar ~59 1/16” ~1500 mm ~1800 mm ~70 7/16” ~78 3/4” ~2000 mm Ø... -
Page 25: Drain Hose Connection
12.2 DRAIN HOSE CONNECTION Connect the drain hose to the drain plumbing. 1. Use the supplied rubber connection hose and drain hose clamps to connect the dishwasher drain hose to the plumbing drain connection. 2. Use the spring clamp to secure the rubber connection hose to the dishwasher drain hose. Use the screw clamp to secure the rubber connection hose to the plumbing drain connection. - Page 26 NOTICE : You must add a loop at least 28” (710mm) above the floor of the cabinet and above the drain connection in the drain hose to prevent waste water from not draining properly, and causing either poor washing results or a bad odor. 12.3.2 INSTALLING AN AIR GAP NOTICE : Check with local ordinance for type of air gap required.
-
Page 27: Electrical Connection
13. ELECTRICAL CONNECTION WARNING • The access hole of the supply cord to the • Make sure the voltage and frequency listed installation compartment must be smooth and on the data plate correspond with the rounded and it must be large enough for the household electrical supply. -
Page 28: Final Installation
15. FINAL INSTALLATION 15.1 INSTALLING THE TOE KICK INSULATION AND TOE KICK Now that you have successfully installed the dishwasher, you need to attach the toe kick to the dishwasher. The two piece toe kick can be adjusted to the height and depth needed for your kitchen. Be sure to use the slotted toe kick in the front and the other behind it. - Page 29 4. Apply gray cotton insulation to the metal panel below the door,ensuring the toe kick brackets come through the cutouts, and the felt touches the floor. 5. Remove the backing from the adhesive strip on the insulation that is already attached to the bottom of the dishwasher door.
-
Page 30: Adjusting A Wooden Toe Kick
15.2 ADJUSTING A WOODEN TOE KICK • Check whether the bottom of the door hits the toe kick of the kitchen cabinet ( • If the door hits the toe kick cut the necessary section out of the toe kick ( •... -
Page 31: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-845-4641, or write to: VIKING RANGE, LLC... - Page 32 Viking Range, LLC 111Front Street Greenwood, Mississippi 38930 )662(455-1200 For more product information call 1-888-845-4641 or visit our website at vikingrange.com 068681-000D EN (030123) 15 8023 0100_VIKING_EN/ 21-07-23.(11:59)
