- Page 1 Use & Care MANUAL 3 & 5 SERIES VDWU524SS VDWU524WSSS FDWU524WS FDWU524 VDWU324SS FDWU324...
-
Page 2: Table Of Contents
4.2 LOWER RACK 4.3 PROPER AND IMPROPER LOADING OF DISHWARE 5. WHAT SHOULD NOT BE WASHED IN YOUR DISHWASHER OPERATING THE PRODUCT PROGRAM SELECTION / PROGRAMME CANCEL KEY 5 SERIES FUNCTION KEYS PREPARING THE MACHINE PROGRAM SELECTION PROGRAMME SELECTION / PROGRAMME CANCEL KEY 3 SERIES... -
Page 3: Important Safety Instructions
• Use only detergents or rinse aids recommended for Please read this user manual and particularly the safety use in a household dishwasher and keep them in a instructions completely and carefully. They will save you dry place out of the reach of children. Check that the time and effort and help to ensure optimum dishwasher detergent dispenser is empty after the completion of performance. -
Page 4: Recycling
tripping on the unit. WARNING:If your dishwasher is equipped with internal illumination, lamp should only be replaced by the Authorized Service Agent in case of failures that may occur on the lamp. WARNING: This product can expose you to chemicals including Nickel (Metallic) which is known to the State of California to cause cancer. -
Page 5: Getting To Know Your Dishwasher
3. GETTING TO KNOW YOUR DISHWASHER 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Removable cutlery basket 5. Door 6. Model and Serial Tag 7. Control panel 8. Detergent and rinse agent dispenser 9. Lower basket 10. Filters 11. -
Page 6: Loading The Dishwasher
4. LOADING THE DISHWASHER Pull the handle to open the door. If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will continue. Remove coarse food leftovers from tableware. Now you can load the dishwasher. Upper rack ( Standard Pattern) International Loading Pattern –... - Page 7 Upper rack ( Select Models) CAUTION:Use extreme caution when removing knives and other sharp utensils from the dishwasher. These items may have shifted position during the wash program, and may be wet or slippery. CAUTION:Hot steam can escape! Danger of serious burns or other injury.
-
Page 8: Upper Rack
4.1 UPPER RACK ADJUSTING THE HEIGHT OF THE UPPER BASKET (Select Models) Load the upper rack with dessert plates, cups, glasses etc. The upper basket height adjustment mechanism has been designed for you to create large spaces in the lower or upper sections of your machine depending on your needs by adjusting the height in the upper or lower direction while your basket is empty or loaded. -
Page 9: Lower Rack
UPPER BASKET MULTIPURPOSE SERVICE RACK COLLAPSIBLE LOWER BASKET TINES (Select Models) (Select Models) This accessory located at the upper basket of your There are foldable tines (A) located in the lower basket machine allows you to easily wash pieces such as extra of the machine that are designed for an easier placement long ladles and bread knives. - Page 10 REMOVABLE CUTLERY BASKET LOWER BASKET MULTIPURPOSE / HEIGHT (Select Models) ADJUSTABLE SERVICE RACK Removable cutlery basket is designed to wash your dishes (Select Models) such as knife, fork, spoon, etc. in a more efficient manner. This accessory located in the lower basket of your machine Since the silverware basket can be moved (A, B), you can allows you to easily wash pieces such as extra glasses, create more space while placing your dishes in the lower...
-
Page 11: Proper And Improper Loading Of Dishware
4.3 PROPER AND IMPROPER LOADING OF DISHWARE 4 4 4 1: Salad Fork 2: Teaspoon 3: Dinner fork 4: Knife-solid handle 4 4 4 5: Serving spoon 6: Serving fork Sliding Cutlery Basket load pattern for 12 place settings according to the AHAM DW-1 Standards •... -
Page 12: What Should Not Be Washed In Your Dishwasher
Remember, if there is any doubt about any aspect concerning items to be washed in the dishwasher, follow the instructions from the manufacturer of the items, or wash the items by hand. 5 SERIES OPERATING THE PRODUCT 1. -
Page 13: Program Selection / Programme Cancel Key 5 Series
10 11 13 14 9. Auto Door Open Indicator (depends on the model) 10. Filter Cleaning Function Indicator (depends on the model) 11. Function Indicator (depends on the model) 12. Delay Time / Program Time Indicator 13. Delayed Start Indicator 14. -
Page 14: Programme Selection / Programme Cancel Key 3 Series
3 SERIES OPERATING THE PRODUCT 1. On / Off Key 2. Menu Key 3. Time Delay Selection / Menu Direction Selection Keys 4. Selection / Confirmation Key 5. Display 6. Start / Pause / Cancel Key 7. Function Selection Keys Express Function High Gloss Function Sanitize Function... -
Page 15: Function Keys
On/Off Key When you press the On/Off key, the indicator lights illuminate on the display for ON position. The lights turn off in OFF position. PROGRAM SELECTION / PROGRAM CANCEL KEY Select the desired program using the “program selection keys” and press the button. To cancel the running program, open the door of the machine and press and hold the Program Start/Pause/Cancel key for 3 seconds. -
Page 19: Auxiliary Functions
6.4 AUXILIARY FUNCTIONS IntenseWash Function Washing programs of your dishwasher are designed to IntenseWash impeller located under the obtain the best cleaning effect, considering the type of the lower impeller helps washing your soiling, soiling degree and properties of the dishes to be heavily soiled dishes places in the right washed. -
Page 20: Scheduling The Washing Time
Functions Under the Settings Menu Program and auxiliary functions cannot be set/ (depends on the model) changed after the program has started. Under the settings menu of your product, there are some additional functions that depend on the model. To cancel the Time Delay function To access these functions, press and hold the Menu key Open the door of the product Press and hold the Program for 3 seconds. -
Page 21: Cancelling The Program
Leave your dishes in the machine for about 6.7 CANCELLING THE PROGRAM 15 minutes to allow them cool down after Open the door of the product press and hold the Program they are washed. Your dishes will dry in a Selection / Program Cancel keys for 3 seconds. -
Page 22: Tablet Detergents
Inside the detergent dispenser there are Observe the instructions of the detergent level markings that help you use appropriate manufacturer on the package when using amount of powder detergent. When full, the tablet detergents. detergent dispenser will contain 1.5 Ounces Contact the detergent manufacturer if your (42.5g) of detergent. -
Page 23: Adjusting The Water Softening System
The rinse aid adjustment is described under "Adjusting the amount of rinse aid" in the section for operating the machine. Wipe clean any spilled rinse aid outside the reservoir. Rinse aid that spilled accidentally will cause foaming and it will eventually decrease washing performance. -
Page 24: Filling The Dishwasher Salt Dispenser
4. Fill the salt reservoir with salt by using the salt funnel If you move your dishwasher to another house, (D). To speed up dissolution rate of salt in water, stir it it is necessary to readjust water hardness level with a spoon. -
Page 25: Caring For Your Dishwasher Exterior
10.1 CARING FOR YOUR DISHWASHER 10.3 CLEANING THE FILTERS EXTERIOR Clean the filters at least once a week in order for the machine operate efficiently. Check if food residues are left CAUTION :Possible dishwasher damage: on the filters. If there are food residues on filters, take them Abrasive cleaners, scouring pads, abrasive out and clean well under running water. -
Page 26: Cleaning The Hose Filter
10.4 CLEANING THE HOSE FILTER 10.5 CLEANING THE WASH ARMS Damages on the machine that may be caused by Clean the wash arms at least once a week in order for the impurities coming from the water supply or your own water machine operates efficiently. -
Page 27: Troubleshooting
1. TROUBLESHOOTING Machine does not start. • Power supply not connected. >>> Check the main power supply. • Circuit Breaker is blown. >>> Check the Circuit Breaker in your house. • Water is not entering machine. >>> Make sure that the water inlet tap is open. •... - Page 28 There is a different odor in the machine A new machine has a peculiar odor. It will fade out after a couple of washing. • Filters are clogged. >>> Check if the filter system is clean. Clean the filter system regularly as illustrated in section “Cleaning and Care”.
-
Page 29: Technical Features
A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid. •... -
Page 30: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-845-4641, or write to: VIKING RANGE, LLC... -
Page 31: Warranty
Built-in dishwashers and all of their component parts, except as detailed below*†, are warranted to be free from defective materials or workmanship in normal residential use for a period of one (1) year from the date of original retail purchase. Viking Range, LLC, warrantor, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period. - Page 32 Viking Range, LLC 111Front Street Greenwood, Mississippi 38930 (662)455-1200 For more product information call 1-888-845-4641 or visit our website at vikingrange.com 068680-000A EN 073018...
