General Information

Features

HMI 4.3 inch Color Touchscreen Display
System Configurable via the Connectivity server
®
using most Wi-Fi
Ethernet connection
Remote
Communication
Modbus TCP/IP, 10/100 Mbs Ethernet IEEE 802.3
or Wi-Fi
Configurable Analog and Digital I/O
Configurable Monitoring of Analog I/O, Digital I/O,
and Machine State Data
Configurable Detection and Mitigation of Faults
with E-Mail Annunciation
Configurable Logging of Faults and Events with
Associated Data Capture
Configurable Logging and Trending of Data
Digitally Controlled Generator Output Voltage and
Frequency Regulation
Customer Programmable Built-in Multichannel PLC
Logic Controller
2
Alternator I
T with 300% Current Limiting for
Breaker Coordination
Alternator Ground Fault Indication
Parameters Monitored on Display or
Connectivity Server
Keyswitch Position Monitoring
Amps per Phase - Generator
Line to Line and Line to Neutral Volts - Utility and
Generator
Power Factor - Generator
Real Power - kW - Generator
Apparent Power - kVA - Generator
Reactive Power - kVAR - Generator
Frequency - Utility and Generator
Engine Speed
Engine Coolant Temperature
Engine Oil Pressure
Engine Oil Temperature
Battery Voltage
Shutdown Messages
Diagnostics
Maintenance Events/Information
Engine Run Hours
6
®
, Bluetooth
devices, or wired
®
via
Modbus
Voltage Regulation (Single or Three-Phase
Module Options)
Digital Control
Single-Phase or Three-Phase RMS Sensing with
Loss of Sensing Protection
RTU,
Variable V/F Slope Settings and Adjustable Gains
Negative Power Protection
Soft Start Ramping
Fault Protection (I

Electronic Governor

Electronic
Controlled
Engines
Adjustable Gains
Low Speed Exercise

PLC (Built-In Programmable Logic Controller)

Configurable Through Software Tool
Customer Configurable for Non-Standard Options
Up to 8 Simultaneously Running PLC Programs or
in Sequence

Connections

21 Digital Outputs Maximum (Open Drain, 35 V
1.7 A)
7 fast PWM capable Outputs, 1 High Current
15 Digital Inputs Maximum
7 fast PWM capable Inputs
12 General Purpose Analog Inputs
2 Special Purpose Analog Inputs
2 Analog Outputs (0-10 V
1 E-Stop Relay Output
3 Current Sense Inputs
8 High Voltage Sense Inputs (3-Phase + Neutral)
1 Magnetic Pickup Input
1 Coolant Level Sensor Input
2 CAN bus Channels
2 External RS-485 Ports (1 available to customer)
2 Switchable 12 V
NOTE: Actual I/O may vary due to configuration.

Qualification Testing

Life Test in Environmental Chamber
Temperature Rating
Vibration Tested and Protected
Owner's Manual for Power Zone Pro Main Controller
2
T Function and GFI)
Speed
Control
for
Compression
and
Spark
)
Power Outputs
Electronically
Ignited
