General Information

Specifications

Environmental Specifications
Operating Temperature
Humidity
Enclosure
Weight
Power Supply Requirements
Power Supply Source
Power Supply Voltage
Power Supply Wattage
Power Supply Cable
Cranking Dropout
Reverse Polarity Protection
Communication (RS-485)
Number of Ports
Internally Terminated
Communication Link
Communication Cable
Maximum Cable Length
Baud Rate
Maximum Number of Devices
Communication (CAN)
Number of Ports
Internally Terminated
Communication Link
Communication Cable
Maximum Cable Length
Baud Rate
Maximum Number of Devices
Analog/Digital/Inputs/Outputs (all voltages are DC)
Ratings
Digital Input
Digital Input PWM Capable
Digital Output or PWM capable
or Watchdog/Overspeed
Digital Output High Current
Capable
General Purpose Analog Input
Special Analog Input
Analog Output
Others
8
-40 °F (-40 °C) to 149 °F (65 °C)
2% to 95% Non-Condensing
UL Type 1
3.3 lbs
Engine Battery or Battery Charger
12/24 V (6 V to 35 V
31 Watts
2 wires - 16 AWG recommended
3.5 V
Yes
2 (1 for customer use, 1 is for internal use only)
Yes, 120 Ohms
2 wires - RS-485
2 wires - shielded twisted pair (i.e. Belden 3105A)
4,000 ft (1,219 m)
RS-485-0 115.2 Kbps; RS-485-1 4.8 to 115.2 kbps (selectable parity and stop bits)
32
2
Yes, 120 Ohms
2 wires
2 wires - shielded twisted pair (i.e. Belden 3105A)
131 ft (40 m)
250 kbps and 1 Mbps
30
Installation and Operation
See
0 V to 5 V, 1.5 mA max, 100 Hz, inputs are internally pulled up to 5V
0 V to 5 V, 5 mA max, 1 Mhz, inputs are internally pulled up to 5V
0 V to Vopen-drain, Vbattery max, 1 A max sink
0 V to Vopen-drain, Vbattery max, 2 A max sink
0 V to 5 V (10 uA max), 0 V to 10 V (10 uA max); 4-20 mA (50 mA max), or Resistive, 1
kHz
0 V to 5 V (10 uA max), 0 V to 10 V (10 uA max); Resistive, 500 Hz
0 V to 5 V, 0 V to 10 V, 10 mA max
Installation and Operation
See
)
.
.
Owner's Manual for Power Zone Pro Main Controller
