Dimensions
Remarque : Les dimensions sont sujettes à changer sans préavis.
2
Mesures
A
3 3/4 po, 95 mm
Taille de trou de la vanne
de dérivation
B
Min. Ø 3 po, 76 mm
Max. Ø 3 1/4 po, 83 mm
C
3 1/2 po, 89 mm
D
3 1/8 po, 79 mm
E
Ø 4 1/4 po, 108 mm
F
3 1/2 po, 89 mm
