DEVICE SCREEN
The device screen is the main control screen for the air conditioner, providing access to the controls to amend the
functions and settings.
Back: Returns to the Home
Screen.
Desired Temperature:
Displays what has
been set as the target
room temperature.
Horizontal swing:
Press to turn the
horizontal swing on
and off
Mode:
Press to change the
mode between Auto,
Heat, Cool, Dry and
Fan
Speed:
Press to change the
fan speed
Decrease Desired
Temperature
Temperature range
15-35C.
WIFI CONTROL
Device Name
Power: Use to turn
the unit on or off.
20
Edit Name: Use to change
the name of the heater.
Current Temperature:
Displays what the
current temperature is.
Vertical swing:
Press to turn the vertical
swing on and off
Additional Features:
Press to adjust
additional features
such as Sleep mode,
Silent mode and
display.
Timer:
Press to set the air
conditioner to turn on
or off at a specified
time.
Increase Desired
Temperature
Temperature range
15-35C.
