REMOTE CONTROLLER ILLUSTRATION

Thank you very much for purchasing our air conditioner.
Please read this owner's manual carefully before using
your air conditioner.

AIR CONDITIONER

iQool9
iQool12
iQool18
iQool24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iQool9 and is the answer not in the manual?

Questions and answers

Related Manuals for ElectrIQ iQool9

Summary of Contents for ElectrIQ iQool9

  • Page 1: Air Conditioner

    AIR CONDITIONER REMOTE CONTROLLER ILLUSTRATION iQool9 iQool12 iQool18 iQool24 Thank you very much for purchasing our air conditioner. Please read this owner's manual carefully before using your air conditioner.

  • Page 2: Table Of Contents

    CONTENTS Remote controller Specifications........... Operation of buttons ..............Indicators on LCD ................How to use the buttons ..............Auto operation................. Cooling/Heating/Fan operation............Dehumidifying operation ............... Timer operation................Handling the remote controller ............

  • Page 3: Remote Controller Specifications

    Remote Controller Specifications Model RG51F/E 3.0V(Dry batteries R03/LR03 2) Rated Voltage Signal Receiving Range Environment -5 C 60C SET TEMPERATURE(C) AUTO HIGH COOL HEAT TEMP ON/OFF MODE FAN SPEED TIMER ON SWING TIMER OFF RESET LOCK DISPLAY TURBO Model: RG51F/E...

  • Page 4: Operation Of Buttons

    TEMP UP Button Operation of buttons Push this button to increase the indoor temper- ature setting in 1 C increments to 30 C. TEMP DOWN Button Push this button to decrease the indoor temper- ature setting in 1 C increments to 17 C. SET TEMPERATURE( C) NOTE Temperature contol is not available AUTO...
  • Page 5 Operation of buttons RESET Button Once the recessed RESET button is pressed, all of the current settings will be cancelled and SET TEMPERATURE( C) the controller will return to the initial settings. AUTO HIGH COOL LED Button HEAT Disable/Active indoor screen Display. When pushing the button, the indoor screen display is cleared, press it again to light the display.
  • Page 6 TIMER OFF Button Press this button to initiate the auto-off time sequence. Each press will increase the auto -timed setting in 30 minutes increments. When the setting time displays 10.0, each SET TEMPERATURE( C) press will increase the auto-timed setting AUTO 60 minutes increments.

  • Page 7: Indicators On Lcd

    Indicators on LCD Mode display Information are displayed when AUTO COOL the remote controller is powered HEAT Displayed when data transmitted. AUTO Displayed when remote controller is ON. HIGH COOL Displayed when TIMER ON time is set. TIMER ON HEAT TIMER ON OFF Displayed when TIMER OFF time is set.

  • Page 8: How To Use The Buttons

    How to use the buttons Auto operation Ensure the unit is plugged in and power is available. The OPERATION indicator on the SET TEMPERATURE( C) display panel of the indoor unit starts flashing. AUTO HIGH COOL 1. Press the MODE button to select Auto. 2.

  • Page 9: Dehumidifying Operation

    How to use the buttons Dehumidifying operation Ensure the unit is plugged in and power is available. The OPERATION indicator on the display panel of the indoor unit starts flashing. SET TEMPERATURE( C) 1. Press the MODE button to select DRY mode. 2.

  • Page 10: Timer Operation

    Timer operation Press the TIMER ON button can set the auto-on time of the unit. Press the TIMER OFF button can set the auto-off time of the unit. SET TEMPERATURE( C) To set the Auto-on time. AUTO HIGH COOL 1. Press the TIMER ON button. The remote controller shows TIMER ON, the last Auto-on HEAT setting time and the signal "H"...
  • Page 11 CAUTION The effective operation time set by the remote controller for the timer function is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13, 14, 15,16,17, 18, 19, 20, 21, 22, 23 and 24.
  • Page 12 TIMER OFF (Auto-off Operation) The TIMER OFF feature is useful when you want the TIMER OFF unit to turn off automatically after you go to bed. The air conditioner will stop automatically at the set time. Example: To stop the air conditioner in 10 hours. 1.
  • Page 13 TIMER ON TIMER OFF (Off Start Stop operation) This feature is useful when you want to start the air conditioner before you wake up and stop it after you leave the house. TIMER ON OFF Example: To start the air conditioner 2 hours after setting, and stop it 5 hours after setting.

  • Page 14: Handling The Remote Controller

    Handling the remote controller Location of the remote controller. Use the remote controller within a distance of 8 meters from the appliance, pointing it towards the receiver. Reception is confirmed by a beep. CAUTIONS The air conditioner will not operate if curtains, doors or other materials block the signals from the remote controller to the indoor unit.
  • Page 15 Replacing batteries The following cases signify exhausted batteries. Replace old batteries with new ones. Receiving beep is not emitted when a signal is transmitted. Indicator fades away. The remote controller is powed by two dry batteries (R03/LR03X2) housed in the back rear part and protected by a cover.
  • Page 16 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
