Perforated part is required for actuating the tamper in case of any attempt to
dismantle the hub. Do not break it off.
3. Power cable socket
4. Ethernet cable socket
5. Slot for micro SIM 2
6. Slot for micro SIM 1
7. QR Code
8. Tamper button
9. Power button
10. Сable retainer clamp

Operating principle

The hub monitors the security system operation by communicating with
connected devices via the
range is up to 2000 m without obstacles (for example, walls, doors, inter- oor
constructions). If the detector is triggered, the system raises the alarm in 0.15
seconds, activates the sirens, and noti es the central monitoring station of the
security organization and the users.
If there is interference at the operating frequencies or when jamming is
attempted, Ajax switches to a free radio frequency and sends noti cations to
the central monitoring station of the security organization and to system users.
What jamming of a wireless security system is and how to resist it
Hub 2 Plus supports up to 200 Ajax devices connected, which protect against
intrusion, re, and ooding, as well as control electrical appliances automatically
according to scenarios or manually from an app.
To send photos from
separate Wings radio protocol and a dedicated antenna are used. This ensures
the delivery of visual alarm veri cation even with an unstable signal level and
interruptions in communication.
Jeweller encrypted protocol
MotionCam MotionCam Outdoor /
. The communication
motion detector, a
