3.6 Configuring the IP Address

GV-Control Center System V2 supports remote monitoring, control and configuration over a
network connection.
The system supports up to 2 Ethernet ports.
(Note: The figure is for reference only. The rear panel may vary due to product
enhancement.)
To change the static IP addresses or to enable dynamic IP address, follow the steps below.
1. Right-click the Network Connection icon
Network and Sharing Center.
Figure 3-26
2. Click Change Adapter Settings from the left-hand side menu of the Network and Sharing
Centre window.
3. Under Network Connections, select a network connection you want to configure its IP
address.
Figure 3-27
Figure 3-25
18
from the notification area and select Open
