- Page 1 GV-AS1520 Controller User’s Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. AS1520V10-A...
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
1.4 LED Status and Beeper ................... 5 Chapter 2 Getting Started ..................6 2.1 Basic Setup for GV-AS1520................6 2.2 Accessing the Web Interface of the GV-AS1520 ..........7 2.2 Accessing the Web Interface of the GV-AS1520 ..........7 Chapter 3 Installation ....................8 3.1 Connecting RS-485 Card Readers.............. - Page 4 5.2.5 Log Viewer ....................40 5.3 Extended Device.....................41 5.3.1 Extended Reader ..................41 Chapter 6 Troubleshooting..................43...
-
Page 5: Notice
Notice The product pattern is certified by the FCC. Unauthorized modification of the frequency, power, or originally designed functions and characteristics of the RFID reader are prohibited. This product has a water-resistant design. Unauthorized removal of the screws and case of the product will damage the water-resistant performance and void product warranty. -
Page 6: Optional Devices
Optional Devices Optional devices can expand the capabilities and versatilities of your GV-AS1520 Controllers. Consult your sales representative for more information. GV-SR1252 is a card reader that uses a 125 kHz frequency. It has both GV-SR1251 Wiegand and RS-485 outputs that can be connected to any standard access control panel. -
Page 7: Installation Considerations
Installation Considerations 1. Install the RFID reader with the antenna paralleled to the Tag for better reading results. The Tag receives signals and returns them to the Reader. 2. Install the RFID Reader and Tag as shown below. Correct Misplaced... - Page 8 3. RFID Reader Installation Position Do not install RFID Reader near metal or the metallic substance will affect the electromagnetic field type. Recommended height to set RFID reader is 1.8 ~ 2.2 m (5.9 ~ 7.2 ft). The height should not be lower than the location of RFID Tag. Recommended angle to set RFID reader is 15-20 degree.
- Page 9 4. The RFID Reader must be installed at the same side of the Tag or at the nearest reading range to the Tag. Upper Installation Proper Improper Side Installation Proper Improper 5. Recommended Tag Position Vehicles Place the tag on the front windshield or headlight, at the nearest reading range to the reader.
- Page 10 Windshield insulation films that contain metal ingredients will affect the reading range. To avoid such situation, install the Tag on the headlight. Motorcycles Install the Tag on the front shield and at the closest range to the RFID Reader. If there is no front shield available, it is suggested to install the Tag on the plastic body of motorcycle at the closest range to the RFID Reader.
- Page 11 6. For card-type tags, hold the card as shown below to ensure reading results. Correct Misplaced 7. Notice When the installation is complete, examine and adjust the environment parameters again for better reading results. Reading range between RFID Reader and the Tag will be shortened on rainy days.
-
Page 12: Chapter 1 Introduction
Introduction Chapter 1 Introduction GV-AS1520 is a controller with a built-in Radio Frequency Identification (RFID) reader of ISO18000-6C (EPC GEN2) standard. Designed for parking lot management, GV-AS1520 can read RFID tag within 10 m (32.8 ft). Figure 1-1... -
Page 13: Main Features
1.1 Main Features Built-in UHF Reader Builtin 1 digital input and 4 relay outputs 1 RS485 interface for connecting to up to 2 readers 1 network interface for connection with GVASManager and TCP/IP reader DC 12V / PoE+ (IEEE 802.3at, provides up to 25.5 W) ... -
Page 14: Packing List
GV-AS1520 L-Bracket Fixed-Clamp U-Clip Screw x 4 Quick Guide Warranty Card 1.3 Firmware and Software Compatibility The GeoVision software versions compatible with GV-AS1520 are listed below. GV-AS1520 Firmware Version Software V2.00 GV-ASManager V5.0.1.0 V5.0.2.0... -
Page 15: Wire Definitions
1.3 Wire Definitions Figure 1-2 Wire Definition 12V DC Black Blue RS-485+; see 3.1 Connecting RS-485 Card Readers. Light Blue RS-485–; see 3.1 Connecting RS-485 Card Readers. Brown DO COM; see 3.3 Connecting Output Devices. Green DO NO1 (Gate); see 3.3 Connecting Output Devices. Light Red DO NO2 (Alarm);... -
Page 16: Led Status And Beeper
Introduction 1.4 LED Status and Beeper You can find the LED at the bottom of your GV-AS1520. Condition Beeper Boot completed Green Two long beeps Ready Green The e-tag is detected but the access Displays red LED momentarily Three short beeps... -
Page 17: Chapter 2 Getting Started
Chapter 2 Getting Started 2.1 Basic Setup for GV-AS1520 The flowchart below covers the basic steps required to start running GV-AS1520. For detailed instructions, refer to the section number listed in each step. Connect card readers (Optional) Connect AS1520 to up to two readers through a single RS-485 cable 3.1 Connecting RS-485 Card Readers... -
Page 18: Accessing The Web Interface Of The Gv-As1520
Getting Started Accessing the Web Interface of the GV-AS1520 After connecting the required wires and cables for GV-AS1520, access its Web interface to configure the controller settings. See the section number below for detailed instructions. Static IP address Set network configurations 4.2 Configuring the Static IP Address... -
Page 19: Chapter 3 Installation
3.1 Connecting RS-485 Card Readers You can establish RS-485 connection with up to 2 readers through a single RS-485 cable. When connecting a second reader to GV-AS1520, you will need to set up a separate power source to power the second reader. -
Page 20: Connecting An Input Device
GV-AS1520 supports 1 type of input: Sensor input, e.g. infrared sensor. The input is dry contact and can be disabled and configured as normally open (NO) or normally closed (NC) through the GV-AS1520 Web interface. The default value is Disable. To change the input status, see 4.2.4 Input Configuration. -
Page 21: Connecting Output Devices
GV-AS1520 supports 3 types of outputs: 1. Alarm outputs, e.g. siren 2. Door outputs, e.g. gate 3. Signal outputs, e.g. green LED and red LED The table below shows the wire assignments of output connectors on GV-AS1520. Wire color Definition Brown... -
Page 22: Connecting The Pc
Installation 3.4 Connecting the PC Connecting GV-AS1520 to a computer allows you to access its Web interface and connect it to GV-ASManager if the computer is installed with GV-ASManager. The computer running GV-ASManager software can be used to monitor the access information and alarm messages from GV-AS1520. -
Page 23: Connecting The Power
When using a Power Adaptor, connect the 12V DC and GND wires to a 12V DC power adapter and then connect the power adapter to a power source. The table below shows the wire assignments of the power connectors on GV-AS1520. Wire color... -
Page 24: Installing Gv-As1520
Installation 3.6 Installing GV-AS1520 You can install the reader on a pole or a pillar. Two types of pole mounts are recommended, as indicated below. Figure 3-3 Note: Make sure the diameter of the pole is within 53 mm (0.17 ft). - Page 25 Secure the reader on a pillar or a pole using fixed-clamp and U-clip. Figure 3-5 Adjust the angle of the U-clip on L-bracket and secure the hexagon screw nuts. Adjust the angle Hexagon screw nuts Figure 3-6...
- Page 26 Installation Here is an overview of the pole mount. Figure 3-7...
-
Page 27: Chapter 4 Installing On A Network
Chapter 4 Installing on a Network You can install GV-AS1520 on a network and set up general settings and the input device through its Web interface. Through the network connection, you can also connect GV- AS1520 to GV-ASManager for more comprehensive management. -
Page 28: Checking The Dynamic Ip Address
LAN. 3. Click the Name or Mac Address column to sort. 4. Find GV-AS1520 with its MAC address, click on its IP address and select Web Page. Figure 4-1 5. When login dialog box appears, type the default ID and password admin and click OK to log in. -
Page 29: Configuring The Static Ip Address
4.2 Configuring the Static IP Address By default, GV-AS1520 uses a DHCP connection. However, you can follow the instructions to configure the static IP address. 1. Open an Internet browser, and type the default IP address https://192.168.0.100 or the dynamic IP address. The login dialog box appears. -
Page 30: Configuring Ddns Connection
Dynamic DNS uploads IP addresses over the Internet through ports 80 and 81. If your GV-AS1520 is connected behind a router or firewall, make sure ports 80 and 81 are enabled. Dynamic DNS will only upload global IP addresses. If your GV-AS1520 is using virtual IP, NAT port mapping should be done first. - Page 31 To install the LocalDDNS Server in a computer, download GV-Local DDNS Service from http://www.geovision.com.tw/download/product/ under the Supplemental Utilities drop-down list of GV-AS1520. Follow the on-screen instructions to install the application. After Installation, the program will be minimized to the system tray. Configuring Controller on LAN After running the LocalDDNS Server, configure the controller on LAN: 1.
- Page 32 Installing on a Network 5. Click Submit to send the information to the LocalDDNS Server. When the setting is complete, the Status field will indicate: Register Success. Then your GV-AS1520 can be accessed with the device name from the GV-ASManager.
-
Page 33: Connection Over Internet
ASManager can always access the controller by using the domain name. To enable the DDNS function, you should first apply for a domain name from the GeoVision DDNS Server, the DDNS service provider’s website. To register at the GeoVision DDNS Server, see the following instructions. - Page 34 Installing on a Network Figure 4-9 2. In the Hostname field, type a name. The hostname can be up to 16 characters with the choices of “a ~ z”, “0 ~9”, and “-”. Note that space or “-” cannot be used as the first character.
- Page 35 After acquiring a domain name from the DDNS Server, you need to configure the registered domain name on GV-AS1520 in order to access the unit by the domain name on Internet. 1. Open an Internet browser, and type the GV-AS1520’s IP address. The login dialog box (Figure 3-2) appears.
- Page 36 Installing on a Network 5. Click Submit. When the setting is complete, the Status field will indicate: Register Success. Then GV-AS1520 can be accessed with the domain name.
-
Page 37: Chapter 5 The Web Interface
Chapter 5 The Web Interface After installing the GV-AS1520 on the network, you can configure the controller settings on the Web interface. The left menu of the Web interface is divided into three sections: Basic Setting, Advanced Setting and Extended Device. -
Page 38: Basic Settings
The Web Interface 5.1 Basic Settings The Basic Settings section covers general system settings, firmware update and user account settings. For details on Network Setting, refer to Chapter 4 Installing on a Network. 5.1.1 System Setup In the left menu, click Other Configuration. This page appears. Figure 5-1... - Page 39 Device Port: Keeps the default value 4000. Or modify it to match that of GV-ASManager. GV-ASManager Connection Status: If GV-AS1520 is successfully connected to GV- ASManager, the system will automatically bring up the IP address of GV-ASManager. ...
-
Page 40: Upgrading Firmware
The Web Interface 5.1.2 Upgrading Firmware Follow the steps below to update the firmware of the controller. 1. In the left menu, click Firmware Update. This page appears. Figure 5-3 2. Click the Browse… button to open the firmware file (*.bin) 3. -
Page 41: Changing Login Id And Password
5.1.3 Changing Login ID and Password To change the login ID and password: 1. In the left menu, click Security Configuration. 2. Modify the login name and password. The password is case sensitive and is limited to alphabets and numbers. Figure 5-5... -
Page 42: Advanced Settings
The Web Interface 5.2 Advanced Settings Under Advanced Settings, you can configure the door settings, turn on Alarms, set the device time, edit the input function and view logs. Changes in some of the Advanced Settings pages will affect the options available on other pages. -
Page 43: Function Configuration
5.2.1 Function Configuration In the left menu, click Function Configuration. This page appears. Figure 5-7... - Page 44 Function: Select the function for GV-AS1520 connected to the Door/Gate. Parking Entry Control: The GV-AS1520 is installed at the entry door/gate of the parking lot for access control. Parking Exit Control: The GV-AS1520 is installed at the exit door/gate of the parking lot for access control.
- Page 45 This option lets you assign a camera to capture snapshots upon an e-tag being detected by GV-AS1520 or swiping a valid card on the connected reader. The captured snapshots will be saved to the flash drive of GV-AS1520 and then transfer to Access Log whenever GV- ASManager resumes connection after it has been disconnected.
-
Page 46: Parameter Configuration
5.2.2 Parameter Configuration In the left menu, click Parameter Configuration. This page appears. IMPORTANT: Once connected to GV-AS1520, GV-ASManager will load its parameters to the controller. That means some of the Parameter Settings you have configured here may be overwritten by GV-ASManager later. - Page 47 [Alarm] Select Yes or No to enable or disable the alarm function. The default settings are set to NO. Option Description Access Denied The access denied alarm on GV-ASManager. It activates whenever entry is denied due to using the wrong card or entering the wrong password.
-
Page 48: Time Configuration
The Web Interface 5.2.3 Time Configuration In the left menu, click Time Configuration to set up system time, local time and daylight saving time period. Figure 5-9... - Page 49 [System Local Time] Local Time: Displays the current date and time of the controller. Time Zone: Displays the current time zone of the controller. [Local Time] Disable: Disable the manual configuration of time and date. Setup: Enable the manual configuration of Time Zone, Date and Time for the controller. You can click the Current local time button to set synchronize the controller’s date and time with the PC’s current date and time.
-
Page 50: Input Configuration
The Web Interface 5.2.4 Input Configuration In the left menu, click Input Configuration to define the input device connected to the GV- AS1520. You set the input to NO (normally open), NC (normally close) or disable. Figure 5-10 Input Function Description Door/Car Sensor N/O When N/O is selected, the e-tag cannot be detected. -
Page 51: Log Viewer
5.2.5 Log Viewer In the left menu, click Log Viewer to select a log type and specify a time period to access the log information. Only up to 100 log entries of Event Log / Access Log can be retrieved at a time. -
Page 52: Extended Device
The Web Interface 5.3 Extended Device You can define the GV-Readers and GV-GF Fingerprint Readers connected to GV-AS1520 through RS-485 or network connection. 5.3.1 Extended Reader In the left menu, click Extended Reader Configuration. This page appears. Figure 5-12 [GV-Reader / CR420 / GF1921 / 1922 Function] Define the readers connected to the controller, and then use the Function drop-down list to select the door/gate associated with the reader. - Page 53 GV-CR420: Select the RS-485 checkbox only if the GV-CR420 is connected to the controller through RS-485 connection. If the reader is using network connection, do not check the RS485 box. Type the MAC address of GV-CR420 if you using the latest GV- CR420 firmware.
-
Page 54: Chapter 6 Troubleshooting
ASManager and GV-AS1520 respectively. This procedure can determine if the problem is caused by the faulty devices and incorrect network settings. 1. Disconnect the hub or switch, which connects the GV-ASManager and GV-AS1520, from the network. 2. Give the GV-ASManager a fixed IP address that is NOT used by another device, e.g. - Page 55 5. Open the browser and type the controller default address: http://192.168.0.100 Figure 6-2 6. In the IP address field, give the controller an IP address that is NOT used by another device, e.g. 192.168.0.XXX. 7. On the GV-ASManager, type the following settings: Controller ID: 1 Network: TCP/IP IP: 192.168.0.XXX...
- Page 56 5. Open the browser and enter the assigned IP address of the controller. The Network Configuration page appears. See Figure 6-2. 6. In the IP address field, give the GV-AS1520 an IP address that is NOT used by another device, e.g. 192.168.0.XXX.
- Page 57 Q4: After I add a card by presenting to the reader, the message “Access Denied Invalid Card” still appears. It may be the card format is not compatible with the GV-AS1520. Make sure the card format is 64 bits. Otherwise, send us the related information of your card format so that we can customize the format for you.
- Page 58 Troubleshooting 2. Make sure the correct GV-Reader ID is set on the controller. See 4.3.1 Extended Reader for details. Q6: How can I find more help? Visit our website at http://www.geovision.com.tw Write to us at support@geovision.com.tw...
