Add Static IP Address Binding

Click the add button
box:
Click the Save button to add the rule to the Static IP Address Binding List.

VLAN Settings

Create a Virtual Local Area Network (VLAN) custom network from one or more existing LANs.

Add a VLAN Binding

Click the add button
Enter the new VLAN details. Select an Interface Port from the drop down list and create a VLAN ID [the ID
must be a number between 3-4094].
Click the Save button to add the rule to the VLAN Binding List.
CF40MESH Wi-Fi 6 Gateway– User Guide
UG01438 v1.00 December 2022
in the Static IP Address Binding List heading bar to open the configuration popup
Figure 29 - Advanced Setup – Add Static IP Address Binding list dialog
Figure 30 - Network Setting – LAN – VLAN Settings
in the VLAN Binding List heading bar to open the Add Rule popup box:
Figure 31 - Advanced Setup – Add VLAN Binding Rule dialog
