  • Page 1 Operation Manual ParaBeam 410 & 210 DMX ® ParaBeam 410 Yoke Mount ParaBeam 410 Pole-Op Part No. 3100064 Rev B 11-18-2015...
  • Page 2 ParaBeam Fixture Styles and Features ParaBeam Yoke Mount PAR-410Y-120 ParaBeam 410 DMX Yoke Mount, 120VAC PAR-410Y-230 ParaBeam 410 DMX Yoke Mount, 230VAC PAR-210Y-120 ParaBeam 210 DMX Yoke Mount, 120VAC PAR-210Y-230 ParaBeam 210 DMX Yoke Mount, 230VAC ParaBeam Pole-Op PAR-410P-120 ParaBeam 410 DMX Pole-Op, 120VAC PAR-410P-230 ParaBeam 410 DMX Pole-Op, 230VAC PAR-210P-120...
  • Page 3 Included w/ all ParaBeam Models GFR-P4 ParaBeam 410 Gel Frame (Included) GFR-P2 ParaBeam 210 Gel Frame (Included) LVR-P490-P ParaBeam 410 Louver/HP, 90° (Included) LVR-P290-P ParaBeam 210 Louver/HP, 90° (Included) True Match Lamps ® 55C-K32 55W Kino KF32 Compact 55C-K55 55W Kino KF55 Compact...
  • Page 4 ParaBeam Yoke Mount The yoke has a ½” hole to accept industry standard mounting hardware. The ParaBeam 410 Yoke Mount can hang from a grid by a junior pipe hanger using a Junior Pin Assembly for Yoke (MTP-I80), sold separately.
  • Page 5 ParaBeam Pole-Op The ParaBeam 410 and 210 Pole-Op fixtures include a yoke with an attached junior pin. They can be hung from a grid with a Junior pipe hanger. Junior pin attached to Pole-Op Yoke Pole Operation The Blue cup alters the Pan (left or right.) The White cup alters the Tilt (up or down.) Warning! Do not pull yoke to adjust tilt.
  • Page 6 ParaBeam Center Mount The ParaBeam 410 Center Mount includes a lollipop w/ Junior Pin (MTP-LM) and can hang from a grid by a Junior pipe hanger or mount onto a Junior stand. Note: Loop the safety chain through the handle on the ParaBeam 410. The ParaBeam 210 Center Mount includes a lollipop w/ Baby Receiver (MTP-LB) and can hang from a grid by a baby pipe hanger or mount onto a baby stand.
  • Page 7 Note: When looking at the back of the fixture, the Kino Flo logo should read: If the Logo is upside down, the fixture does not have the correct orientation.
  • Page 8 Mounting Barndoors Side Doors First apply Side Doors by inserting the hinge bracket into the extruded edge. Lock the bracket by turning the silver thumbscrew. Top & Bottom Doors Position the Top and Bottom Doors to allow for sufficient movement. Hinge Tension Adjustment Hinge tension on Top &...
  • Page 9 Inserting Lamps Open hinged reflector door. Insert lamp end first. Snap lamp pins into To release lamps, Close reflector door. lamp holder. press Red button and lift lamp out. Inserting Gel Frame and Louver Push tab down and forward Insert gel frame into to lock into open position.
  • Page 10: Fixture Operation

    Fixture Operation Warning! To Ensure Proper Operation ALWAYS TURN OFF THE FIXTURE BEFORE connecting or disconnecting lamps. After the lamps are properly installed, the fixture can be turned on. Avoid operating in temperatures above 125°F (51°C) or below 60°F (15°C). In temperatures below 60°F or 15°C, the fixture may take longer to strike.
  • Page 11: Manual Operation

    Manual Operation The onboard dimmer knob can manually dim lamps. The MANUAL DIM LAMPS switch selects 4 lamp or 2 lamp operation. Select the 2 lamp setting to turn off the outer lamps. Note: All manual controls are disabled as soon as the DMX cable is applied.
  • Page 12 Auto Terminate Feature The ParaBeam 410 and 210 series have an “AUTO TERMINATE” feature. The last fixture that does not have an XLR cable attached to the DMX “Out” port will automatically terminate. Any theatrical lighting board with DMX512 protocol can be used to individually turn on/off lamps in a fixture.
  • Page 13: Troubleshooting

    Troubleshooting LAMPS FAIL TO LIGHT: • With the power switch in the ON position, the red light should be on. If it is not, voltage is not present. Check your power feed. Check the fuse on the fixture and replace if necessary (5 x 20mm, T3.15AH/250V, Time Delay Type). •...
  • Page 14: Accessories And Parts

    Accessories and Parts BRD-P4 ParaBeam 410 Barndoors (Set of 4) BRD-P2 ParaBeam 210 Barndoors (Set of 4) LVR-P460-P ParaBeam 410 Louver/HP, 60° LVR-P260-P ParaBeam 210 Louver/HP, 60° MTP-I80 Junior Pin Assembly for Yoke (28mm) MTP-I40 Baby Receiver Assembly for Yoke (16mm) MTP-LB Kino 41 Lollipop w/ Baby Receiver (16mm) MTP-LM...
  • Page 15: Fixture Specifications

    Fixture Specifications Model: PAR-410Y ParaBeam 410 DMX Yoke Mount Input Voltage: 120VAC or 230VAC 50/60Hz Output Frequency: 30kHz Amperage: 2.0A at 120VAC 1.1A at 230VAC Lamp Switching: 4/2 Dimming Range: 100%~5% Weight w/ lamps: 23 lbs /10.5kg ParaBeam 410 Dimensions: 29.5 x 26.5 x 6” Yoke Mount (75 x 67 x 15cm) Lamp type:...
  • Page 16 Lamp type: 55W CFL w/ 2G11 base For latest Warranty information and Certifications, see Kino Flo website at www.kinoflo.com. Environmental: Disposal of Old Electrical & Electronic Equipment. This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.
