NOTE
When a tripod is used, the adjustable feet will
have no effect.
SWITCHING ON/OFF LASER LINES
When switching on the device, only two of the
four horizontal laser lines will be activated.
HORIZONTAL LASER LINES
To change the projected horizontal laser lines,
press the H-button for horizontal lines [B].
 
· Press the H-button [B] a fi rst time to switch on
all horizontal lines.
· Press the H-button [B] a second time time to
switch off all horizontal lines.
· Press the H-button [B] again to switch on two of
the four horizontal laser lines.
· ... (these three previous steps will repeat)
VERTICAL LASER LINES
To change the projected vertical laser lines, press
the V-button for vertical lines [C].

· Press the V-button [C] a fi rst time to switch on
two of the four verical laser lines and the plumb
point (projected from the tripod thread [05]).
· Press the V-button [C] a second time to switch
on all vertical laser lines and the plumb point
(projected from the tripod thread [05]).
· Press the V-button [C] a third time to switch off
all vertical lines and the plumb point (projected
from the tripod thread [05]).
· ... (these four previous steps will repeat)

...
NOTE
When at least two vertical lines are switched on,
you can measure an exact angle of 90° or show
a plumb line (imaginary line between the cross
on the fl oor and the cross on the ceiling)
USING A LASER RECEIVER
When you work over long distances or the
workplace has a high brightness, laser lines will
be less visible for the human eye. In this case, you
can use a laser receiver to detect the laser lines.
 
...
