  • Page 1 USER EN ENGLISH MANUAL 062.03R SPINNER RED Manual 062.03G SPINNER GREEN in your language? Check the back cover...
  • Page 2 OVERVIEW...
  • Page 3 HOUSING KEYPAD REMOTE CONTROL 01 Laser head Power button Arrow UP button 02 Plumb point up (Z-axis) Arrow UP button Arrow DOWN button 03 Keypad Arrow DOWN button Arrow LEFT button 04 X-axis D Arrow LEFT button Arrow RIGHT button 05 Y-axis Arrow RIGHT button Speed button...
  • Page 4 QUICK START GUIDE Power button Press short Switch ON/OFF the device Arrow UP button Press short or Hold Change the slope. Y-axis rises on the side pointed by the arrow of the y-axis. Arrow DOWN button Press short or Hold Change the slope.
  • Page 5 LED Slope indicator Slope modus OFF Red, continuous Slope modus ON Red, flashing Laser out of levelling range LED Tilt indicator Tilt security OFF Red, flashing slow Preparing TILT security Red, continuous TILT security active Red, flashing fast TILT alarm LED Power indicator Green, continuous Power ON...

  • Page 6: Automatic Functions

    SAFETY AUTOMATIC FUNCTIONS Please read the safety instructions provided as AUTO-LEVELLING separate booklet with the device. This rotation laser always levels itself automati- LASER RADIATION – Class 2 Laser product. – Do cally after turning on the device. After being lev- not stare into beam elled, the laser starts spinning.

  • Page 7: Horizontal Alignment

    start before the Tilt-security is active. Tilt-security is the best choice if accuracy is the Press the power button [A] to activate the device. most important. NOTE BASIC MODE (TILT-SECURITY OFF) The choice of the tripod defi nes in a large way the user-friendliness of the device.

  • Page 8: Vertical Alignment

    VERTICAL ALIGNMENT NOTE The device should not be placed on a surface with a slope of more than 5°. If this is the case, the laser is outside the self-levelling range, in which case the laser diode will continue to blink and the LED slope indicator [L] will fl ash red.
  • Page 9 ANGLES OF 90° SPINNING SPEED 90° 0 RPM 120 RPM 300 RPM 600 RPM In vertical position, it is possible to project angles This device has multiple spinning speeds. 0, 120, of 90°. 300 and 600 RPM (rotations per minute). The default rotation speed is 600 RPM.

  • Page 10: Scan Function

    SCAN FUNCTION To set up slopes, you must take a few steps in the right order. NOTE Keep in mind that auto-levelling is disabled when working with the slope function. 0 ° 10° 45° 90° 180° HORIZONTAL SLOPE, <5° The scan function allows to limit the laser beam to an angle instead of the complete 360°...
  • Page 11 VERTICAL SLOPE, <5° · Place the receiver by means of the clamp on a measuring rod and slide the receiver until the laser beam is at the zero level of the receiver. · Activate the Slope function with the slope but- ton [H].
  • Page 12 HORIZONTAL SLOPE, >5° Steeper slopes, slopes outside the laser leveling range, can be set using a slope adapter, which is available as optional accessory. > 5° In case you use this slope adapter: · Place the laser in its horizontal (normal) position on the slope adapter.

  • Page 13: Specifications

    SPECIFICATIONS 062.03R 062.03G SPINNER RED SPINNER GREEN Visibility Precision 1,5mm / 10m Range (with receiver) 2x ± 250m Dust- and water resistance IP55 Levelling Motorised Plumb bob ✔ Rotations per minute 0, 120, 300, 600 Scan function 0°, 10°, 45°, 90°, 180°...
  • Page 14 DECLARATION OF CONFORMITY Futech (Belgium) declares under its own responsibility that this device: - 062.03R, Spinner RED - 062.03G, Spinner GREEN is in conformity with the standards EN 61000-6-3:2007+A1:2011, EN 61000-6-1:2007, EN 60825-1:2014, EN 61010-1:2010, following the provisions of Directive(s) 2014/30/EU, 2014/35/EU.
  • Page 15 NOTES...
