OVERVIEW
03
02
01
07
08
C
F
B
G
2
02
04
06
01
05
08
08
07
HOUSING
03
01 Horizontal laser line
D
02 Vertical laser line
E
03 Keypad
H
04 Belt
A
05 5/8" Tripod thread /
downpoint
06 Li-ion battery
07 Fine adjustment
08 Adjustable foot
KEYPAD
A
Power button
B
H-button for horizontal
lines
C
V-button for vertical lines
D Receiver buttons
E
Slope button
F
Indicator LED Y-axis
G Indicator LED X-axis
H
Slope indicator LED
08
07
08
