· Activate the manual slope mode by pressing
the slope button [E] in the center of the keypad
[03].
When the manual slope mode is active, the slope
indicator LED [H] becomes red and the indicator
LED Y-axis [F] starts fl ashing green to indicate
slope can be set in parallel with the Y-axis.
· Press or hold the V-button [C] to make the laser
line descends on the side pointed by the arrow
of the Y-axis.
· Press or hold the H-button [B] to make the laser
line rises on the side pointed by the arrow of
the Y-axis.
· To change to the Y-axis, press the receiver
button [D].
10
The indicator LED Y-axis [F] stops fl ashing, the in-
dicator LED X-axis [G] starts fl ashing. This shows
the device is ready to be set the slope in parallel
with the X-axis.
· Press or hold the V-button [C] to make the laser
line rises on the side pointed by the arrow of
the Y-axis.
· Press or hold the receiver button [D] to make
the laser line descend on the side pointed by
the arrow of the Y-axis.
The slope is now set on the X- and Y-axes.
If you like, you can go back to adapt the Y-axis
by pressing the H-button [B]. The indicator LED
X-axis [G] will no longer fl ash. The indicator LED
Y-axis [F] will starts fl ashing. This shows the Y-axis
is ready to set.
You can repeat this steps as much you like.
· Turn off the slope mode by pressing the slope
button [E].
The laser is going to auto-level itself again.
