- Page 1 USER EN ENGLISH MANUAL 035.3DR MULTICROSS 3D COMPACT RED Manual 035.3DG MULTICROSS 3D COMPACT GREEN in your language? 035.4DG MULTICROSS 4D COMPACT GREEN Check the back cover...
- Page 2 OVERVIEW...
-
Page 3: First Time Usage
SAFETY CASE 01 On/Off switch / Pendulum lock Please read the safety instructions provided as 02 Laser window separate booklet with the device. 03 USB Type-C charging port LASER RADIATION – Class 2 Laser product. – Do not stare into beam 04 Battery cover 05 Keypad BATTERY... - Page 4 SELF LEVELLING MODE · Shift the Pendulum lock [04] to the “Unlock” position to unlock the pendulum and switch on Should the slope exceed 4°, the laser lines will the laser. either blink fast and the laser will start beeping. At this point the laser is able to level itself.
-
Page 5: Good To Know
CHOOSE HORIZONTAL AND VERTICAL LINES At times, you may not require all laser lines, making it useful to activate only the ones needed. Therefore, you have the option to deactivate or activate specific laser lines as desired. · Make sure the Pendulum lock [04] is in the “Lock”... - Page 6 Lier, Belgium, January 29, 2024 Patrick Waûters NOTE All Futech laser will use 10Khz as frequency in receiver mode. Only receivers that can detect Potential misprints are reserved. Images used are not strict. All features, laser lines at 10KHz are compatible.
-
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS 035.3DR 035.3DG 035.4DG MC3D COMPACT RED MC3D COMPACT GREEN MC4D COMPACT GREEN Visibility Accuracy ± 3mm / 10m ± 3mm / 10m ± 3mm / 10m Range with receiver up to 2x 120m up to 2x 150m up to 2x 150m Levelling range ±... - Page 8 USER MANUAL other languages: DANSK ITALIANO DEUTSCH NEDERLANDS ESPAÑOL NORSK EESTI KEEL PORTUGUÊS SUOMEN KIELI SLOVENŠČINA FRANÇAIS SVENSKA ÍSLENSKA Facebook @futechtools LinkedIn futechtools World Wide Web futech-tools.com YouTube @futechtools...
