Agora Models NO TIME TO DIE DB5 Build Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
B U I L D
STAGE 058: BUILDING THE ENGINE BAY
RIGHT WALL
STAGE 059: BUILDING THE FIREWALL
STAGE 060: BUILDING THE ENGINE BAY
LEFT WALL
STAGE 061: FITTING THE SPEAKER
AND RADIATOR HEADER TANK
STAGE 062: FITTING THE IGNITION COIL
AND PIPES
NO TIME TO DIE © Danjaq, LLC and Metro-Goldwyn-Mayer Studios Inc. NO TIME TO DIE,
Metro-Goldwyn-Mayer Studios Inc. NO TIME TO DIE,
Pack 08
I N S T R U C T I O N S
and related James Bond Trademarks are trademarks of Danjaq, LLC. All Rights Reserved.
Aston Martin, the Aston Martin Wings logo and the model name "DB5" are trademarks owned, licensed
or used by Aston Martin Lagonda Limited. All Rights Reserved.
STAGE 063: FITTING THE AIR FILTER,
MOUNTING THE ENGINE AND FIXING
THE INTERIOR FLOOR
STAGE 064: BUILDING THE
MINE DISPENSER
STAGE 065: FITTING THE
MINE DISPENSER
STAGE 066: FITTING THE
EXHAUST PIPES
