Warnings and Alarms

8.4 Warning and Alarm Definitions

Table 8.2 defines whether a warning is issued prior to an
alarm, and whether the alarm trips the unit or trip locks
the unit.
No. Description
1 10 Volts low
2 Live zero error
4 Mains phase loss
5 DC link voltage high
6 DC link voltage low
7 DC over voltage
8 DC under voltage
9 Inverter overloaded
10 Motor ETR over temperature
11 Motor thermistor over temperature
12 Torque limit
13 Over Current
14 Earth (Ground) fault
15 Hardware mismatch
16 Short Circuit
17 Control word timeout
20 Temp. Input Error
21 Param Error
22 Hoist Mech. Brake
23 Internal Fans
24 External Fans
25 Brake resistor short-circuited
26 Brake resistor power limit
27 Brake chopper short-circuited
28 Brake check
29 Heatsink temp.
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Inrush fault
34 Fieldbus communication fault
35 Option Fault
36 Mains failure
37 Phase Imbalance
38 Internal fault
39 Heatsink sensor
40 Overload of Digital Output Terminal 27
41 Overload of Digital Output Terminal 29
42 Ovrld X30/6-7
43 Ext. Supply (option)
®
VLT Automation Drive D-Frame
Operating Instructions
Warning Alarm/Trip
X
(X) (X)
(X) (X)
X
X
X X
X X
X X
(X) (X)
(X) (X)
X X
X X
X X
X
X
(X) (X)
(X) (X)
X
X
X
(X) (X)
X X
(X) (X)
X X
(X) (X)
(X) (X)
(X) (X)
X
X X
X X
X X
X
X
X
(X)
(X)
(X)
®
MG34U202 - VLT is a registered Danfoss trademark
Alarm/Trip Lock Parameter Reference
6-01 Live Zero Timeout
Function
(X) 14-12 Function at Mains
Imbalance
1-90 Motor Thermal Protection
1-90 Motor Thermal Protection
X
X
X
X
8-04 Control Timeout Function
Parameter Group 2-2*
14-53 Fan Monitor
2-13 Brake Power Monitoring
2-15 Brake Check
X
(X) 4-58 Missing Motor Phase
Function
(X) 4-58 Missing Motor Phase
Function
(X) 4-58 Missing Motor Phase
Function
X
X
X
5-00 Digital I/O Mode,
5-01 Terminal 27 Mode
5-00 Digital I/O Mode,
5-02 Terminal 29 Mode
8 8
59
