Danfoss VLT AutomationDrive FC 300 Operating Instructions Manual page 79

Specifications
Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Resolution of frequency outputs
1) Terminal 27 and 29 can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 V DC output
Terminal number
Max. load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV ), but has the same potential as the analog and digital
inputs and outputs.
Relay outputs
Programmable relay outputs
Relay 01 Terminal number
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Min. terminal load on 1-3 (NC), 1-2 (NO)
Environment according to EN 60664-1
Relay 02 Terminal number
Max. terminal load (AC-1)
Max. terminal load (AC-15)
10 10
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Min. terminal load on 4-6 (NC), 4-5 (NO)
Environment according to EN 60664-1
1) IEC 60947 t 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2) Overvoltage Category II
3) UL applications 300V AC 2 A
Control card, 10 V DC output
Terminal number
Output voltage
Max. load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control characteristics
Resolution of output frequency at 0-1000 Hz
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open loop)
Speed accuracy (open loop)
All control characteristics are based on a 4-pole asynchronous motor
76
®
VLT Automation Drive D-Frame
Operating Instructions
1)
on 1-2 (NO) (Resistive load)
on 1-2 (NO) (Inductive load @ cosφ 0.4)
1)
1)
on 1-2 (NO) (Resistive load)
1)
on 1-2 (NO) (Inductive load)
1)
on 1-3 (NC) (Resistive load)
on 1-3 (NC) (Inductive load @ cosφ 0.4)
1)
1)
on 1-3 (NC) (Resistive load)
1)
on 1-3 (NC) (Inductive load)
1)
on 4-5 (NO) (Resistive load)
on 4-5 (NO) (Inductive load @ cosφ 0.4)
1)
1)
on 4-5 (NO) (Resistive load)
1)
on 4-5 (NO) (Inductive load)
1)
on 4-6 (NC) (Resistive load)
on 4-6 (NC) (Inductive load @ cosφ 0.4)
1)
1)
on 4-6 (NC) (Resistive load)
1)
on 4-6 (NC) (Inductive load)
MG34U202 - VLT
2)3)
overvoltage category III/pollution degree 2
2)3)
overvoltage category III/pollution degree 2
®
is a registered Danfoss trademark
Max. error: 0.1 % of full scale
1-3 (break), 1-2 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 2 mA
4-6 (break), 4-5 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 2 mA
10.5 V ±0.5 V
1:100 of synchronous speed
30-4000 rpm: Maximum error of ±8 rpm
0 Hz
32 kHz
12 bit
12, 13
200 mA
2
50
25 mA
±0.003 Hz
≤2 ms
