- Page 1 INSTRUCTION MANUAL AIR 53 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.0x16mm SCREW M3.5x45mm SCREW 12PCS+1spare 18PCS+1spare Latch Roof hinge... - Page 4 PARTS Left Panel Front Panel Back Panel Metal Tray Right Panel Divider Wooden Floor Wooden Board Bottom Wire Netting...
- Page 5 PARTS Roof Ramp Layer Brake casters Normal casters 2PCS 2PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach side panel Part C & D and divider Part E to back panel Part B by 6xP1 screws. Attach front panel Part A by 6xP1 screws. - Page 7 PRODUCT ASSEMBLY ① Put in the wooden floor Part I as show on the picture. ② Slide in the tray Part F. Put in wooden board Part G & bottom wire netting Part H.
- Page 8 PRODUCT ASSEMBLY Screw ramp Part K to layer Part J by 4XP2. Then put it in the house. Attach roof Part L by 6XP2 screws.
- Page 9 PRODUCT ASSEMBLY Attach roof hinge P3 by 4XP2 screws. Attach casters Part M & N to the legs.
- Page 10 PRODUCT ASSEMBLY Attach lock P4 by 4XP2 screws.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
