32. C1 Button
Customize functions in DJI Pilot 2.
33. C2 Button
Customize functions in DJI Pilot 2.
34. Rear Cover
35. Battery Release Button
36. Battery Compartment
For installing the WB37 intelligent battery.

Mounting the WB37 Intelligent Battery

1. Push the rear cover release button to the end to open the rear cover.
2. Insert the WB37 battery into the battery compartment and push forward until it clicks firmly
in place.
3. Close the rear cover.
• To remove the WB37 battery, press and hold the battery release button.
MATRICE 350 RTK User Manual
37. Rear Cover Release Button
38. Alarm
39. Air Intake
For heat dissipation. DO NOT block the
air intake during usage.
40. M4 Screw Hole
For mounting the strap bracket.
3
2
1
©
