Using the Battery Station

Charging
1. Connect the battery station to a power outlet using a AC power cable.
2. Press the power button once to power on the battery station.
3. Charging the TB65 batteries:
a. Align the orange marks on the TB65 battery and the battery port, then insert the batteries
into the battery ports.
b. Toggle the charging mode switch to Storage Mode, Ready-to-Fly Mode, or Standard Mode.
Storage Mode
charging. Storage Mode is good for long-term battery storage.
Ready-to-Fly Mode
after charging. Ready-to-Fly Mode facilitates quick use of batteries.
Standard Mode
c. The battery station will charge the batteries in pairs. The pair with the highest power will
be charged first.
4. Charging the WB37 batteries: insert the WB37 batteries, and the battery with the highest
battery level will be charged first.
5. Charging the DJI RC Plus remote controller: connect the remote controller to the USB-C
charging port using a USB-C to USB-C cable.
• The battery station should stay powered on to maintain the battery level in Storage
Mode and Ready- to-Fly Mode. Maintaining a high power level in Ready-to-Fly Mode
will affect battery life. Power off the battery station after charging, except for special
situations such as fire emergencies.
• Connect the remote controller to the maintenance port and run DJI Pilot 2 to view
battery information, update the firmware, or diagnose the error.
• When the temperature of the TB65 battery is below 18° C (64.4° F), the batteries will be
automatically warmed up after being inserted into battery station and powered on.
: each battery pair is charged to 50% in sequence and kept at 50% after
: each battery pair is charged to 90% in sequence and kept at 90%
: each battery pair is charged to 100% in sequence.
MATRICE 350 RTK User Manual
©
2023 DJI All Rights Reserved.
67
