- Page 1 Machine Translated by Google Parachute system and Circuit breaker DJI MATRIX 350 RTK Before handling the parachute system, read this manual carefully.
- Page 2 Machine Translated by Google INSTRUCTIONS FOR USE PRESENTATION Flying Eye has been your partner specializing in drone technology since 2009. We have been developing parachute systems since the appearance of drone regulations in 2012. A pyrotechnic system based on aviation technology, you have the most efficient and lightest system on the market.
- Page 3 Machine Translated by Google INSTRUCTIONS FOR USE WARNINGS AND PRECAUTIONS FOR USE The Flying Eye company may suspend the warranty and release itself from any liability to any person who does not respect the basic safety instructions set out below. Flying Eye disclaims all liability for damage or injury related directly or indirectly to the use of pyrotechnic cartridges or through the use of pyrotechnic cartridges that do not meet safety requirements and standards.
- Page 4 The assembly and disassembly of the system can be done by the customer. The system does not modify the integrity of the DJI MATRICE 350 RTK. The DJI manufacturer's warranty is retained. Fits in the original Matrice 300 RTK case.
- Page 5 Machine Translated by Google INSTRUCTIONS FOR USE CONTENT : • 2 parachute containers • 1 left interposer module • 1 right interposer module • 1 cradle (landing gear support) • 2 charging caps • 2 pyrotechnic charges • 1 remote control •...
- Page 6 Machine Translated by Google INSTRUCTIONS FOR USE PARACHUTE RADIO CONTROL Radio control charge level: To find out the charge level, press the “POWER” button once, indicator lights appear. Getting started: To turn on the parachute radio control, make a short press then a long press on the “POWER” button.
- Page 7 Machine Translated by Google INSTRUCTIONS FOR USE The different alerts on the system radio control: Operational system Loss of connection with the drone Safety pin in place Missing load(s) System Triggering 09/20/2023 FLYSAFE-M350 Version 1.1 Hardware version 1.04...
- Page 8 Machine Translated by Google INSTRUCTIONS FOR USE PARACHUTE RADIO CONTROL MOUNTING OPERATING MODE Take the following 3 pieces (as well as the M30 radio control): Radio Control Parachute RC Bracket Support Screw Insert the RC support on the parachute radio control and screw in the 2 small screws using an allen key (supplied with the M30) as below: Then attach everything to the M30 radio control by inserting the 2 small pins of the RC support into the 2 holes (orange arrows) and then insert the screw of the support into the screw thread of the M30 radio...
- Page 9 Machine Translated by Google INSTRUCTIONS FOR USE FACILITY Installation of the parachute cradle: In order to position the parachutes on the drone you must: Unscrew the two landing gear supports Position the cradle in place under the drone cradle. Secure it using the 4 screws on each side (USB connector towards the front) Installation of the battery butterfly: In order to be able to lock the batteries with...
- Page 10 Machine Translated by Google INSTRUCTIONS FOR USE Installation of the circuit breaker modules: To place the circuit breaker modules on each side in the battery slots, insert them from the rear by sliding them forward. Slide the modules all the way forward to the stop to ensure a good connection to the connector. The circuit breaker modules can remain in place for storage in the M350 RTK case.
- Page 11 Machine Translated by Google INSTRUCTIONS FOR USE PROPER FUNCTIONING TEST Before each flight, you must check all the elements constituting the system and verify its integrity. If an anomaly is noted, do not proceed with the theft and contact your dealer. Test for proper operation on the ground: •...
- Page 12 Machine Translated by Google INSTRUCTIONS FOR USE MAINTENANCE 09/20/2023 ANNUAL MAINTENANCE Change of pyrotechnic charges. Ventilation of the sail for 24 hours, canvas, line and folding inspection. For optimal operation of the system, annual maintenance of the sail is essential. STORAGE AND WARRANTY SPECIFIC MAINTENANCE: You must dry the sail immediately after any contact with humidity or water to avoid any damage.
- Page 13 Machine Translated by Google Contact us : Flying Eye 400 avenue roumanille Green Side - Bat. 06410 Biot Mail : info@flyingeye.fr Tel: 09 72 62 78 50...
